DE18DBNGR/LPR and DE24DBNGR/LPR
REMOTE CONTROL GAS LOG
VENTED DECORATIVE APPLIANCE
Convertible from Natural Gas to Propane/LP Gas
OWNER'S OPERATION AND INSTALLATION MANUAL
WARNING: If the information in this manual is not
followed exactly, a fire or explosion may result causing
property damage, personal injury or loss of life.
— Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Immediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire
department.
— Installation and service must be performed by a quali-
fied installer, service agency or the gas supplier.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
Tested &
Listed By
Vented Decorative Appliances
for installation in Solid Fuel
Burning Fireplaces
Advertisement
Table of Contents
Related Manuals for EmberGlow DE18DBNGR/LPR
Summary of Contents for EmberGlow DE18DBNGR/LPR
- Page 1 Tested & Listed By Vented Decorative Appliances for installation in Solid Fuel Burning Fireplaces DE18DBNGR/LPR and DE24DBNGR/LPR REMOTE CONTROL GAS LOG VENTED DECORATIVE APPLIANCE Convertible from Natural Gas to Propane/LP Gas OWNER'S OPERATION AND INSTALLATION MANUAL WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing...
-
Page 2: Table Of Contents
Safety ............... 2-3 Cleaning and Maintenance ........12 Service Hints ............. Product Identification ........... 3 Local Codes ............4 Technical Service ..........Unpacking ............4 Troubleshooting ...........12-13 Product Features ..........4 Replacement Parts ........14-15 Installation .. -
Page 3: Safety
SAFETY Continued 5. You must operate this log set with fireplace screens 11. Do not run log set: in place and fully closed. Unless provided by other • where combustible materials, gasoline and other means, fireplace doors or screens shall haveopen- flammable vapors and liquids are used or stored ings for introduction of combustion air. -
Page 4: Local Codes
LOCAL CODES UNPACKING Install and use log set with care. Follow all local CAUTION: Do not remove the metal data plates from the codes. In the absence of local codes, use the burner pan. The data plates contain important warranty latest edition of The National Fuel Gas Code ANSI- and safety information. - Page 5 INSTALLATION Continued CHECK GAS TYPE The charts in Figure 2 indicate technical inform- ation regarding the installation of your gas log set. Use only natural gas. If your gas supply is not nat- Please make sure that all of the specifications ural gas, you must convert the appliance to propane shown are applicable before installation is attempt- /LP.
- Page 6 INSTALLATION Continued We recommend that you install a sediment trap in 4. Check all joints of gas supply piping system. Apply a noncorrosive leak detection fluid to all the supply line as shown in Figure 4. Locate sediment trap where it is within reach for cleaning. Install in piping joints.
- Page 7 INSTALLATION Continued Be sure to use the correct orifice for your app- Retighten and adjust the location of the gas control as necessary. The gas control liance. The orifice kit included with this appli- ance contains an orifice installed in an air should be level, with the control knob to the mixer fitting.
- Page 8 INSTALLATION Continued 5. Turn pressure selecting screw over and reinstall it in regulator cap (see Figure 10-11).This will set the pressure selecting screw to the LP/Propane gas ition. Makethe pressure selecting screw is installed tightly to the regulator cap. 6. Replace the regulator cap on the appliance regulator. Figure 10 - Removing Regulator Cap from Pressure Selecting Screw Pressure...
- Page 9 Proper Log Placement for Vented Gas Log Models DE18DBNGR/LPR AND DE24DBNGR/LPR Log #1 Log Stand-Offs Log #2 Log #3 Log #4 Log #5 Log #6 Log #7 Complete With Embers If you have any questions, please call (800) 229-5647...
-
Page 10: Operation
OPERATION FOR YOUR SAFETY LIGHTING INSTRUCTION READ BEFORE LIGHTING 1. STOP! Read the safety information on the WARNING: Keep flue open when operating unit. left side of this page. 2. Make sure equipment shutoff valve is fully WARNING: If you do not follow these instruct- open. -
Page 11: Inspecting Burners
LIGHTING INSTRUCTION This is a normal and temporary situation that is not Continued cause for alarm. However, you may want to provide extra ventilation to the room during this time. 9. Slightly push in and turn control knob counterclockwise to the ON position. Hand Held Remote 10.To leave pilot lit and shut off burners only:... -
Page 12: Cleaning And Maintenance
CLEANING AND MAINTENANCE SERVICE HINTS When Gas Pressure is Too Low • Keep the area around the log set clean and clear of debris. • pilot will not stay lit • Occasionally, you may use a soft bristle brush to •... -
Page 13: Troubleshooting
TROUBLESHOOTING Continued OBSERVED PROBLEM POSSIBLE CAUSE REMEDY 1. Pilot flame needs adjust - Delayed ignition burner. 1. Adjust pilot flame for ap - proximately 2" blue flame. ing. 2. Wrong pilot orifice for gas 2. Replace pilot orifice. type. Remote does not function. Battery is not installed. -
Page 14: Replacement Parts
DE18,24DBNG(LP) PARTS LP Conversion... - Page 15 DE18,24DBNG(LP) PARTS Continued KEY NO. PART NO. DESCRIPTION QTY. SBNCJ00365A Burner Pan RCOCB00002A Burner Tube RMH-120-00085B Orifice Holder, Natural Gas RMH-120-90955 Orifice, Natural Gas RMH-120-00084B Orifice, Propane/LP Gas RMH-120-00324 Orifice, Propane/LP Gas RCODZ00145A Washer RMH-120-00574 Pal Nut RMH-120-00069 Elbow, “Street” 3/8”NPT Valve, Remote “ON/OFF”...
- Page 16 LIMITED WARRANTY Sure Heat Mfg. warrants that the components of this appliance are warranted free from defects in material and workmanship for one (1) year from the date of purchase. Sure Heat Mfg. at its option, will repair or replace this product, or any component of the product found to be defective during the warranty period .
