- Page 1 GLOBAL LIFT CORP Owner’s Manual ROTATIONAL SERIES R-375 NEED New Picture 684 N Port Crescent Rd Suite C Bad Axe, MI 48413 Toll Free: 866-712-0606 Fax: 989-269-5902 www.globalliftcorp.com Page | 1...
- Page 2 ROTATIONAL SERIES POOL LIFTS R-375 TABLE OF CONTENTS INTRODUCTION PAGE – 3 ADA GUIDELINES FOR PLACEMENT PAGE – 4 24 VOLT BATTERY SYSTEM/WITH CONTROLS PAGE – 5 ROTATIONAL SERIES OPERATING INSTRUCTIONS PAGE – 6 UNIT MAINTENANCE AND CARE PAGE – 7 TROUBLE SHOOTING PAGE –...
- Page 3 Your Number One Choice for Commercial Pool Access Equipment Global Lift Corp. is located in Mid Michigan, Global Lift Corp. prides itself in manufacturing top of line quality aquatic access equipment. Global Lift Corp.'s key staff has a century of combined industry experience and we take pride in each and every product that we build.
- Page 4 ADA GUIDELINES FOR POOL LIFT PLACEMENT 1. Pool Lift Location. Pool lifts shall be located where the water level does not exceed 48 inches (1220 mm). 2. Seat Location. In the raised position, the centerline of the seat shall be located over the deck and 16 inches (405 mm) minimum from the edge of the pool.
-
Page 5: Recharging The Battery
24 VOLT BATTERY SYSTEMS WITH CONTROLS All of Global Lift Corp’s Rotational Series Lifts are equipped with a sealed 24 volt battery that is rechargeable. Along with a charging unit, hand held controller and control compartment. The 24 volt battery mounts right above the control compartment and the battery simply snaps in. - Page 6 ROTATIONAL SERIES POOL LIFT OPERATING INSTRUCTIONS Prior to using the Rotational Series Pool Lift, perform a test run of the lift empty. Once that is completed and the lift is back to original position, make sure that the arm lifts...
-
Page 7: Maintenance
Maintenance Regular servicing will help prolong the life of your lift. Routine maintenance and cleaning is very important. The following is a routine maintenance you should follow. Daily Check and charge battery Test for normal operations Inspect your lift Clean the lift and seat Cover and store lift after use Weekly o Overview Daily Checklist... -
Page 8: Troubleshooting Guide
TROUBLESHOOTING GUIDE Before any troubleshooting commences make sure the battery has a full charge! (1) Does the lift raise or lower (a) Check the battery connection and reconnect (b) Check hand controls, make sure they are connected properly (c) Check for any lose wires on the control compartment (d) Check the connection cable for damage (2) Did the lift stop moving over water and is stuck? (a) Have a person or attendant push the emergency return button... - Page 9 Global Lift Corp's decision regarding the claim. If the request made by Global Lift Corp for the product to be returned to its factory or distributor of choice for inspection and/or repair, purchaser will be liable for "Freight Prepaid". Global Lift Corp at its...
- Page 10 THIS LIMITED WARRANTY. THE SOLE AND EXCLUSIVE REMEDY OF THIS WARRANTY IN REGARDS TO GLOBAL LIFT CORP'S PRODUCT SHALL BE LIMITED TO REPLACEMENT OR REPAIR AT A GLOBAL LIFT CORP'S FACILITY OR A DULY APPOINTED DISTRIBUTOR'S LOCATION OR AT A GLOBAL LIFT CORP'S DESIGNATED LOCATION.
- Page 11 PRO-RATED EXTENDED WARANTY Year 3: 50% Coverage (Customer is responsible for 50% of the replacement cost) Year 4: 30% Coverage (Customer is responsible for 70% of the replacement cost) ***THIS IS THE EXCLUSIVE WRITTEN EXTENDED WARRANTY OF THE ORIGINAL WARRANTY PURCHASER AND ALL STANDARD WARRANTY TERMS &...
- Page 12 Signature: ______________________________________ Date: ______________ This card must be completed and returned to Global Lift Corp within 30 days of purchase date to assure coverage. Please mail to: Global Lift Corp, 684 N Port Crescent Suite C, Bad Axe, MI 48413...
