Philips CEM2000/00 Quick Start Manual

Register your product and get support at
EN Quick Start Guide
1
a b c
e f g
2 3
4 5
B
A
CEM2000
6
Overview of parts 1
d These are the supplied parts needed to connect
and install this unit.
a In-car audio system
b Sleeve
c Front panel
d Standard ISO connector
h
e Trim plate
f Rubber cushion
g Disassembly tools
h Screws (4 pieces)
Select country/region
1
Press to turn on the unit.
2
Rotate to select an option:
• [USA] (United States)
• [Latin] (Latin America)
• [Europe] (Western Europe)
• [ASIA] (Asia Pacific)
• [Mid-East ] (Middle East)
• [Russia] (Russia)
3
Press to confirm.
Connection
Caution
Ensure that all loose leads are insulated with
•
electrical tape.
For cars with ISO connectors
1
Pull out the ISO connectors from car dash-
a a a
b board and connect them to the bigger end
c
d
of the supplied standard connector.
a
b
b b
c
d
2
Connect the other end of the supplied stan-
dard connector to the unit.
e
c c
f
3
Connect the antenna and amplifier as il-
g
h
lustrated, if applicable. You can connect the
d
d
car audio to the amplifier through RCA-TO-
RCA cables (not supplied).
Connector Connect to
1 ANTENNA Antenna
2 FRONT LINE Front right speaker
OUT R (Socket)
3 FRONT LINE Front left speaker
OUT L (Socket)
4 REAR LINE Rear right speaker
OUT R (Socket)
5 REAR LINE Rear left speaker
OUT L (Socket)
6 SUBWOOFER Subwoofer
For cars with ISO connectors
4 5
Caution
• Be sure to connect the black ground (earth)
lead first.
1
Connect the antenna and amplifier as illus-
trated, if applicable.
2
Cut off the bigger end of the supplied stan-
dard connector.
3
Check the car's wiring carefully and connect
them to the supplied standard connector.
4
Connect the supplied standard connector to
the unit.
1 Green/black strip Left speaker (Rear)
2 White/black strip Left speaker (Front)
3 Gray/black strip Right speaker (Front)
234
4 Purple/black strip Right speaker (Rear)
e RED Ignition key +12V DC when
ON/ACC
f BLUE Motor/electric antenna relay
control lead/Amplifier relay
control lead
g BLACK Ground
h YELLOW To the +12V car battery
which is energized at all times
5
Mount in the dashboard 6
Turn
6
Press
1
If the car does not have an on-board drive or
navigation computer, disconnect the negative
terminal of the car battery.
View clock
• If you disconnect the car battery in a car
that has an on-board drive or navigation 1
Press and hold OPTIONS repeatedly until
computer, the computer may lose its
the clock is displayed.
memory.
• If the car battery is not disconnected,
Listen to radio
to avoid short-circuit, ensure that bare
wires do not touch each other.
1
Press SOURCE repeatedly to select Tuner.
2
Remove the two screws on the top of the 2
Press
unit.
[FM3], [AM1], or [AM2] .
3
Remove the mounting sleeve with the sup- 3
Press
plied disassembly tools.
manually.
4
Install the sleeve into the dashboard and • The radio station is broadcast.
bend the tabs outward to fix the sleeve.
• To search for a radio station automati-
5 cally, press
Place the supplied rubber cushion over the
end of the mounting bolt.
6
Slide the unit into the dashboard until you
hear a click sound.
7
Reconnect the negative terminal of the car
battery.
Attach the front panel 6
1
Attach the trim plate.
2
Insert the right side of the panel in the chas-
sis until it is correctly engaged.
3
Press the left side of the panel until the
mechanism locks it into place.
Turn on
1
Press to turn on the unit.
• To turn off the unit, press for over 3
seconds.
Set clock
1
Press MENU.
2
Press or repeatedly until currently time
is displayed.
3
Turn clockwise to set hour.
4
Press to confirm.
anti-clockwise to set minute.
to confirm.
or to select band: [FM1], [FM2],
or to tune to a radio station
or for over 3 seconds.
