SPECIFICATIONS

b
c
▲
M16MG/M16TG
▲ M36MG/M36TG
Model
M16MG / M16TG
M24MG / M24TG
M36MG / M36TG
M48MG / M48TG
M60MG / M60TG
a
f
g
h
▲ M60MG/M60TG
Dimensions
(H x W x D)
15.3" x 16.0" x 26.0"
15.3" x 24.0" x 26.0"
15.3" x 36.0" x 26.0"
15.3" x 48.0" x 26.0"
15.3" x 60.0" x 26.0"
7
d
e
▲ Model M24MG/M24TG
k
▲ M48MG/M48TG
m
n
NG
Burners
(KW/BTU)
30,000 1
60,000 2
90,000 3
120,000 4
150,000 5
Figure 1
a. 15.3" (389 mm)
b. 26.0" (660 mm)
c. 16.0" (406 mm)
d. 15.3" (389 mm)
e. 26.0" (660 mm)
f. 24.0" (610 mm)
g. 15.3" (389 mm)
h. 26.0" (660 mm)
j
i. 36.0" (914 mm)
j. 15.3" (389 mm)
k. 26.0" (660 mm)
l. 48.0" (1219 mm)
m. 15.3" (389 mm)
n. 26.0" (660 mm)
o. 60" (1524 mm)
Net Weight
103.0 lbs
(46.7 kg )
114.0 lbs
(51.7 kg)
176.0 lbs
(79.8 kg)
244.0 lbs
(110.7 kg)
300.0 lbs
(136.1 kg)
