85cm
Imported by Amart Furniture Pty Ltd, Qld, Brisbane Australia.
For any assistance with assembly or for missing parts please phone
Amart Furniture, Customer Service Free call 1800 351 084
ASSEMBLY INSTRUCTION
CASSIUS 3SEATER CHAISE
ITEM CODE 70812
Imported by Amart Furniture Pty Ltd, Qld, Brisbane Australia.
For any assistance with assembly or for missing parts please phone
Amart Furniture, Customer Service Free call 1800 351 084
326cm
Depth: 185cm
1
70812
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Amart Furniture CASSIUS 70812
Summary of Contents for Amart Furniture CASSIUS 70812
- Page 1 ASSEMBLY INSTRUCTION CASSIUS 3SEATER CHAISE ITEM CODE 70812 Imported by Amart Furniture Pty Ltd, Qld, Brisbane Australia. For any assistance with assembly or for missing parts please phone Amart Furniture, Customer Service Free call 1800 351 084 326cm 85cm Depth: 185cm Imported by Amart Furniture Pty Ltd, Qld, Brisbane Australia. For any assistance with assembly or for missing parts please phone Amart Furniture, Customer Service Free call 1800 351 084 70812...
-
Page 2: Pre-Assembly Preparation
PRE‐ASSEMBLY PREPARATION Before you start: Choose a clean, level, spacious assembly area. Avoid hard surfaces that may damage the product Take care when lifting. Product should be assembled as near as possible to the point of use Ensure that you have all required contents for complete assembly Always read the assembly instructions carefully before beginning assembly. - Page 3 Step1: Locate package of recliner power cord and arm table kit which are fixed on the mechanism at the bottom of left hand facing recliner. With 2 people carefully turn onto back on piece of cardboard or carpet to protect covering Recliner Power Cord Arm table kit Recliner power cord 1pcs Arm Table Lid Arm Table Bracket Allen key Bolt M6X16 1pcs 1pcs 1pcs 4pcs Step2: Install the arm table lid on the table bracket with four bolts by Allen key. clockwise turning the Allen key for tighten of the bolts 70812...
- Page 4 Step3: Attach the table bracket to the base inside left or right arm pocket according to demand. Base inside arm pocket Step4: Plug recliner power cord into the socket at the back panel of left hand facing recliner. SAFETY NOTE: PLEASE ENSURE THAT ALL ELECTRICAL CORDS AND CABLES ARE CLEAR OF THE FRAME AND MECHANISM. A FAILURE TO DO SO MAY SEVER YOUR POWER CORD RESULTING IN SERIOUS INJURY OR DEATH. 70812...
- Page 5 Step5: Locate packages of sound power cord and reading light that are placed into zipper pocket at the bottom console. With 2 people carefully turn onto back on piece of cardboard or carpet to protect covering Sound Power Cord Reading Light 1pcs 1pcs Step6: Attach the reading light to the base inside back cover, then connect the cord of reading light with cord inside back cover. Button Switch Reading light at the front of Cord of reading light light bar Cord inside back cover Base inside back cover 70812...
- Page 6 Step7: Plug sound power cord into the socket at the back panel of console. SAFETY NOTE: PLEASE ENSURE THAT ALL ELECTRICAL CORDS AND CABLES ARE CLEAR OF THE FRAME AND MECHANISM. A FAILURE TO DO SO MAY SEVER YOUR POWER CORD RESULTING IN SERIOUS INJURY OR DEATH. Step8: Locate package of sofa feet that is placed into zipper pocket at the bottom of right hand facing chaise. With 2 people carefully turn onto back on piece of cardboard or carpet to protect covering Bolt M8X60 Washer Support foot Side foot 5pcs 1pcs 5pcs 5pcs 70812...
- Page 7 Step9: Take out 5 side feet, then use cross screwdriver to fasten the feet to the holes at bottom of the chaise with bolts and washers. Arm Side Step10: Take out the support foot and then screw into the hole in the middle at armless side of the chaise. Armless Side Arm Side clockwise turning for tighten of support foot with screw 70812...
- Page 8 Step11: Connect 4 pieces from right to left. Begin with RHF chaise, then connect pieces on demand until final item of LHF electric recliner. Left Right 4th PCS 1st PCS slide clips at connecting item into clips at connected item, then together press front and rear side of connecting item to ensure the clips go into each other to the bottom. Step12: Connect the cords of light strip between every piece. SAFETY NOTE: PLEASE ENSURE THAT ALL ELECTRICAL CORDS AND CABLES ARE CLEAR OF THE FRAME AND MECHANISM. A FAILURE TO DO SO MAY SEVER YOUR POWER CORD RESULTING IN SERIOUS INJURY OR DEATH. 70812...
- Page 9 70812...
- Page 10 70812...
