SOLUS-310R
EXTRACTOR
120V
INFORMATION
&
OPERATING
INSTRUCTIONS
DO NOT OPERATE MACHINE UNTIL YOU HAVE READ
ALL SECTIONS OF THIS INSTRUCTIONS
IMPROPER USE OF THE MACHINE WILL VOID THE WARRANTY
1. Always use a defoamer when foaming occurs to prevent vacuum motor damage.
2. Keep machine from rain and snow, extremes in temperatures, and store in a
heated location. DO NOT let the machine or wand freeze. Use the machine indoors.
3. Do not let the pump run dry.
4. Use approved chemicals only. NO SOLVENTS.
5. Wear gloves or use rags when removing quick disconnects to prevent burns.
6. Never use water above 130 ºF/54 ºC in the solution tank.
1
05.20.2008
Advertisement
Table of Contents
Related Manuals for U.S. Products SOLUS-310R
Summary of Contents for U.S. Products SOLUS-310R
- Page 1 SOLUS-310R EXTRACTOR 120V INFORMATION & OPERATING INSTRUCTIONS DO NOT OPERATE MACHINE UNTIL YOU HAVE READ ALL SECTIONS OF THIS INSTRUCTIONS IMPROPER USE OF THE MACHINE WILL VOID THE WARRANTY 1. Always use a defoamer when foaming occurs to prevent vacuum motor damage.
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS This machine is only suitable for commercial use, for example in hotels, schools, hospitals, factories, shops and offices other than normal residential housekeeping purposes. When using any electrical appliance, basic precautions should always be followed, including the following: NOTE: Read all instructions before using this machine. -
Page 3: Cleaning Solutions
INSPECTION: Carefully unpack and inspect your SOLUS-310R for shipping damage. Each machine is tested and inspected before shipping. Any shipping damage incurred is the responsibility of the carrier. You should notify the carrier immediately if you notice damage to the box or to the machine or... -
Page 4: Know Your Machine
KNOW YOUR MACHINE VACUUM LID - This lid provides access into your recovery tank so that you can clean the tank. The lid must be closed before you try to clean.. SOLUTION TANK FILL HOLE - This is where you fill the tank with water and cleaning solution. VACUUM HOSE BARB - This is where you connect your vacuum hose to the machine. -
Page 5: Switch Plate
SWITCH PLATE HEAT RECIRCULATION SWITCH (1): This switch will energize a solenoid that will pump heated water back into the holding tank in order to pre-heat the cleaning solution -- up to 125 °F. NOTE: this switch must be turned off to prime the pump or to begin the cleaning operation. - Page 6 SET-UP: 1. Fill the holding tank with clear water and prespray with the detergent of your choice (we recommend a CRI approved chemical). Mix well. Although this machine is designed to supply instant hot water, the addition of warm water o the holding tank would increase heater efficiency. Never use water above 130º F/54º C in the solution tank.
- Page 7 (18) Heat Recirculation Hose Pump Inlet Hose Pump to Bypass Heater Hose Hose Heater to Outlet Hose SOLUS-310R Pump to 05.20.2008 Gauge Hose...
- Page 8 SOLUS-310R EXTRACTOR PART LIST 120V ITEM PART No DESCRIPTION ITEM PART No. DESCRIPTION FP311A Switch, SPST, with cover 2095 Solenoid, high temp. FP312 Switch, SPDT,with cover FP336 PCB mounting track, 4” Light, red Hose Clamp Light, green 923B Dual Cord Sensor PCB...
- Page 9 TROUBLE SHOOTING: IF THIS OCCURS CHECK THIS Solution tank is empty. NO SPRAY Clogged spray tip. Pump not running or not primed. Valve on wand not operating. Check the brushes in the pump motor. Replace if necessary. PUMP DOES NOT RUN No power to pump.
- Page 10 SOLUS-310R NOTES: 208-772-0573 800-257-7982 FAX: 208-772-0577 • • Coeur d’Alene, Idaho VISIT US AT: http://www.usproducts.com...
