Altronix VertiLine48MV Series Installation Manual page 3

Fig. 1
PTC1
Used
on PTC
Power LEDs
models
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user
to the presence of an insulated DANGEROUS VOLTAGE within the product's enclosure that may be of
sufficient magnitude to constitute an electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of impor-
tant operating and maintenance (servicing) instructions in the literature accompanying the appliance.
VertiLine48MV Series Installation Guide
Fig. 1a
Removable
Terminal
Block
Power Supply
Power LEDs Power LEDs Power LEDs
CAUTION: To reduce the risk of electric shock do not open enclosure.
There are no user serviceable parts inside.
Refer servicing to qualified service personnel.
Fig. 1b
Strain Relief
Line Cord
Power Supply
Green Wire
Earth GND
Fig. 1c
Illuminated
Power Disconnect
Circuit Breaker with
manual reset
- 3 -
