TEW‐825DAP TRENDnet User’s Guide Features Product Overview Equip your business with a manageable and cost‐effective AC1750 wireless network with TRENDnet’s AC1750 Dual Band PoE+ Access Point, model TEW‐ 825DAP. Broadcast concurrent 1300 Mbps WiFi AC and 450 Mbps WiFi N networks. Relieve congestion and overcrowding on the 2.4GHz band by employing band steer technology. Power the access point with the included AC adapter, or connect via PoE+ for installation flexibility. The low‐profile design blends into most environments and includes a convenient ceiling/wall mounting plate. Multi‐Language Multi‐Language Interface: English, Spanish, French, German, and Russian Power over Ethernet (PoE) Saves installation time and costs with Gigabit PoE support TEW‐825DAP Concurrent Dual Band AC1750: concurrent 1300 Mbps WiFi AC + 450 Mbps WiFi N bands Package Contents Multi‐Mode Support In addition to your router, the package includes: Supports Access Point (AP), Client, WDS+AP, WDS Bridge, WDS Station, TEW‐825DAP and Repeater modes ...
TEW‐825DAP TRENDnet User’s Guide Band Steering Product Hardware Features Band steering alleviates network congestion by automatically directing wireless devices from the 2.4 GHz band to the 5 GHz band Top View WiFi Traffic Shaping Off white low profile housing Manage traffic allocation per SSID for each band separately Multiple SSIDs Create up to 8 SSIDs per band (16 total) IPv6 IPv6 network support Housing Design Off‐white low‐profile design LED Control Reduce product visibility by disabling LED indicators Mounting Plate Included ceiling/wall mounting plate for flexible installation *Maximum wireless signal rates are referenced from IEEE 802.11 theoretical 5GHz 2.4GHz ...
TEW‐825DAP TRENDnet User’s Guide Front View Application Diagram Reset button Gigabit Port Power port Gigabit port: Plug an Ethernet cable (also called network cables) from The access point provides concurrent 1300 Mbps and WiFi AC and 450 Mbps WiFi N combined your access point to your router and wired network devices with AP, Client, WDS and Repeater modes support multiple applications. Power port: Connect the power adapter from your access point power port to an available power outlet. Reset button: Use a sharp tool to press and hold this button for 10 seconds to Connect wireless devices to your access point ...
TEW‐825DAP TRENDnet User’s Guide Mounting device Getting Started For a typical wireless setup at home or office when using the access point in AP mode, 1. Remove the mount plate from the access point. please do the following: Installation 1. Connect the power adapter to the power port of the access point. Or simply plug an Ethernet cable on the access point to a PoE (Power over Ethernet) switch that connects to your router or network. 2. If using the power adapter, plug an Ethernet cable to the access point and plug the other end to your router or network. 3. Verify that all LEDs are on. 2. Place the mounting plate on the wall or ceiling where the device will be located and 4. For your security, each TEW‐825DAP comes pre‐encrypted with a unique WiFi Name mark the location of the screw holes. Ensure that the device has enough clearance to (SSID) and WiFi Password. You can find your device's SSID and WiFi password on the slide on and off the mounting plate. white labels located on the device. Use this information to connect to the TEW‐ 825DAP access point. 3. Drill out the marked holes and insert the plastic wall anchors in to the wall. 4. Secure the mounting plate using the screws that came with the device. ...
TEW‐825DAP TRENDnet User’s Guide 5. Place the access point on the mounting plate and slide to lock into position. Steps to improve wireless connectivity There are a number of factors that can impact the range of wireless devices. Follow these tips to help improve your wireless connectivity: 1. Keep the number of obstructions to a minimum. Each obstruction can reduce the range of a wireless device. Position the wireless devices in a manner that will minimize the amount of obstructions between them. a. For the widest coverage area, install your router near the center of your home, and near the ceiling, if possible. b. Avoid placing the access point on or near metal objects (such as file cabinets and metal furniture), reflective surfaces (such as glass or mirrors), and masonry walls. c. Any obstruction can weaken the wireless signal (even non‐metallic objects), so the fewer obstructions between the router and the wireless device, the better. d. Place the access point in a location away from other electronics, motors, and fluorescent lighting. e. Many environmental variables can affect the router’s performance, so if your ...
Page 9
TEW‐825DAP TRENDnet User’s Guide Connect wireless devices to your access point Configuration A variety of wireless network devices can connect to your wireless network such as: Note: The access point’s default management page http://192.168.10.100 is accessed Gaming Consoles through the use of your Internet web browser (e.g. Internet Explorer, Firefox, Chrome, Internet enabled TVs Safari, and Opera) and will be referenced frequently in this User’s Guide. Network media players Before accessing the web‐based management page, configure the IP address and Smart Phones subnet mask of your computer to the following: Wireless Laptop computers IP Address: 192.168.10.xxx Wireless IP cameras Subnet Mask: 255.255.255.0 Each device may have its own software utility for searching and connecting to available wireless networks, therefore, you must refer to the User’s Manual/Guide of your 1. Open your web browser (e.g. Internet Explorer, Firefox, Safari, Chrome, or Opera) and ...
Page 11
TEW‐825DAP TRENDnet User’s Guide System Name: Assign name of the device to help distinguish between similar 4. Select the access point you want to configure. devices VLAN ID: Assigns the VLAN ID for the Ethernet port. Band Steer: Select this to enable/disable band steering Band: Select on the pull‐down menu the wireless interface to configure 802.11 Mode: Select the 802.11 mode of the selected wireless interface Channel: Select the wireless channel of the selected wireless interface VLAN ID: Assigns the VLAN ID for the primary SSID. Separate Stations: Select this option to restrict wireless client devices from accessing other client devices connected to this network(s). Enable: Select this option to enable the selected wireless interface Visible: Select this option to wireless broadcast the selected wireless interface SSID: Enter the SSID (Wireless Network Name) of the selected wireless interface ...
Page 12
TEW‐825DAP TRENDnet User’s Guide Note: WPA2 encryption supports 802.11n speeds and WPA encryption will limit Wireless Networking and Security your connection speeds to 54Mbps WPA2: This is the most secure wireless encryption available today, similar to WPA encryption but more robust. This encryption standard also supports the highest How to choose the type of security for your wireless network connection speeds. TRENDnet recommends setting your router to this encryption Setting up wireless security is very important. Leaving your wireless network open and standard. If you find that one of your wireless network devices does not support unsecure could expose your entire network and personal files to outsiders. TRENDnet WPA2 encryption, then set your router to either WPA or WPA‐Auto encryption. recommends reading through this entire section and setting up wireless security on your Note: Check the specifications of your wireless network adapters and wireless new access point. appliances to verify the highest level of encryption supported. Below is brief There are a few different wireless security types supported in wireless networking each comparison chart of the wireless security types and the recommended having its own characteristics which may be more suitable for your wireless network configuration depending on which type you choose for your wireless network. taking into consideration compatibility, performance, as well as the security strength along with using older wireless networking hardware (also called legacy hardware). It is strongly recommended to enable wireless security to prevent unwanted users from Security Standard WEP ...
Page 13
TEW‐825DAP TRENDnet User’s Guide 5. Select from the drop‐down list to the wireless security to configure. Secure your wireless network Wireless (2.4GHz or 5GHz)> Security After you have determined which security type to use for your wireless network (see “How to choose the security type for your wireless network” on page 12), you can set up wireless security. 1. Log into your router management page (see “Access the management page” on page 16). 2. Click on the Wireless network you want to configure button (Wireless 2.4GHz or 5GHz). 6. Review the wireless security settings, click Apply and Save/Reload when finished. Selecting WEP‐OPEN, WEP‐SHARED: If selecting WEP (Wired Equivalent Privacy), please review the WEP settings to configure and click Apply to save the changes. Note: WPS functionality is not available when using WEP. WEP Key Format HEX ...
Page 14
TEW‐825DAP TRENDnet User’s Guide o This is where you enter the WEP key needed for a computer to connect to the Note: It is recommended to use the default interval time. Your passphrase will not router wirelessly change; rotation of the key is part of the WPA protocol and designed to increase o You can define up to 4 passwords or 4 keys. Only one key can be active at a given security. time. Most users simply define one key. o Choose a key index 1, 2, 3, or 4 and enter the key. Selecting WPA‐Enterprise, WPA2‐Enterprise, or WPA2‐Enterprise Mixed: o When connecting to the access point, the client must match both the password and the Key number. (e.g. if you have activated Key 2 with a password of 12345, then the client must select: Key 2 (entering Key 1, 3, or 4 will block the ability to connect) and enter password 12345) Note: It is recommended to use 128‐bit format because it is more secure to use a key that consists of more characters. HEX or ASCII: Select which WEP code type to assign Selecting WPA‐ Personal, WPA2‐ Personal, WPA2‐ Personal, or Mixed (WPA2‐PSK recommended): In the Security Mode drop‐down list, select WPA‐ Personal ...
Page 15
TEW‐825DAP TRENDnet User’s Guide Connect wireless devices using WPS 3. Click on WPS to configure the selected wireless band’s WPS feature. Click Apply to save settings WPS (Wi‐Fi Protected Setup) is a feature that makes it easy to connect devices to your wireless network. If your wireless devices support WPS, you can use this feature to easily add wireless devices to your network. Note: You will not be able to use WPS if you set the SSID Broadcast setting to Disabled or 4. Review the WPS settings, click Save/Reload when finished. if you are using WEP security. There are two methods the WPS feature can easily connect your wireless devices to your network. Push Button Configuration (PBC) method WPS Config o WPS Software/Virtual Push Button ‐ located in router management page PIN (Personal Identification Number) Method ‐ located in router management page Note: Refer to your wireless device documentation for details on the operation of WPS. ...
Page 16
TEW‐825DAP TRENDnet User’s Guide WPS Security Mode: Display the security mode of the WPS network Advance configuration WPS Key: Displays the security password Access the management page AP PIN: Display the WPS PIN information. WPS Action Note: Your router management page URL/domain name http://TEW‐825DAP or IP address http://192.168.10.100 is accessed through the use of your Internet web browser (e.g. Internet Explorer, Firefox, Chrome, Safari, Opera) and will be referenced frequently in this User’s Guide. 1. Open your web browser (e.g. Internet Explorer, Firefox, Safari, Chrome, or Opera) and go to URL/domain name http://TEW‐825DAP or IP address http://192.168.10.100. PIN: Enter the PIN information of the wireless client you want to connect to the Your router will prompt you for a user name and password. network. Click Start PIN button to activate WPS once you enter the client’s PIN information Note: You may need to initiate the WPS PIN on your wireless device first when using this method. Refer to your wireless device documentation for details on the operation of WPS. ...
Page 17
TEW‐825DAP TRENDnet User’s Guide 3. Enter your Username and Password, select your preferred language, and then click Login. Operating Modes This section outlines the available operating modes available on the access point. 1. Log into your management page (see “Access the management page” on page 16). Access Point: In this mode, the device creates a wireless network to your existing 2. Click on System and Operation Mode. network. Client Bridge: Select this mode to allow the access point the ability to wireless connect to your wireless network. This is similar to a wireless laptop or mobile device connecting to a wireless network. WDS Access Point: In the mode, the access point connects to other WDS bridge enable devices for backbone communication and provides wireless connection to clients (STAs) at the same time. ...
Page 18
TEW‐825DAP TRENDnet User’s Guide Repeater: In this mode, the wireless interface repeats wireless signal and packets for backbone communication as well as a client access. This feature is used to expand your existing wireless network to areas that your current access point is unable to reach. Make sure all of the settings of the wireless interface matches to your root or connecting wireless access points, same SSID, channel and wireless encryption settings. Access Point 4. Click on Save/Reload button located on the top left section to apply settings. Wireless Mode: If all of the wireless devices you want to connect with this Access Point can connect in the same transmission mode, you can improve performance slightly by choosing the appropriate mode. If you have some devices that use a Basic different transmission mode, choose the appropriate mode. Wireless (2.4GHz or 5GHz) > Wireless Network 2.4GHz Wireless o B/G/N mixed: Select this mode for the best compatibility. This mode allows older This section outlines the available features to configure for both wireless 2.4Ghz and 802.11b and 802.11g wireless devices to connect to the access point in addition ...
Page 19
TEW‐825DAP TRENDnet User’s Guide Frequency (Channel): In North America, this router can broadcast on 1 of 11 o A only: This mode only allows devices to connect to the access point using older and slower 802.11a technology (typically not recommended). Channels for 2.4GHz (13 in Europe and other countries). Selecting the Auto option o A/N mixed: This mode only allows devices to connect to the access point using enables the router to automatically select the best Channel for wireless older and slower 802.11a or 802.11n technology and it thereby reduces the communication. To manually set the channel on which the router will broadcast, access point’s maximum speed to 54Mbps (typically not recommended). click the drop‐down list and select the desired Channel for wireless communication. o N only: This mode only allows newer 802.11n devices to connect to your access The goal is to select the Channel that is least used by neighboring wireless point. This mode does ensure the highest speed and security for your network, networks. however, if you have older 802.11a wireless clients, they will no longer be able to connect to this router. Wireless Profile o N/AC mixed: Select this mode for the best compatibility. This mode allows older Wireless (2.4GHz or 5GHz) > Wireless Network 802.11a wireless devices to connect to the access point in addition to newer 802.11ac devices. ...
Page 20
TEW‐825DAP TRENDnet User’s Guide Filter Mode: Select from the pull‐down list the MAC filter rule to apply. o Disable: Select to turn off MAC filter feature SSID: Enter the wireless network name (SSID) to assign to the selected wireless o DENY: Select this option to DENY all listed MAC addressed profile o ALLOW: Select this option to only ALLOW the listed MAC address to the network. Hide SSID: Select option to disable the wireless network name to broadcast MAC Address: Enter the MAC address to apply on the MAC filter rule Separate Stations: Select this option to restrict wireless client devices from accessing other client devices connected to this network(s). MAC Filter List ...
Page 21
TEW‐825DAP TRENDnet User’s Guide 2. Click on System, and select Operation Mode. 6. Configure the below settings and click Apply and Save/Reload to save settings. 3. Enable Client Bridge, under the wireless band (2.4GHz or 5GHz) you would like to Wireless Mode: Select the wireless mode to set on the selected wireless band in connect this access point to. Please make sure that the selected band is available on client bridge mode your network. SSID: Manually enter the wireless network name (SSID) you want to establish connection. Or simply click on Site Survey to scan for available wireless network. Preferred BSSID: Click option and enter the preferred wireless network you would like to connect to. Security Mode: Select from the pull‐down menu the wireless security that is used on the wireless network you would like to connect to. Scan for wireless networks ...
Page 22
TEW‐825DAP TRENDnet User’s Guide WDS 3. Under SSID section click Scan to wireless scan for available wireless networks. WDS Link 4. Click on the wireless network you would like to connect. The information will Wireless (2.4GHz or 5GHz) > WDS Link Settings automatically fill on the previous screen. You will then need to select and enter the This section outlines the available features to configure for both wireless 2.4Ghz and wireless security. 5GHz when WDS mode is selected. 1. Log into your management page (see “Access the management page” on page 16). 2. Click on System, and select Operation Mode. 3. Enable WDS Access Point, under the wireless band (2.4GHz or 5GHz) you would like to connect this access point to. Please make sure that the selected band is available on your network. 5. Click on Apply button to apply the settings and then click on the Save/Reload button located on the top left section to save the settings. ...
Page 23
TEW‐825DAP TRENDnet User’s Guide 4. Click on the wireless band you would like to configure and click WDS Link Settings. Basic Wireless (2.4GHz or 5GHz) > Wireless Network This section outlines the available features to configure for both wireless 2.4Ghz and 5GHz when Access Point mode is selected. 1. Log into your management page (see “Access the management page” on page 16). 2. Click on System, and select Operation Mode. 5. Configure the below settings and click Apply to save settings. Insert operation mode menu image 3. Enable WDS Access Point, under the wireless band (2.4GHz or 5GHz) you would like to connect this access point to. Please make sure that the selected band is available on your network. Insert Operation mode image 4. Click on the wireless band you would like to configure and click Wireless Network. Site Survey: Click this option to scan for available WDS networks Remote AP MAC: Enter the MAC address of the remote access point you want to establish WDS connection. ...
Page 24
TEW‐825DAP TRENDnet User’s Guide o B/G/N mixed: Select this mode for the best compatibility. This mode allows older unsure, it is recommended that you keep the default setting (B/G/N mixed) for the 802.11b and 802.11g wireless devices to connect to the access point in addition best compatibility. to newer 802.11n devices. When applying the 802.11 mode setting, please keep in mind the following: Wireless devices that support 802.11n are backwards compatible and can o B/G mixed: This mode only allows devices to connect to the access point using older and slow 802.11b or 802.11g technology and it thereby reduces the access connect wirelessly at 802.11g or 802.11b. Connecting at 802.11b or 802.11g will limit the capability of your 802.11n point’s maximum speed to 54Mbps (typically not recommended). o N only: This mode only allows newer 802.11n devices to connect to your access supported wireless devices from obtaining higher performance and data rates. Allowing 802.11b or 802.11g devices to connect to an 802.11n capable wireless point. This mode does ensure the highest speed and security for your network, however if you have older 802.11g wireless clients, they will no longer be able to network may degrade the wireless network performance below the higher connect to this access point. performance and data rates of 802.11n. Wireless devices that only support 802.11b or 802.11g will not be able to ...
Page 25
TEW‐825DAP TRENDnet User’s Guide Repeater 3. Underneath the basic wireless band section, you will see Wireless Network and all your wireless network profiles will be listed. 4. Click on the Edit button next to the wireless profile you want to configure. Basic Wireless (2.4GHz or 5GHz) > Wireless Network This section outlines the available features to configure for both wireless 2.4GHz and 5GHz when Repeater mode is selected. 5. Review the wireless settings, click Apply when finished. 1. Log into your management page (see “Access the management page” on page 16). 2. Click on System, and select Operation Mode. SSID: Enter the wireless network name (SSID) to assign to the selected wireless profile Hide SSID: Select option to disable the wireless network name to broadcast 6. Click on Save/Reload button located on the top left section to apply settings. ...
Page 26
TEW‐825DAP TRENDnet User’s Guide Security Mode: Select from the pull‐down menu the wireless security that is used on the wireless network you would like to connect to. 6. Click on the Save/Reload button located on the top left section to save the settings. 4. Click on the wireless band (Wireless 2.4GHz / Wireless 5GHz) you would like to configure and click Wireless Network. Scan for wireless networks Wireless (2.4GHz or 5GHz) > Wireless Network This section outlines the available features to configure for both wireless 2.4Ghz and 5GHz when Repeater mode is selected. 5. Configure the below settings and click Apply to save settings. 1. Log into your management page (see “Access the management page” on page 16). 2. Click on the wireless band you would like to configure and click Wireless Network. ...
Page 27
TEW‐825DAP TRENDnet User’s Guide 3. Review the settings and click Apply to save settings. Advanced Wireless 4. Click on the wireless network you would like to repeat. The information will automatically fill on the previous screen. You will then need to select and enter the wireless security. Data Rate: Select the operating wireless data rate. Transmit Power: The wireless transmit power can be modified to lower the antenna strength setting from 18 dBm to 11 dBm, if necessary. Lowering the wireless transmit power may help to better stabilize the wireless connectivity and reduce the effects of wireless interference in areas where there are several 2.4GHz wireless devices. (Default: 18 dBm) RTS/CTS Threshold: The Request To Send (RTS) function is part of the networking 5. Click on Apply button to apply the settings and then click on the Save/Reload button located on the top left section to save the settings. protocol. A wireless device that needs to send data will send a RTS before sending the data in question. The destination wireless device will send a response called ...
TEW‐825DAP TRENDnet User’s Guide broadcast and multicast messages. The default value is 1. Valid settings are 3. Select enable to turn on band steering feature and click Apply to save settings. between 1 and 255. HT Physical Mode 4. Click on Save button to apply the settings and then click on the Save/Reload button located on the top left section to save the settings. To enable band steering, you have to setup steering SSID the same in both 2.4GHz and 5GHz Guard Interval: Select to enable short guard interval (400ns). ‐MPDU: MPDU aggregation also collects Ethernet frames to be transmitted to a single destination, but it wraps each frame in an 802.11n MAC header. Normally this is less efficient than MSDU aggregation, but it may be more efficient in IPv6 Settings environments to maintain performance in noisy networks and to prevent hidden System > IPv6 Settings nodes from degrading the performance. ...
TEW‐825DAP TRENDnet User’s Guide Local Connection Only Static IPv6 Static IPv6 are static IP addresses that are usually provided by your Internet Service Provider (ISP). 1. Review the Static IPv6 settings below. 2. Select either Obtain IPv6 DNS server address automatically or Use the following IPv6 DNS Servers. Obtain IPv6 DNS server address automatically: Selecting this option will allow the access point to automatically search for the DNS server address that is provided by your Internet Service Provider (ISP) Use the following IPv6 DNS Servers: Selecting this option enables you to manually input the Primary and Secondary DNS Servers Change your IP address LAN IPv6 Address: Enter the IPv6 IP address provided to you by your Internet Service Provider (ISP) System > IP Settings In most cases, you do not need to change the IP address settings. Typically, the IP ...
TEW‐825DAP TRENDnet User’s Guide Connection Type: Select on the pull‐down menu the LAN connection type. o DHCP: Select this option to have the access point obtain an IP address from your DHCP server o STATIC: Select this option to manually assign and IP address to your access point 3. Click on Enable to enable Captive Portal. DNS Server: Enter your network’s DNS server IP address 4. Select which SSID you wish to enable Captive Portal on. 4. Click on Apply button to apply the settings and then click on the Save/Reload button located on the top left section to save the settings. Captive Portal System > Captive Portal Captive Portal is a web page that enables users connecting to public‐access WiFi to view and interact with the web page before giving users access to the network. Captive Portal are typically used in public spaces such as hotel lobbies, airports, coffee shops and other ...
TEW‐825DAP TRENDnet User’s Guide Create schedules Configure Spanning Tree Maintenance > Schedule 1. Log into your management page (see “Access the management page” on page 16). 2. Click on the System tab and click Spanning Tree Settings. Create a schedule to define the days/time period when a feature should be active or 3. Review the settings and click Apply to save changes. inactive: 1. Log into your management page (see “Access the management page” on page 16). 2. Click on the Management tab and click Schedule. 3. Select from the pull‐down menu under Wireless Schedule to enable wireless schedules. Spanning Tree Status: Select On or Off to enable or disable spanning tree feature. Bridge Hello Time: Enter the bridge duration Bridge Max Age: Enter the max duration 3. Review the settings and click Add to save settings. Bridge Forward Delay: Enter the delay duration ...
TEW‐825DAP TRENDnet User’s Guide Set date and time Management > Time and Date Settings There are two ways to set the access point’s date and time. NTP (Network Time Protocol) is based on time servers. You can also manually set the router’s date and time. Note: It is important that the time is configured correctly before setting any schedules. Enable: Check option to enable NTP feature 1. Log into your management page (see “Access the management page” on page 16). NTP Server: Select the NTP server to use NTP synchronization: Enter the time of when the access point will continue to 2. Click on the Management tab and click Time and Date Settings. check for NTP updates. 3. Next to Time Zone, click the drop‐down list to select your time zone. 2. Click on Apply button to apply the settings and then click on the Save/Reload button located on the top left section to save the settings. ...
TEW‐825DAP TRENDnet User’s Guide 3. Review the settings for both 2.4G and 5G profiles and click Apply to save settings. 3. Review the settings for both wireless bands (2.4GHz and 5GHz) and click Apply to save settings. Enable: Check box of the selected SSID to enable VLAN feature VID: Enter the VID to assign on the selected wireless network SSID: Displays the available SSID WiFi Security: Displays the wireless security type of the wireless network Enable: Check box to enable traffic shaping of the selected wireless band Incoming Traffic: Enter your network’s inbound traffic limit Outgoing Traffic Limit: Enter your network’s outbound traffic limit for the selected wireless band ...
TEW‐825DAP TRENDnet User’s Guide 3. Review the settings and click Apply to save settings. Enable CLI Management > CLI Settings CLI (Command Line Interface) is a user interface where commands can be sent to the access point in the form of successive lines of text (command lines). 1. Log into your management page (see “Access the management page” on page 16). 2. Click on the Management tab and click CLI Settings. 3. Select ON and click Apply to save settings. 4. Click on Apply button to apply the settings and then click on the Save/Reload button located on the top left section to save the settings. SNMP: Select enable to enable SNMP feature Contact: Enter the contact person or contact information for your access point. ...
TEW‐825DAP TRENDnet User’s Guide 2.4GHz LED: Select On to leave wireless 2.4GHz LED on or Off option to turn off. 5GHz LED: Select On to leave wireless 5GHz LED on or Off option to turn off. 4. Click on Apply button to apply the settings and then click on the Save/Reload button located on the top left section to save the settings. Maintenance & Monitoring Account: Change the login user name in this field Password: Change the login password in this field Administration Idle Timeout: Change the length of time that the access point can idle before Management > Administration timing out. The duration can be between 120 – 3600 seconds. (By default it is set to 120 seconds) You may want to change your login credentials for logging into your access point. Resetting the access point to factory default settings will also reset the login credentials ...
TEW‐825DAP TRENDnet User’s Guide 4. Depending on your web browser settings, you may be prompted to save a file (specify Reset to factory defaults the location) or the file may be downloaded automatically to the web browser Management > Backup/Restore Settings settings default download folder. (Default Filename: config.bin) You may want to reset the access point to factory defaults if you are encountering 5. Save the configuration file to location on your computer. difficulties and have attempted all other troubleshooting. Before you reset to defaults, if possible, you should backup your access point’s configuration first. To restore your configuration: 1. Log into your management page (see “Access the management page” on page 16). There are two methods that can be used to reset your access point to factory defaults. 2. Click on the Management tab and click Backup/Restore Settings. 3. Under Import Settings, depending on your web browser, click on Browse or Choose Reset Button: Located on the front panel of your router, (see “Product Hardware File. A separate file navigation window should open. Features” on page 5). Use this method if you are encountering difficulties with accessing your router management page. OR Access Point Management Page 1. Log into your management page (see “Access the management page” on page 16). 2. Click on the Management tab and click Backup/Restore Settings. ...
TEW‐825DAP TRENDnet User’s Guide Router Management Page: This is also known as a soft reboot or restart. Any interruptions during the firmware upgrade process may permanently damage your router. 1. Log into your management page (see “Access the management page” on page 16). 1. Log into your router management page (see “Access your router management page” 2. Click on the Management tab and click Backup/Restore Settings. on page 16). 3. Click Reboot under System Reboot to restart the access point. If prompted, click yes Note: You can check your router’s current firmware version at the top right of the or OK. page. 2. Click on Management, and click on Upload Firmware. 3. Depending on your web browser, next to Upgrade Firmware, click Browse or Choose File. Upgrade your firmware Management > Upload Firmware TRENDnet may periodically release firmware upgrades that may add features or fix 4. Navigate to the folder on your computer where the unzipped firmware file (.bin) is ...
TEW‐825DAP TRENDnet User’s Guide System Test connectivity Management > Diagnostics Ping Test 1. Log into your management page (see “Access the management page” on page 16). 2. Click on the Management tab and click Diagnostic. Device Name: Displays the assigned device name Firmware Version: Displays the firmware version currently loaded on the router System Time: Displays the current time of the device System Up Time: Displays the time duration of how long the device has been running IP: Enter the IP address you would like to conduct the ping test Network Packet Length: Enter the packet size Number of Pings: Enter the amount of pings to conduct. ...
TEW‐825DAP TRENDnet User’s Guide Kick and Ban: Clicking this option will allow you to kick the client from the network and ban them as well System Log Status > System Log System log keeps track of changes made to the access point. 1. Log into your management page (see “Access the management page” on page 16). 2. Click on the Status tab and click System Log. Operation Mode: Displays the current operating mode for each wireless band Wireless Mode: Displays the wireless mode set on each wireless band Channel Width: Displays the applied channel width Frequency (Channel): Displays the current operating wireless channel Tx/Rx Packets: Displays the Transmit (Tx) and Receive (Rx) packet rate SSID List: Displays the multiple SSID settings. Check connected wireless clients ...
TEW‐825DAP TRENDnet User’s Guide 4. Select the access point you want to configure. AP utility Installation 1. Insert the CD ROM included with the access point. 2. Click on AP Utility to install the utility. 5. Click on Device settings to configure the access point. Device Settings 3. Once the utility is installed click on Discover to refresh the list of access points. Product Name: Displays the device model IP Mode: Select the IP mode to apply on the device ...
TEW‐825DAP TRENDnet User’s Guide o DHCP: Select this option to allow the device to receive IP address from your 3. Enter the IP address of the device you would like to add to the controller and press DHCP server OK. o Static: Select this option to manually set the IP address of the device IP Address: Enter the IP address to assign to the device Subnet Mask: Enter the subnet mask to assign to the device Gateway: Enter the gateway IP address to assign to the device System Name: Assign name of the device to help distinguish between similar devices VLAN ID: Assigns the VLAN ID for the Ethernet port. Band Steer: Select this to enable/disable band steering Band: Select on the pull‐down menu the wireless interface to configure 802.11 Mode: Select the 802.11 mode of the selected wireless interface Delete device ...
TEW‐825DAP TRENDnet User’s Guide 3. Enter the login password of the devices and click Upgrade to start the firmware IP Address: Displays the IP address of the access points on the network upgrade process. Model Name: Displays the model number of the access points connected on the network Firmware Version: Displays the current firmware version of the access points connected on the network Access Points Status: Displays the current status of the access points connected on the network 1. To view access points that are currently connected to your network, click on the SSID: Displays the SSID (Wireless Network Name) of the access points connected on the Access Points tab. network Channel: Displays the current channel that the access point is on Total Clients: Displays the number of clients (devices) that is currently connected to the access point Upload/Download: Displays the amount of data that the access point has sent and received Clients ...
TEW‐825DAP TRENDnet User’s Guide Statistics 1. To view statistical data about your access point, click on the Statistics tab. 2. Review the statistics information below. MAC: Displays the MAC address that is connected to the access point WLAN (SSID): Displays the SSID (wireless network name) of the access point the device is connected to Access Point: Displays the wireless MAC address of the access points on the network that the device is connected to Signal strength (dBm): Displays the signal strength between the access point and the client. ie: ‐40 is a stronger signal than ‐50. Uptime: Displays the duration the client has been connected to the access point ...
Page 45
TEW‐825DAP TRENDnet User’s Guide over the chart to view a current break‐down of the total number of clients connected to the selected SSID. Clients by AP: Displays number of clients and traffic per access point. Most Active Device: Displays the access point with the most activity in comparison between other access points on the network. Most Active SSID: Displays the SSID (wireless network name) with the most amount of activity. Clients (Total): Shows the number of clients currently connected onto the access point. The unit of measurement (time) can be configured to show the number of devices connected in the last 5 minutes, hours, or days Traffic (MBytes): This displays the amount of throughput (upload, download, all) that has been passed. This can be configured to display only upload, download, or all. ...
TEW‐825DAP TRENDnet User’s Guide Q: I am not sure what type of Internet Account Type I have for my Cable/DSL Troubleshooting connection. How do I find out? Answer: Q: I typed http://192.168.10.1 in my Internet Browser Address Bar, but an error Contact your Internet Service Provider (ISP) for the correct information. message says “The page cannot be displayed.” How can I access the access point management page? Q: The Wizard does not appear when I access the access point. What should I do? Answer: Answer: 1. Check your hardware settings again. See “Getting Started” on page 7. 1. Click on Wizard on the left‐hand side. 2. Make sure the LAN and WLAN lights are lit. 2. Near the top of the browser, “Pop‐up blocked” message may appear. Right click on 3. Make sure your network adapter TCP/IP settings are set to Obtain an IP address the message and select Always Allow Pop‐ups from This Site. automatically or DHCP (see the steps below). 3. Disable your browser's pop up blocker. 4. Make sure your computer is connected to one of the router’s LAN ports 5. Press on the factory reset button for 15 seconds, the release. Q: I went through the Wizard, but I cannot get onto the Internet. What should I do? Windows 10/8.1/8/7 Answer: ...
TEW‐825DAP TRENDnet User’s Guide Note: If you are experiencing difficulties, please contact your computer or operating Appendix system manufacturer for assistance. How to find your IP address? Note: Please note that although the following procedures provided to follow for your How to configure your network settings to obtain an IP address automatically or use operating system on configuring your network settings can be used as general DHCP? guidelines, however, it is strongly recommended that you consult your computer or Note: Please note that although the following procedures provided to follow for your operating system manufacturer directly for assistance on the proper procedure for operating system on configuring your network settings can be used as general configuring network settings. guidelines, however, it is strongly recommended that you consult your computer or operating system manufacturer directly for assistance on the proper procedure for Command Prompt Method configuring network settings. Windows 2000/XP/Vista/7/8/8.1/10 Windows 7 and up 1. On your keyboard, press Windows Logo + R keys simultaneously to bring up the Run dialog box. a. Go into the Control Panel, click Network and Sharing Center. 2. In the dialog box, type cmd to bring up the command prompt. b. Click Change Adapter Settings, right‐click the Local Area Connection icon. ...
Page 50
TEW‐825DAP TRENDnet User’s Guide In MAC 10.4, from the Configure IPv4, drop‐down list, select Using DHCP and How to connect to a wireless network using the built‐in Windows utility? click the Apply Now button. Note: Please note that although the following procedures provided to follow for your In MAC 10.5, from the Configure drop‐down list, select Using DHCP and click operating system on configuring your network settings can be used as general the Apply button. guidelines, however, it is strongly recommended that you consult your computer or In MAC 10.6, from the Configure drop‐down list, select Using DHCP and click operating system manufacturer directly for assistance on the proper procedure for the Apply button. connecting to a wireless network using the built‐in utility. f. Restart your computer. Windows 7/8/8.1/10 Note: If you are experiencing difficulties, please contact your computer or operating 1. Open Connect to a Network by clicking the network icon ( or ) in the notification system manufacturer for assistance. area. 2. In the list of available wireless networks, click the wireless network you would like to How to find your MAC address? connect to, then click Connect. In Windows 2000/XP/Vista/7/8/8.1/10, ...
Page 51
TEW‐825DAP TRENDnet User’s Guide Federal Communication Commission Interference Statement Europe – EU Declaration of Conformity This equipment has been tested and found to comply with the limits for a Class B digital TRENDnet hereby declare that the product is in compliance with the essential requirements device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable and other relevant provisions under our sole responsibility. protection against harmful interference in a residential installation. This equipment ...
Page 52
TEW‐825DAP TRENDnet User’s Guide 2014/35/EU, 2004/108/EB, 1999/5/EB, 2009/125/EB, en 2011/65/EU. TRENDnet tímto prohlašuje, že tento TEW‐825DAP je ve shodě se základními Česky [Czech] požadavky a dalšími příslušnými ustanoveními směrnice 2014/35/EU, Hawnhekk, TRENDnet, jiddikjara li dan TEW‐825DAP jikkonforma mal‐ħtiġijiet Malti [Maltese] 2004/108/ES, 1999/5/ES, 2009/125/ES, a 2011/65/EU. essenzjali u ma provvedimenti oħrajn relevanti li hemm fid‐Dirrettiva 2014/35/EU, 2004/108/KE, 1999/5/KE, 2009/ , u 2011/65/EU. Undertegnede TRENDnet erklærer herved, at følgende udstyr TEW‐825DAP Dansk [Danish] overholder de væsentlige krav og øvrige relevante krav i direktiv 2014/35/EU, Alulírott, TRENDnet nyilatkozom, hogy a TEW‐825DAPmegfelel a vonatkozó Magyar 2004/108/EF, 1999/5/EF, 2009/125/EF, og 2011/65/EU. alapvetõ követelményeknek és az 2014/35/EU, 2004/108/KE, 1999/5/KE, [Hungarian] 2009/125/KE, irányelv és a 2011/65/EU irányelv egyéb elõírásainak. Hiermit erklärt TRENDnet, dass sich das Gerät TEW‐825DAP in Deutsch [German] Übereinstimmung mit den grundlegenden Anforderungen und den übrigen Niniejszym TRENDnet oświadcza, że TEW‐825DAP jest zgodny z zasadniczymi Polski [Polish] einschlägigen Bestimmungen der Richtlinie 2014/35/EU, 2004/108/EG, wymogami oraz pozostałymi stosownymi postanowieniami Dyrektywy 1999/5/EG, 2009/125/EG, und 2011/65/EU befindet. ...
Page 53
Limited Warranty TRENDnet User’s Guide In the event that, after evaluation, TRENDnet cannot replace the defective product or Limited Warranty there is no comparable model available, we will refund the depreciated value of the TRENDnet warrants only to the original purchaser of this product from a TRENDnet product. authorized reseller or distributor that this product will be free from defects in material and workmanship under normal use and service. This limited warranty is non‐ If a product does not operate as warranted during the applicable warranty period, transferable and does not apply to any purchaser who bought the product from a TRENDnet shall reserve the right, at its expense, to repair or replace the defective reseller or distributor not authorized by TRENDnet, including but not limited to product or part and deliver an equivalent product or part to the customer. The purchases from Internet auction sites. repair/replacement unit's warranty continues from the original date of purchase. All products that are replaced become the property of TRENDnet. Replacement products Limited Warranty may be new or reconditioned. TRENDnet does not issue refunds or credit. Please contact the point‐of‐purchase for their return policies. TRENDnet warrants its products against defects in material and workmanship, under normal use and service. Specific warranty periods are listed on each of the respective product pages on the TRENDnet website. TRENDnet shall not be responsible for any software, firmware, information, or memory data of customer contained in, stored on, or integrated with any products returned to ...
Page 54
Limited Warranty TRENDnet User’s Guide shipping from outside of the USA and Canada are responsible for any return shipping CONTRACT OR TORT (INCLUDING NEGLIGENCE), FOR INCIDENTAL, CONSEQUENTIAL, and/or customs charges, including but not limited to, duty, tax, and other fees. INDIRECT, SPECIAL, OR PUNITIVE DAMAGES OF ANY KIND, OR FOR LOSS OF REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF INFORMATION OR DATE, OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN CONNECTION WITH THE SALE, INSTALLATION, Refurbished product: Refurbished products carry a 90‐day warranty after date of MAINTENANCE, USE, PERFORMANCE, FAILURE, OR INTERRUPTION OF THE POSSIBILITY purchase. Please retain the dated sales receipt with purchase price clearly visible as OF SUCH DAMAGES, AND LIMITS ITS LIABILITY TO REPAIR, REPLACEMENT, OR REFUND evidence of the original purchaser's date of purchase. Replacement products may be OF THE PURCHASE PRICE PAID, AT TRENDNET'S OPTION. THIS DISCLAIMER OF LIABILITY refurbished or contain refurbished materials. If TRENDnet, by its sole determination, is FOR DAMAGES WILL NOT BE AFFECTED IF ANY REMEDY PROVIDED HEREIN SHALL FAIL unable to replace the defective product, we will offer a refund for the depreciated value OF ITS ESSENTIAL PURPOSE. of the product. Governing Law: This Limited Warranty shall be governed by the laws of the state of WARRANTIES EXCLUSIVE: IF THE TRENDNET PRODUCT DOES NOT OPERATE AS California. WARRANTED ABOVE, THE CUSTOMER'S SOLE REMEDY SHALL BE, AT TRENDNET'S OPTION, REPAIR OR REPLACE. THE FOREGOING WARRANTIES AND REMEDIES ARE EXCLUSIVE AND ARE IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED, ...
