Summary of Contents for TRENDnet TEW-821DAP
- Page 1 Quick Installation Guide TEW-821DAP (V1)
- Page 2 Table of Content 1 English 1. Before You Start 2. Initial Access Point Setup 3. AP Management Utility 4. Mounting the Device...
-
Page 3: Before You Start
1. Before You Start Package Contents TEW-821DAP Ÿ 1 x 5 ft. (1.5 m) network cable Ÿ CD-ROM (User's Guide and Utility) Ÿ Quick Installation Guide Ÿ Power adapter (12V DC, 1A) Ÿ Mounting Plate Ÿ Minimum Requirements Computer with network port and web browser Ÿ... - Page 4 WiFi Password. You can find your device's SSID and WiFi password on the white labels located on the device. Use this information to connect to the TEW-821DAP access point. If the TEW-821DAP is reset, the SSID and WiFi key will also be reset to the default login credentials located on the white label.
- Page 5 3. AP Management Utility 1. Insert the included CD into your computer, and select AP Utility from the menu. Note: The AP Utility only supports Windows based computers. Please visit TRENDnet.com for complete list of the AP Utility’s supported operating systems.
- Page 6 3. Select your device by checking the box next to your TEW-821DAP, and click on Device Settings. Static 4. The Device Settings page will show your basic Wi-Fi network settings. If your network requires a static IP address, select the Static radio button and enter your settings. If you are not sure, leave IP Mode on the default setting, DHCP.
- Page 7 TEW-821DAP. Band 6. When you are finished, enter the password for your TEW-821DAP (NOT your WiFi password) and click OK to save your changes. If this is the first time you are accessing the device, or if the unit has been reset, the default password is admin.
- Page 8 9. To access the unit's advanced settings, launch the AP Utility, locate your TEW-821DAP, click on the IP Address, and select Yes to configure your device. 192.168.10.62 10. This will launch your default web browser, and automatically direct it to your TEW-821DAP for advanced settings.
- Page 9 13. The status screen will display information about your TEW-821DAP access point, and the unit's wireless networks. 14. For detailed information on advanced settings and features, please refer to the User's Guide.
- Page 10 4. Secure the mounting plate, using the screws that came with the device. 5. Place the TEW-821DAP on the mounting plate, and attach the network cable. If you are using a non-PoE router or switch and require external power, connect the power adapter.
- Page 11 N300 PoE Access Point Trade Name: TRENDnet TRENDnet hereby declare that the product is in compliance with the essential requirements and other relevant provisions under our sole responsibility. Safety EN 60950-1: 2006 + A11: 2009: + A1: 2010 + A12: 2011 + A2: 2013 EN 301 489-1 V1.9.2: 09-2011...
- Page 12 Product Warranty Registration If you have any questions regarding the product Please take a moment to register your installation, please contact our Technical Support. product online. Go to TRENDnet’s website at: www.trendnet.com/register Toll free US/Canada: 1-855-373-4741 Regional phone numbers available at www.trendnet.com/support...
