ASSEMBLY INSTRUCTIONS
ASSEMBLY RATING
The Assembly Rating is a 5-point
system that shows the degree of effort
needed in assembling a specific
product (with 1 being easy and 5 being
difficult). For most products, two
persons are recommended.
EASY
YNJ-16913C5-84TV
DIFFICULT
Page 1
E-commerce-Enitial Lab
Tools Required for Assembly
Allen Wrench
Phillips Screwdriver
2 PERSON RECOMMENDED
(Included)
(Not Included)
17.09.25
Advertisement
Related Manuals for Furniture of America YNJ-16913C5-84TV
Summary of Contents for Furniture of America YNJ-16913C5-84TV
- Page 1 E-commerce-Enitial Lab ASSEMBLY INSTRUCTIONS YNJ-16913C5-84TV Tools Required for Assembly ASSEMBLY RATING The Assembly Rating is a 5-point system that shows the degree of effort Allen Wrench needed in assembling a specific (Included) product (with 1 being easy and 5 being difficult).
- Page 2 Thank you for your purchase! We hope you will enjoy your new product for many years to come. Our commitment to providing quality products does not simply end when a purchase is made. We stand behind our products and will provide any support needed in order for you to fully enjoy your purchase.
- Page 3 Page 3...
- Page 4 PRE-ASSEMBLY INTRODUCTION Unless you are particularly adept at assembling flat-pack/knock-down furniture, we understand building ready-to-assemble furniture can be a frustrating experience for some. To help avoid confusion and to make the assembly process quicker and smoother, we have provided some helpful tips.
- Page 5 CAM LOCK FASTENER ASSEMBLY INSTRUCTIONS Page 5...
-
Page 6: Parts List
TV STAND ASSEMBLY INSTRUCTIONS MODEL # YNJ-16913C5-84TV Please keep for future reference PARTS LIST Before you begin, please read "Assembly and Care Advice","Pre- Assembly Introduction" and "Cam Lock Fastener Assembly Instructions" DIMENSIONS 82.68" (W) X15.75" (D) X21.85" (H) 2PCS 4PCS... - Page 7 ASSEMBLY INSTRUCTIONS STEP1 Use a small dab of glue on wood Hardware #1=2pcs dowel hole, then insert wood Hardware #3=22pcs dowel (#3) to the same hole. Hardware #7=4sets Hardware #10=4pcs Hardware #11=4pcs Hardware #12=4pcs Hardware #13=16pcs 0.39" 0.47" Flip 180° right Use smaller screws (#11).
- Page 8 ASSEMBLY INSTRUCTIONS STEP2 Hardware #1=4pcs Hardware #2=4pcs Hardware #3=2pcs Hardware #4=4pcs Hardware #12=1pc Hardware #13=4pcs Please refer to page 5 on how to fasten cam locks. Page 8...
- Page 9 ASSEMBLY INSTRUCTIONS STEP3 Hardware #1=8pcs Hardware #2=8pcs Hardware #5=4pcs Hardware #8=2pcs Hardware #9=4pcs Panel (#F) mirrors panel (#E). Finished Page 9...
- Page 10 ASSEMBLY INSTRUCTIONS STEP4 Hardware #2=2pcs Hardware #5=6pcs Page 10...
- Page 11 ASSEMBLY INSTRUCTIONS STEP5 Hardware #5=8pcs Hardware #14=8pcs Page 11...
- Page 12 ASSEMBLY INSTRUCTIONS STEP6 Hardware #6=2pcs Hardware #15=8pcs Hardware #16=8pcs Insert and attach doors(#K) on both sides of the coffee table. right Extend the two outer slides of the runners so that they could align with the sides of the drawer. Make sure the pre-drilled holes from the drawer align with the screw holes of the outer slides.
