E-commerce-Enitial Lab
ASSEMBLY INSTRUCTIONS
YNJ-15409
Tools Required for Assembly
ASSEMBLY RATING
The Assembly Rating is a 5-point
system that shows the degree of effort
needed in assembling a specific
Phillips Screwdriver
product (with 1 being easy and 5 being
(Not Included)
difficult). For most products, two
persons are recommended.
EASY
DIFFICULT
2 PERSON RECOMMENDED
16.04.18
Page 1
Advertisement
Related Manuals for Furniture of America YNJ-15409
Summary of Contents for Furniture of America YNJ-15409
- Page 1 E-commerce-Enitial Lab ASSEMBLY INSTRUCTIONS YNJ-15409 Tools Required for Assembly ASSEMBLY RATING The Assembly Rating is a 5-point system that shows the degree of effort needed in assembling a specific Phillips Screwdriver product (with 1 being easy and 5 being (Not Included) difficult).
- Page 2 Thank you for your purchase! We hope you will enjoy your new product for many years to come. Our commitment to providing quality products does not simply end when a purchase is made. We stand behind our products and will provide any support needed in order for you to fully enjoy your purchase.
- Page 3 Page 3...
- Page 4 PRE-ASSEMBLY INTRODUCTION Unless you are particularly adept at assembling flat-pack/knock-down furniture, we understand building ready-to-assemble furniture can be a frustrating experience for some. To help avoid confusion and to make the assembly process quicker and smoother, we have provided some helpful tips.
- Page 5 CAM LOCK FASTENER ASSEMBLY INSTRUCTIONS Page 5...
-
Page 6: End Table
END TABLE ASSEMBLY INSTRUCTIONS MODEL # YNJ-15409 Please keep for future reference PARTS LIST Before you begin, please read "Assembly and Care Advice","Pre- Assembly Introduction" and "Cam Lock Fastener Assembly Instructions" DIMENSIONS 19.69" (W) X19.69" (D) X22.84" (H) 2PCS 2PCS... - Page 7 ASSEMBLY INSTRUCTIONS STEP1 Hardware #1=4pcs Hardware #2=4pcs Hardware #3=4pcs STEP2 Hardware #1=12pcs Hardware #2=6pcs Hardware #3=4pcs Page 7...
- Page 8 ASSEMBLY INSTRUCTIONS STEP3 Hardware #2=6pcs Hardware #3=8pcs Page 8...
- Page 9 ASSEMBLY INSTRUCTIONS STEP4 Hardware #4=6pcs STEP5 Hardware #1=4pcs Hardware #2=4pcs Hardware #4=2pcs Page 9...
- Page 10 ASSEMBLY INSTRUCTIONS STEP6 STEP7 Hardware #1=2pcs Hardware #2=2pcs Hardware #3=2pcs Hardware #4=4pcs Hardware #5=1pc Hardware #6=1pc Page 10...
- Page 11 ASSEMBLY INSTRUCTIONS STEP8 Hardware #7=4pcs Hardware #8=4pcs Hardware #9=2pcs Extend the two outer slides of the runners so that they could align with the sides of the drawer. Make sure the pre-drilled holes from the drawer align with the screw holes of the outer slides. Secure two screws from the inside of the drawer using a Phillips screwdriver to tighten them to the outer slides.
