2.3.2 LCD Front Panel
Front Panel
The LCD front panel is an option to setup some system settings. To start using the LCD panel,
press the Select button to login and configure the system. See the LCD menu diagram in the
next section.
Parts
Exitbutton
Selectbutton
Up and Down Arrow
buttons
Use the function keys to navigate through the menus in the front panel. The menus will show the
system status and allows you to configure network settings, password and mute the alarm buzzer.
NOTE: The login password of GV-Storage System V3 (Rev. B)'s LCD panel
and its Web interface are not independent of one another, where if one was
changed, the other won't be affected.
12
Function
Press this button to return to the previous menu.
EXIT
This is used to enter the option you have selected.
Use the Up or Down arrow keys to go through the
information on the LCD screen. This is also used to
move between each menu when you configure the
system.
