Before assembling your telescope, visit the Meade LX85 resources page to access instructional videos, manuals, quick start guides
and download our AutoStar® Suite Planetarium Software.
LX85 Mount Overview
Open the tripod, extend the legs,
STEP
and adjust height as needed. Orient
1
North Peg to face north.
STEP
Install Latitude and Azimuth Adjust-
ment knobs.
4
Adjust to local latitude using Altitude
STEP
Adjustment and Lock Knobs
5
Looking at or near the Sun will cause irreversible damage to your eye. Do not point this telescope at or near the Sun.
Meade® LX85™ Quickstart Guide
https://www.meade.com/content/lx85-support-resources
STEP
Assemble Accessory Tray as shown.
2
Attach the Counterweight Shaft and
STEP
Counterweight(s).
6
ACF Optical Tube Overview
Reflector Optical Tube Overview
STEP
Attach the LX85 mount to the tripod.
3
Install the Optical Tube and secure
STEP
with 2 locking knobs.
7
SCAN ME
