U.S. Products COBRA PLUS-150 Information & Operating Instructions

Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual
COBRA PLUS-150
IMPROPER USE OF THE MACHINE WILL VOID THE WARRANTY
1. Always use a defoamer when foaming occurs to prevent vacuum motor damage.
2. Keep machine from rain and snow, extremes in temperatures, and store in a
heated location. Use the machine indoors only.
3. Do not let pump run dry.
4. Use approved chemicals only. NO SOLVENTS.
5. Wear gloves or use rags when removing quick disconnects to prevent burns.
6. Never use water over 130 °F/ 54 °C in the machine.
EXTRACTOR
120V
DO NOT OPERATE MACHINE UNTIL YOU HAVE READ
ALL SECTIONS OF THE INSTRUCTIONS
INFORMATION
&
OPERATING
INSTRUCTIONS
08.07.2007

Advertisement

loading

Related Manuals for U.S. Products COBRA PLUS-150

Summary of Contents for U.S. Products COBRA PLUS-150

  • Page 1 COBRA PLUS-150 EXTRACTOR 120V INFORMATION & OPERATING INSTRUCTIONS DO NOT OPERATE MACHINE UNTIL YOU HAVE READ ALL SECTIONS OF THE INSTRUCTIONS IMPROPER USE OF THE MACHINE WILL VOID THE WARRANTY 1. Always use a defoamer when foaming occurs to prevent vacuum motor damage.

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS This machine is only suitable for commercial use, for example in hotels, schools, hospitals, factories, shops and offices other than normal residential housekeeping purposes. When using any electrical appliance, basic precautions should always be followed, including the following: NOTE: Read all instructions before using this machine.

  • Page 3: Maintenance

    INSPECTION: Carefully unpack and inspect your COBRA PLUS-150 for shipping damage. Each machine is tested and inspected before shipping. Any shipping damage incurred is the responsibility of the carrier. You should notify the carrier immediately if you notice damage to the box or to the machine or parts.
  • Page 4 When this light is illuminated, it confirms that the machine is on two separate circuits VACUUM (4), VACUUM (5), AND PUMP (6) SWITCHES: These switches are all powered by cord #1. Switches are on when illuminated. COBRA PLUS-150 Dump Hose Switch...
  • Page 5 OPERATION Inspect the machine, hoses, and cleaning tools for cleanliness and completeness. Fill the solution tank with water. Using warm water may be a benefit in cleaning effectiveness, but do not use hot water (above 130 F/54 C) in the tank. °...
  • Page 7 COBRA PLUS-150 120V PART LIST ITEM PART No. DESCRIPTION ITEM PART No. DESCRIPTION BKCR-BLK Base, CP, black, 1060B Hose, dump Louver, 3” CWKC-BLK Cord wrap 908A Latch FP345 Switch, SPST 2014 Fan, 100CFM, cooling VKCR-1 Tank, vacuum, white 2015 Guard, fan Light, green, 120V Hose, pump inlet, 1/2”...

  • Page 8: Troubleshooting

    TROUBLE SHOOTING: CP-150 ALWAYS UNPLUG THE MACHINE BEFORE DISCONNECTING OR CONNECTING ANY WIRES OR COMPONENTS IF THIS OCCURS CHECK THIS NO SPRAY Solution tank is empty. Clogged spray tip. Pump not running. Valve on wand not operating PUMP DOES NOT RUN No power to pump.
