- Page 1 SPEEDY-LIFT INSTALLATION MANUAL SP-CHRG05 DODGE CARAVAN|CHRYSLER TOWN & COUNTRY 2005 & UP...
- Page 2 PRD 333-105M Nylon Insert Locknut 1/4-20 Thin PRD 337-211P Button Head Socket Cap Screw Zinc Plated 5/16-18 x 1/2 PRD 2946 Flange Locknut Zinc Plated 5/16-18 SP-CHRG05-00 Floor Installation Kit -Left- PART NUMBER SP-CHRG05 SCALE 1:5 DESCRIPTION Speedy-Lift 2 Dodge Caravan 1 of 5 |tech@adaptsolutions.ca|866.641.0419|418.889.9838 fax...
- Page 3 Nylon Insert Locknut 5/16-18 PRD 341-146P Flat Washer Zinc Plated I.D. 11/32 SAE 5/16 AP S5-8A Sheet metal plug - flush Ø0.625" Black SCALE 1:8 SCALE 1:5 PART NUMBER SP-CHRG05 DESCRIPTION Speedy-Lift 2 Dodge Caravan 2 of 5 |tech@adaptsolutions.ca|866.641.0419|418.889.9838 fax ADAPT SOLUTIONS...
- Page 4 Hex Cap Bolt Zinc Plated 1/4-20 x 1/2 G5 PRD 333-105M Nylon Insert Locknut 1/4-20 Thin PRD BSHCS51618114P Button Head Socket Cap Screw Zinc Plated 5/16-18 x 1 1/4 SCALE 1:9 PART NUMBER SP-CHRG05 SCALE 1:5 DESCRIPTION Speedy-Lift 2 Dodge Caravan 3 of 5 |tech@adaptsolutions.ca|866.641.0419|418.889.9838 fax ADAPT SOLUTIONS...
- Page 5 SPEEDY-LIFT 2 DODGE CARAVAN STOW N'GO 2005+ SP700B Hook Assembly -Black- PRD 337-211P Button Head Socket Cap Screw Zinc Plated 5/16-18 x 1/2 SCALE 1:6 SCALE 1:5 PART NUMBER SP-CHRG05 DESCRIPTION Speedy-Lift 2 Dodge Caravan 4 of 5 |tech@adaptsolutions.ca|866.641.0419|418.889.9838 fax ADAPT SOLUTIONS...
- Page 6 PRD 337-211P Button Head Socket Cap Screw Zinc Plated 5/16-18 x 1/2 PRD 2946 Flange Locknut Zinc Plated 5/16-18 SCALE 1:6 SCALE 1:4 PART NUMBER SCALE 1:4 SP-CHRG05 DESCRIPTION Speedy-Lift 2 Dodge Caravan 5 of 5 |tech@adaptsolutions.ca|866.641.0419|418.889.9838 fax ADAPT SOLUTIONS...
- Page 7 1. Remove or stow the seat found in the location where you plan on installing the SPEEDY-LIFT. 2. Pre-assemble the floor adaptor kit. Secure the slotted angle adaptors SL-EQRS145 to the floor adaptors (tubing) using 5/16” X 2 1/4” bolts. NOTE: DO NOT FULLY TIGHTEN THE BOLTS. 3.
- Page 8 4. Secure the adaptors in place using a 5/16” X 3/4” socket set screw. Cover the socket set screw hole with the provided cap plug. NOTE: In some applications, the adaptors will seem loose and be able to move from side to side. This is normal at this stage of the installation. 5.
- Page 9 6. The SPEEDY-LIFT up/down and in/out motors can be disengaged manually to slide the SPEEDY-LIFT in and out and move the arm up and down. BEWARE! The arms are spring loaded. When disengaging the arms, make sure you hold the arm firmly. To disengage it, move the handle to the right and push down.
- Page 10 8. Thread the lead power cable (red +) under the doorstep moulding and through the firewall. WARNING: Pass through a grommet in the firewall to prevent the cable from chaffing. 9. Install the circuit breaker near the battery and then connect the battery to the circuit breaker. 10.
- Page 11 13. The full up position and the full down position may be adjusted by moving the trigger bolts in the slotted holes on the up/down gear located inside the SPEEDY-LIFT. NOTE: The full up position is pre-adjusted for maximum travel. Full UP FullDOWN 14.
- Page 12 15. To properly position the lower support arms, back the wheelchair up over the upper wheelchair support bracket. Press and hold the ‘IN’ button until the wheelchair barely starts to lift off the ground. Then adjust the lower support arms to support the wheelchair. Adjust the liftting angle of the wheelchair by sliding the lower supports forward or backwards.
- Page 13 16. Adjust the locking mechanism. Remove the wheelchair from the SPEEDY-LIFT. Press and hold the ‘IN’ button until the SPEEDY-LIFT is in its full up position. While manualy holding the lock closed, pull the cable tight and secure the cable lock. Cut off the excess lenght of cable. Run the SPEEDY-LIFT out to see if the locking mechanism operates properly.
-
Page 14: Warning Decals
WARNING DECALS After completing the installation of the SPEEDY-LIFT, please take time to install the warning decals. NOTE: The surface must be clean, dry and at ambient temperature for the sticker to stick to the surface. Start by locating a position to install the decals. ... -
Page 15: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSES Bad electrical connections. Check and clean corrosion from all connections including the car’s battery cable connections. Hand pendant wire problem. Check hand pendant wire to make sure it is properly plugged. Check the wire for any cuts. If so, replace the wire. - Page 16 ELECTRICAL BOX CONNECTIONS ASENTO SPEEDY LIFT with...
- Page 17 SPEEDY-LIFT ALONE SPEEDY LIFT CORD RED = 12 V POWER SUPPLY BLACK = GROUNDED TO THE CHASSIS...
-
Page 18: Year Limited Warranty
The only remedy for a defect in one of Adapt Solutions products shall be the repair or the replacement, at the discretion of Adapt Solutions, of the defective part or component. If repair or replacement is not commercially practical or cannot be timely made, Adapt Solutions may decide to refund the purchase price of the equipment (SPEEDY-LIFT) instead of repairing or replacing the original equipment.
