- Page 1 Hydraulic Puller Set Manual...
- Page 2 Revised 07.09.2017...
-
Page 3: Table Of Contents
ÍNDICE 1. Introduction 2. Hydraulic part 3. Mechanical part 3.1. User manual 3.2. Technical features 3.3. Push puller serie 1100H 3.4. Combinations with the spliters 1200 3.5. 2/3 jaws puller serie 1300H/TH 3.6. Self-centering pullers serie 1300THA 3.7. Internal pullers serie 1500H 3.8. -
Page 5: Introduction
The hydraulic cylinder which is the force creating part of the puller. It is a single acting cylinder with spring loaded return.. The pump is the part that brings pressure to the cylinder. Forza supplies it together with the gauge and hose. - Page 6 Hydraulic cylinders Reference ØA Stroke weight Spindle 09101 50,8 5/16”UNC 111083 3/4”UNF 16h 09181 82,6 3/8”UNC 111883 1”UNC 8h 09301 10,5 92,1 3/8”UNC 113083 1-1/4”UNC 7h 09521 130,2 1/2”UNC 115283 1-5/8”UNS 5,5h 09951 177,8 5/8”UNC 119583 2-1/2”UN 8h Hydraulic pumps Pump force Reference Weight...
-
Page 7: Mechanical Part
3.2 Technical features The hydraulic sets contain the necessary parts to put together several pullers. The various hydraulic pullers sets’ compositions are available in our catalogue or web page www.forza.es. Essentially the sets contains: - Push pullers series 1110H. - Spliter series 1200. -
Page 8: Push Puller Serie 1100H
3.3. Push Puller Serie 1100H Reference Weight (kg) 1110H 1118H 18,5 1130H 1152H 70,5 1195H You can invert the body and use the same extractor for pulling and pushing. Extensions serie 1100H Reference Thread R1 Thread R2 Puller ØD 1110-209H 3/4”... -
Page 9: Combinations With The Spliters 1200
Joining nuts for the 1100 We have joining nuts to connect the extensions and get more reach. Reference Joining nut 1110 112017 1120 112017 1135 113517 1152 115017 1195 119517 3.4 Combinations with the spliters 1200 The 1100H pullers combine with the series 1200: The size of the piece to be pulled out cannot be determined considering the B measuremente, but instead the C measuring distance between arms. - Page 10 Correct set up of the spliter. • The puller 1200 must press against the flat face. • Arms must be positioned as closest as possible to the piece to be pulled out. • It is the C distance which must be almost equal to the B. • In hose cnditions the pullers can work at the maximum force level. 1200 in flat side operation Incorrect spliter set up.
-
Page 11: 2/3 Jaws Puller Serie 1300H/Th
The most vulnerable puller to this is he 20 tons which arms’ thread is 5/8”. Fo this reason pullers 1118H have an interchangeable tip. 3.5. 2/3 jaws pullers serie 1300H/TH Ajustable reach self-tightening arms pullers Two and three amrs. Two amrs length: The longs ones with 3 holes and extra long ones with 4 holes. Forged and tempered arms. Techinical features 2 oscilating jaws puller (Serie 1300H) Technical features 1300H and 1300HX pullers (extra long jaws) Reference... -
Page 12: Self-Centering Pullers Serie 1300Tha
Technical features 3 oscilanting pullers (Serie 1300TH) Technical features serie 1300TH and 1300THX pullers (extra long jaws) Reference Combina Weight Ref. Ton. Mechanical part mechanical part Hydraulic part 1310TH 00910 1310THX 00910 1318TH 00918 1318THX 00918 1330TH 00930 1330THX 00930 1352TH 00952 1352THX... - Page 13 The main advantages of the autocentrants are: • Ease of placement in large and big extractors. • The legs are joined by a self-centering mechanism, so that when moving one, they move all simultaneously. • Ensure that the legs are perfectly positioned at the time of extraction. •...
-
Page 14: Internal Pullers Serie 1500H
3.7. internal pullers serie 1500H Interior puller serie 1500H Puller with two forged arms. With adjustable spindle to position de arms. Serie 1500H to be use with the push puller 1100H. Technical features 2/3 sef-centering jaws (Serie 1300THA) 1506 y 1507 1509 Caracteristicas Extractores Serie 1300THA y 1300THXA (patas extralargas) Reference... -
Page 15: Internal Pullers Serie 4700H
3.8. Internal pullers serie 4700H The 4700H Series interior pullers combine with the 1100H Series pullers. Technical features 2/3 self-centering jaws (Serie 1300THA) Technical features Internal pullers serie 4700H Reference Fit with B max B min 1110H 4704H10 1118H 4704H20... -
Page 16: Technical Features Series 1300H/Th Y 300Tha Jaws Puller
4. TECHNICAL FEATURES SERIE 1300H/TH Y 1300THA JAWS PULLER Arms Thickness Holes Pala P Width R Lenght L reference distances D 131006 12,5 131016 12,5 131706 17,5 15,5 131716 17,5 15,5 133006 133016 135206 1060 135216 1210 139506 1385 5. SPINDLE AND POINT PROTECT If the spindle is not dotted, place a point protector. -
Page 17: User Manual And Technical Features For Big Pullers
6. USER MANUAL AND TECHNICAL FEATURES FOR BIG PULLERS 1- Make sure that spindle is perfectly cleaned and greased. 2- Check that the shaft is punched. Otherwise use a point protector. 3- See that arms are evenly spread. 4- Do not keep the spindle too far from the body. 5- Wear all necesary safety equipamets 6- Hold the equipment steady by tightening the spindle manually. - Page 18 Whenerver possible see to always work with the shortest arm length in oder to reduce the bending of the arms. You may change the arms position simply by loosening the arms screw and the without taking it apart altogether slide it along until it matches the next hole. Proceed one arm after another while always securing the arm with a screw after every change.
- Page 20 S.L. de Herramientas Especiales Forza C/ San Miguel de Atxa, 24 01010 Vitoria www.forza.es...
