2.5 Installing HardDrives
2.5.1 Installing 3.5" Disk in a Disk Tray
1. Make sure the lock indicator is in unlocked position. To pull out a disk tray, press the tray
open button.
2. Pull out an empty disk tray. Pull the lever handle outwards to remove the carrier from the
enclosure.
3. Place the hard drive in the disk tray.
4. Install the mounting screws on the bottom part to secure the drive in the disk tray.
5. Slide the tray into a slot.
6. Close the lever handle until you hear the latch click into place.
16
Tray
Open
Button
Tray Hole A
