- Page 1 Selfcentering Hydraulic puller 1300THA - 3300THA User Manual 1300THA-3300THA...
- Page 2 Revised 04.07.2017...
- Page 3 INDEX 1. Hydraulic part 2. Technical features 3. Puller dimensions 4. General instruccions 5. Mechanical Part, Breakdown...
- Page 5 The hydraulic cylinder which is the force creating part of the puller. It is a single acting cylinder with spring loaded return. The pump is the part that brings pressure to the cylinder. Forza supplies it together with the gauge and hose (1,8 m long).
-
Page 6: Technical Features
Hydraulics pumps Pump force Equipment Reference Weight Bar. Máx 09542 35,4 09102 09182 20-30 09522 09952 2. TECHNICAL FEATURES 3 oscillating jaws. Two available lengths, long jaws with 3 holes and extralong jaws with 4 holes. Forged and tempered jaws. Jaws are linked together through a seflf centering device allowing all 2 and 3 legs to be actuated simultaneously. -
Page 7: General Instructions
1395THA 1000 1600 1310THA and 1310THXA can be mounted with 2 or 3 jaws.. 4. GENERAL INSTRUCTIONS 1- Make sure the spindle is cleaned and greased before using. 2- Make sure the axe has a centre hole. If not, use a point protector 3- Make sure the jaws/extenders are properly centered. - Page 8 Specific instrucions for big pullers • Use a crane and slings for unloading the puller. • Thanks to the slings, the puller can work horizontally. • For changing the position, from horizontally to vertically, incline the puller slowly and carefully. •...
- Page 9 5. MECHANICAL SPARE PARTS Spindles and point protector Reference Spindle Protector Ød ØD 1310THA 111083 3/4”UNF 16h 111037 16,5 1318THA 111883 1”UNC 8h 111837 1330THA 113083 1-1/4”UNC 7h 113037 1352THA 115283 1-5/8”UNS 5,5h 113037 1395THA 119583 2-1/2”UN 8h 119537...
- Page 10 Jaws Long jaw 06 Extra long jaw 16 Ref jaws 131006 12,5 131016 12,5 131706 17,5 15,5 131716 17,5 15,5 133006 133016 135206 1060 135216 1210 139506 1385...
- Page 12 S.L. de Herramientas Especiales Forza C/ San Miguel de Atxa, 24 01010 Vitoria www.forza.es...
