1.3 Maximum Recorded Channels

The maximum number of channels supported by GV-Storage System V3 (Rev. B) varies with the
resolution and video compression method, as listed below. It's highly suggested to keep the total
bitrates under 2700 Mbps for better recording performance. Note that The tests were conducted
using RAID 5 with 4 HDD in a group, each HDD of 8 TB.
H.264 Compression
Video Streaming
Resolution Frame rate
1.3 MP 30 fps
2 MP 30 fps
3 MP 30 fps
4 MP 15 fps
5 MP 25 fps
8 MP 25 fps
12 MP 15 fps
H.265 Compression
Video Streaming
Resolution Frame rate
1.3 MP 30 fps
2 MP 30 fps
3 MP 30 fps
4 MP 25 fps
5 MP 30 fps
Complex Scenes
Recorded
Bitrate
Channels
3.99 Mbps 681
6.12 Mbps 438
8.68 Mbps 313
9.21 Mbps 295
9.19 Mbps 296
13.5 Mbps 201
14.47 Mbps 188
Complex Scenes
Recorded
Bitrate
Channels
2.64 Mbps 1030
4.31 Mbps 631
5.35 Mbps 508
7.87 Mbps 345
8.29 Mbps 538
Normal Scenes
Recorded
Bitrate
Channels
0.54 Mbps 5038
0.87 Mbps 3127
1.05 Mbps 2590
1.15 Mbps 2365
1.61 Mbps 1689
2.2 Mbps 1236
3.41 Mbps 866
Normal Scenes
Recorded
Bitrate
Channels
0.45 Mbps 6045
0.74 Mbps 3676
1.01 Mbps 2698
1 Mbps 2720
1.55 Mbps 1755
