Humminbird
NMEA 2000
Installation and Operation

Advertisement

loading
Need help?

Need help?

Do you have a question about the NMEA 2000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Humminbird NMEA 2000

Summary of Contents for Humminbird NMEA 2000

  • Page 1 All manuals and user guides at all-guides.com Humminbird NMEA 2000 Installation and Operation...
  • Page 2 All manuals and user guides at all-guides.com NMEA 2000 - References Install Guide PN 531951-1A Manual PN 531989-1A contains contains 4 pages of installation 40 pages of installation and setup and connection information and is guidance and is included with the...
  • Page 3 All manuals and user guides at all-guides.com NMEA 2000 - Installation...
  • Page 4 All manuals and user guides at all-guides.com NMEA 2000 - Installation...
  • Page 5 All manuals and user guides at all-guides.com NMEA 2000 - Installation...
  • Page 6 All manuals and user guides at all-guides.com NMEA 2000 - Installation...
  • Page 7 All manuals and user guides at all-guides.com NMEA 2000 - Installation...
  • Page 8 All manuals and user guides at all-guides.com NMEA 2000 - Installation...
  • Page 9 All manuals and user guides at all-guides.com NMEA 2000 – PGN Support PGN is the Parameter Group Number which defines the type of data being transmitted or received...
  • Page 10 All manuals and user guides at all-guides.com NMEA 2000 - Sources • NMEA2K Gateway is under the Accessory • Select sources for each data type needed • Setup and enter any offsets for depth, temperature, speed or heading • Setup and enter units of...
  • Page 11 All manuals and user guides at all-guides.com NMEA 2000 - Sources...
  • Page 12 All manuals and user guides at all-guides.com NMEA 2000 – GPS Selection...
  • Page 13 All manuals and user guides at all-guides.com NMEA 2000 – GPS Selection...
  • Page 14 All manuals and user guides at all-guides.com NMEA 2000 – Alarms...
  • Page 15 All manuals and user guides at all-guides.com NMEA 2000 – X-Press View...
  • Page 16 All manuals and user guides at all-guides.com NMEA 2000 - Views...
  • Page 17 All manuals and user guides at all-guides.com NMEA 2000 - Views...
  • Page 18 All manuals and user guides at all-guides.com NMEA 2000 - Views...
  • Page 19 All manuals and user guides at all-guides.com NMEA 2000 - Views...
  • Page 20 All manuals and user guides at all-guides.com NMEA 2000 - Readouts...
  • Page 21 All manuals and user guides at all-guides.com NMEA 2000 - Readouts...
  • Page 22 All manuals and user guides at all-guides.com NMEA 2000 - Readouts...
  • Page 23 All manuals and user guides at all-guides.com Humminbird RADAR Installation and Operational Overview...
  • Page 24 All manuals and user guides at all-guides.com RADAR Installation – AS 12RD2KW...
  • Page 25 All manuals and user guides at all-guides.com RADAR Installation – AS 21RD4KW...
  • Page 26 All manuals and user guides at all-guides.com RADAR Installation...
  • Page 27 All manuals and user guides at all-guides.com RADAR Installation...
  • Page 28 All manuals and user guides at all-guides.com RADAR Installation...
  • Page 29 All manuals and user guides at all-guides.com RADAR Installation...
  • Page 30 All manuals and user guides at all-guides.com RADAR Menu • Located under the Main Menu, Accessories Tab • Used to access the Radar Installation menu and other less frequently adjusted radar settings.
  • Page 31 All manuals and user guides at all-guides.com RADAR Menu – Transmission Time • There are two types of transmissions – continuous and timed. • A Timed Transmission is useful for conserving power. This is often used in sailing applications or when not running engines and helps extend battery run time.
  • Page 32 All manuals and user guides at all-guides.com Radar Menu - Installation • Used for initial setup/installation of RADAR. • It should not need to be adjusted or changed by user after the installation has been completed.
  • Page 33 All manuals and user guides at all-guides.com Radar Menu – Installation • Used to Auto Tune the RADAR. • Should not need to be used unless user perceives an obvious problem or when major service has been performed on the radar. •...
  • Page 34 All manuals and user guides at all-guides.com Radar Menu – Installation • Adjusts the return so that long straight lines appear straight on the display. • Too much trigger delay pulls objects into the center of the display. • Too little trigger delay pushes objects away from the center of the display.
  • Page 35 All manuals and user guides at all-guides.com Radar Menu – Installation; Trigger Delay Too High...
  • Page 36 All manuals and user guides at all-guides.com Radar Menu – Installation; Trigger Delay Too Low...
  • Page 37 All manuals and user guides at all-guides.com Radar Menu – Installation; Trigger Delay Correct...
  • Page 38 All manuals and user guides at all-guides.com Radar Menu – Installation • Used to filter out the Main Bang return in the immediate vicinity of the RADAR/boat. • Too much MBS will filter out close objects like boats and buoys. •...
  • Page 39 All manuals and user guides at all-guides.com Radar Menu – Installation; MBS Too Low...
  • Page 40 All manuals and user guides at all-guides.com Radar Menu – Installation; MBS Almost…right...
  • Page 41 All manuals and user guides at all-guides.com Radar Menu – Installation; MBS Correct...
  • Page 42 All manuals and user guides at all-guides.com Radar Menu – Installation • Used to prevent the RADAR from transmitting in a certain direction. • Useful if the RADAR is installed on a fly bridge behind the user head or in front of their feet. •...
  • Page 43 All manuals and user guides at all-guides.com Radar Menu – Sector Blanking Active...
  • Page 44 All manuals and user guides at all-guides.com Radar Menu – Installation • Used to calibrate the heading of the RADAR with the keel of the boat. • Each installation will be slightly different so heading lines will have to be adjusted on the water •...
  • Page 45 All manuals and user guides at all-guides.com Radar Menu – Installation; Heading Line: Incorrect...
  • Page 46 All manuals and user guides at all-guides.com Radar Menu – Installation; Heading Line Corrected...
  • Page 47 All manuals and user guides at all-guides.com RADAR Menu • Filters noise from RADARs on other boats • There are three palettes (Red, Green, Yellow) • Turns Range Rings On/Off • Turns Bearing Scale On/Off...
  • Page 48 All manuals and user guides at all-guides.com RADAR Menu – Range Rings / Bearing Scale ON...
  • Page 49 All manuals and user guides at all-guides.com RADAR Menu – Range Rings / Bearing Scale OFF...
  • Page 50 All manuals and user guides at all-guides.com RADAR Views – Radar only...
  • Page 51 All manuals and user guides at all-guides.com RADAR Views – Split Chart and Radar...
  • Page 52 All manuals and user guides at all-guides.com RADAR – Marking Targets on Chart with RADAR...
  • Page 53 All manuals and user guides at all-guides.com X-Press Menu • Accessed from the RADAR views. • Press MENU key once to open. • Displays settings needed for general RADAR use.
  • Page 54 All manuals and user guides at all-guides.com X-Press Menu - Transmission • Used to start a RADAR continuous transmission. • Used to stop a RADAR transmission. • Used to start a timed RADAR transmission...
  • Page 55 All manuals and user guides at all-guides.com X-Press Menu - Gain • Adjusts the strength of the displayed RADAR return. • Works just like Sensitivity on Sonar views. • Adjustable from 0 to 255 • User should adjust Gain for each range as the gain settings are individually saved for each individual...
  • Page 56 All manuals and user guides at all-guides.com X-Press Menu – Gain: Too Low...
  • Page 57 All manuals and user guides at all-guides.com X-Press Menu – Gain: Too High...
  • Page 58 All manuals and user guides at all-guides.com X-Press Menu – Gain: Correct...
  • Page 59 All manuals and user guides at all-guides.com X-Press Menu - STC • STC – Slow Time Constant • Used to filter out noise in the radar return due to waves. • Adjustable from 0 to 255 • User should adjust STC setting for each RADAR range setting depending on water conditions.
  • Page 60 All manuals and user guides at all-guides.com X-Press Menu – STC: Too High...
  • Page 61 All manuals and user guides at all-guides.com X-Press Menu – STC: Too Low...
  • Page 62 All manuals and user guides at all-guides.com X-Press Menu – STC: Correct...
  • Page 63 All manuals and user guides at all-guides.com X-Press Menu - FTC • FTC – Fast Time Constant • Used to filter out noise in the RADAR return due to rain or snow. • Adjustable from 0 to 8 • FTC is common between all RADAR ranges.
  • Page 64 All manuals and user guides at all-guides.com X-Press Menu – FTC: Too High...
  • Page 65 All manuals and user guides at all-guides.com X-Press Menu – FTC: Correct...
  • Page 66 All manuals and user guides at all-guides.com X-Press Menu - Range • Can also be adjusted using ZOOM keys. • AS 12RD2KW is adjustable from 0.125nm to 24 nm. • AS 21RD4KW is adjustable from 0.125nm to 36 nm.
  • Page 67 All manuals and user guides at all-guides.com X-Press Menu - EBL/VRM • EBL – Electronic Bearing Line – Measures the relative bearing from the boat’s heading to a target • VRM – Variable Range Marker – Measures distance from the boat to a target •...
  • Page 68 All manuals and user guides at all-guides.com X-Press Menu - EBL/VRM...
  • Page 69 All manuals and user guides at all-guides.com Humminbird Radar Thank you for your attendance, can we answer any questions?
