E-commerce-Enitial Lab
YNJ-17907C2
Tools Required for Assembly
ASSEMBLY RATING
The Assembly Rating is a 5-point
system that shows the degree of effort
needed in assembling a specific
Phillips Screwdriver
product (with 1 being easy and 5 being
difficult). For most products, two
(Not Included)
persons are recommended.
EASY
DIFFICULT
2 PERSON RECOMMENDED
18.01.25
Page 1
Advertisement
Table of Contents
Related Manuals for Furniture of America YNJ-17907C2
Summary of Contents for Furniture of America YNJ-17907C2
- Page 1 E-commerce-Enitial Lab ASSEMBLY INSTRUCTIONS YNJ-17907C2 Tools Required for Assembly ASSEMBLY RATING The Assembly Rating is a 5-point system that shows the degree of effort needed in assembling a specific Phillips Screwdriver product (with 1 being easy and 5 being difficult). For most products, two (Not Included) persons are recommended.
- Page 2 Thank you for your purchase! We hope you will enjoy your new product for many years to come. Our commitment to providing quality products does not simply end when a purchase is made. We stand behind our products and will provide any support needed in order for you to fully enjoy your purchase.
- Page 3 Page 3...
- Page 4 PRE-ASSEMBLY INTRODUCTION Unless you are particularly adept at assembling flat-pack/knock-down furniture, we understand building ready-to-assemble furniture can be a frustrating experience for some. To help avoid confusion and to make the assembly process quicker and smoother, we have provided some helpful tips.
- Page 5 END TABLE ASSEMBLY INSTRUCTIONS MODEL # YNJ-17907C2 Please keep for future reference PARTS LIST Before you begin, please read "Assembly and Care Advice","Pre- Assembly Introduction" and "Cam Lock Fastener Assembly Instructions" DIMENSIONS 20.16" (W) X19.29" (D) X19.96" (H) 2PCS 2PCS...
- Page 6 ASSEMBLY INSTRUCTIONS STEP1 Hardware #3=8pcs Use a dab of glue in dowel holes before inserting dowels (#3). STEP2 Hardware #1=6pcs Hardware #2=12pcs Align panels (#A) to the holes of panel (#B), then align brackets (#1) to the holes of panels (#A) and panels (#B). Secure by using screws (#2). Page 6...
- Page 7 ASSEMBLY INSTRUCTIONS STEP3 Hardware #1=6pcs Hardware #2=12pcs Hardware #4=4pcs Hardware #5=4pcs Align panel (#B) to the holes of panels (#A), then align brackets (#1) to the holes of panels (#A) and panel (#B). Secure by using screws (#2). Align floor protectors (#4) to the holes of panels (#B), then secure by using screws (#5).
