- Page 1 External Mechanical puller Series 1300 CTH-CTA User´s Manual 1300 CTH-CTA...
-
Page 2: Table Of Contents
ÍNDEX 1. Technical features 2. 1300CTH puller dimensions with pump 3. 1300CTA puller dimensions 4. User instructions 5. Jaws correct position 6. Exploded view Rev. 30.07.18... -
Page 3: Technical Features
1. TECHNICAL FEATURES • 2 or 3 jaws pullers. • Normal jaws (2 holes), long jaws (3 holes), extralong jaws (4holes). • External • Forged jaws 2. 1300CTH PULLER DIMENSIONS WITH PUMP Reference with L: long jaws, X: Extalong jaws Reference Stroke Weigth... -
Page 4: 300Cta Puller Dimensions
3. 1300CTA PULLER DIMENSIONS • All the jaws at the same time. • Offer easier positioning of the puller even in difficult to get at place. • The self centering puller is safe thanks to it´s jaw lock device in max spread position. -
Page 5: Jaws Correct Position
5. JAWS CORRECT POSITION It is advisable to place the jaws in the lowest possible hole. In this way, the jaws will be less bended when applying great effort. (Figure 1) As more height is needed the spindle starts to come out more (Figure 2). If the axis is bigger, the spindle will come out in excess of the body, (Figure 3), in that case when pulling with the wrench we can twist the spindle. -
Page 6: Exploded View
6. EXPLODED VIEW 1306CTH Exploded view 1308CTA Exploded view Spindles Ref. Ton. ØC ØF ØG ØH 00806 00808... - Page 7 Jaws Pata corta Pata extra larga 16 Pata larga Puller Ref jaw 131005 12,5 1306CTH 131006 12,5 1306CTA 131016 12,5 131705 15,5 1308CTH 131706 17,5 15,5 1308CTA 131716 17,5 15,5...
