- Page 1 Instructions manual / XS-38D XS-38D SERVICE MANUAL...
- Page 2 Instructions manual / XS-38D The tool delivered with this manual may have been modified for specific needs. In that case, please give us the tool code number written on our shipping note or the approximate tool delivery date when you place an order for a new similar tool or for spare parts.
-
Page 3: Table Of Contents
8. Soft start and Double hit………………………………………………………………………………….. p.7 9. Over Current Protection (Overload), over heat protection and reset………………………………… p.8 10. Connections………………………………………………………………………………………………. p.9 11. Interface with XS-38D controller……………………………………………………………………….. p.10 11.1 Connector and cables………………………………………………………………………………….. p.10 11.2 Input/Output signals interface…………………………………………………………………………. p.10 11.3 Timing chart of start / Stop signal…………………………………………………………………….. p.10... -
Page 4: General Safety Rules
Instructions manual / XS-38D 1. General safety rules WARNING ! Read and understand all instructions. Failure to follow all instructions listed below, may result in electric shock, fire and/or serious personal injury. SAVE THESE INSTRUCTIONS 1.1 Work Area - Keep your work area clean and well lit. Cluttered benches and dark areas invite accidents. -
Page 5: Tool Use And Care
Instructions manual / XS-38D 1.4 Tool use and Care - Use clamps or other practical way to secure and support the workplace to a stable platform. Holding the work by hand or against your body is unstable and may lead to loss of control. -
Page 6: Electrical Specification
Instructions manual / XS-38D 3. Electric specification Model XS-38D Ver. 4.0 Input 110 / 230 VAC (selectable) Output 20/30, 30/38 VDC (selectable) Rated power 2.5 A 95W Maximum output current Intermittent operation 10s On / 30s Off Safety system CE certified (Class I) 4. -
Page 7: Selectable Output
Instructions manual / XS-38D 7. Selectable OUTPUT 8. Soft start and Double hit Push Function LED light sT Button Standard Green Soft Start during 0.2 sec. Yellow Blink once Soft Start during 0.3 sec. Yellow Blink twice Soft Start during 0.5 sec. -
Page 8: Over Current Protection (Overload), Over Heat Protection And Reset
Instructions manual / XS-38D 9. Over Current Protection (Overload), Over heat protection and reset Description Primary OCP Secondary OCP Limit current 12-13A Condition ‘’A’’ Condition ‘’B’’ Detection Immediately 3 sec 0,5 sec Time duration Whole power shut Protection Output power disappear for 5 sec. -
Page 9: Connections
Instructions manual / XS-38D 10. Connections... -
Page 10: Interface With Xs-38D Controller
Instructions manual / XS-38D 11. Interface with XS-38D controller 11.1 Connector and cables 11.2 Input/Output signals interface 11.3 Timing chart of Start / Stop signal... -
Page 11: Interface Converter (Option)
Instructions manual / XS-38D 11.4 Interface converter (Option) Interface converter converts the electronic signal by opto coupler to opposite direction as below. Also it provides additional dry contact signals in both Normal Closed and Normal Open by the built-in relay.
