- Page 1 X X X X count count+ + + + count count Single Pocket - Currency Counter w/Discriminating feature Instructions Manual V.1...
-
Page 3: Table Of Contents
Table of Contents Chapter 1. Introduction ......................... 1 Compliance Statement............................1 Safety Precautions ............................. 2 Chapter 2. Overview of COUNT+ ................... 3 COUNT+ at a Glance............................4 Overview of Control Panel..........................5 Overview of LCD Display........................... 5 Chapter 3. Operating COUNT+ .................... -
Page 4: Chapter 1. Introduction
Chapter 1. Introduction Introduction ................................. 1 Compliance Statement............................1 Abbreviations and Acronyms ..........................2 Safety Precautions ............................... 2 AMROTEC®... -
Page 5: Compliance Statement
Introduction X X X X This guide covers the installation, operation and troubleshooting of COUNT+ COUNT+ COUNT+ COUNT+ Currency Counter. We recommend reading this guide thoroughly before operating the Currency Counter. Then, X X X X as you become more familiar with COUNT+ COUNT+, use it as a reference guide to look up information COUNT+... -
Page 6: Safety Precautions
Keep the device away from magnets, activated cellular phones, electrical appliances, or speakers within 13 cm / 5 inch. Cautions! Keep drinks, food, and other foreign objects away from the Currency Counter. Placing foreign objects on or into the Currency Counter can interrupt operation of the device. AMROTEC®... -
Page 7: Chapter 2. Overview Of Xcount
Chapter 2. Overview of XCOUNT+ at a Glance .......................... COUNT+ Overview of Control Panel ........................Overview of LCD Display ........................ -
Page 8: Xcount+ At A Glance
XCOUNT+ at a Glance Hopper Guide Hopper LCD Display Stacker Pocket Power Switch Power Socket Serial Port Printer SD Card Upgrade Socket PC Connection Socket Remote Display Socket AMROTEC®... -
Page 9: Overview Of Control Panel
Overview of Control Panel Navigation Keys Number / Function Keys / Start LCD Display (Clear) Overview of LCD Display Auto / Manual Operation Add Mode Counting Speed Counting Mode Batch Currency Name Information Counting modes Counting Result Print X X X X Overview of COUNT+ COUNT+... -
Page 10: Chapter 3. Operating Xcount
Auto / Manual Start Mode........................... 9 Add mode ................................9 Counting Speed ..............................10 Batch Counting..............................10 Discriminating Modes ............................12 Counting Operation in various mode ........................ 13 Counting Results & Display Content ......................13 Printing the Summary ............................14 AMROTEC®... -
Page 11: Power On / Off
Power On / Off X X X X To power on COUNT+ COUNT+: COUNT+ COUNT+ Plug in the supplied Power cord to the appliance socket of the device at the rear side. Press the Power Switch button at the rear side of the device. -
Page 12: Selecting Currency & Count Mode
The device counts banknotes with (A) is defined by the first note of a processed batch. (UV Off): The device counts banknotes without UV detection on. Press the F3 key to activate or deactivate MG counterfeit detection. UV Mode UV(A) Mode AMROTEC®... -
Page 13: Density Detection Level (Cnt)
Density detection level: (COUNT mode) X X X X COUNT+ COUNT+ device allows user to select a different density level if necessary. Press F2 key to COUNT+ COUNT+ select between four different double detection level. If the device cannot detect double feeding error correctly, specially for brand new straps, then set double detection level to “Lv1”... -
Page 14: Counting Speed
To cancel the batch, press “0” confirmed by Start.. The preset batch is now cancelled. Pre-set batch setting [100, 50, 25, 20, 10, DB ] Press the Function key followed by BATCH. Repeat Pressing BATCH key to toggle between pre-set batch number from 10, 20, 25, 50, 100 & DB. AMROTEC®... -
Page 15: Denomination Batch Setting
Press the Start to confirm your pre-set batch setting and back to previous menu. The preset batch is shown on the right top of the LCD display. To cancel the pre-set batch, press the Function and BATCH to enter into batch mode and press the C to clear the present number. -
Page 16: Discriminating Modes
*NOTE: Xcount+ device has the options for deactivating some of these discriminating modes, such as FACE, ORIENT, SORT to simplify the Counting process and easier user-operation. Contact your sales representative if you wish to remove some of these sorting functions from XCOUNT+ device. AMROTEC®... -
Page 17: Counting Operation In Various Modes
Counting Operation in various Modes: To enter into various currency discriminating modes, press the navigation key F2 for “V (value)” to scroll through various modes: Face Ornt (Orient) Sort back to Before start counting, press the navigation key F2 for “V (value)”. Select "MIX"... -
Page 18: Printing The Summary
Press the C to cancel the operation. Printing of receipt. The printer receipt lists the "currency name", date and time, User ID, “Pcs" and amount by each denominations and total quantity and amount of counted banknotes. Printer Option Print Dialogue Example of a receipt: AMROTEC®... -
Page 19: Xcount
Chapter 4. Setting of COUNT+ Set Function and Adjusting Environment Settings ..................16 Contrast ............................Backlight ............................Sound Setting ........................... Alarm ................................17 key Beep ..............................18 Setup Currency Exchange Rates...................... Advanced Setting ..........................Device Information .......................... -
Page 20: Set Function And Adjusting Environmental Settings
Adjust the contrast from light (Level 1) to dark (Level 7) Use the “ (Move Up)” and “ (Move Down)” to select a desired setting. Confirm setting. Press the “ (Enter)” or Start to confirm the setting and return to previous screen. AMROTEC®... -
Page 21: Backlight
Backlight Under Backlight setting menu, operator has the option to turn on or off the backlight of the LCD display ( See below steps describing how to turn on / off the LCD backlight. Default: ON). Highlight the icon (Enter) press the “... -
Page 22: Setup Currency Exchange Rates
Exchange table. Use the number keys to type a current rate and F3 for the decimal separator dot. Press C to delete the last digit. After setting the correct exchange rate, press Start to confirm and return to previous screen. AMROTEC®... -
Page 23: Advanced Setting
Advanced Setting Under Advance setting menu, trained operator has the options to select certain advanced features of the device, such as starting machine as "factory default" or last user's settings, or set up printer paper, or print BPS etc. Follow the below steps to browse this setting area and make changes if necessary. - Page 24 115200 :115200bps Select the baud rate of the connected thermal printer. “ (Move Up)” and “ (Move Down)” Use the to toggle a desired setting. Confirm setting. (Enter) Press the “ ” to confirm setting and return to previous screen. AMROTEC®...
-
Page 25: Device Information
Device Information To retrieve the device detail information including Serial Number of the machine, software versions loaded or upgraded, production date of the machine or total count since it's operation etc. Highlight the icon and press the “ (Enter)”. The Device information is displayed as below: TN: Machine Type Name FV: Firmware Version MD: Production Date... -
Page 26: Chapter 5. Maintaining Xcount
Chapter 5. Maintaining COUNT+ Series Opening Bill Path..........................Cleaning .......................... COUNT+ AMROTEC®... -
Page 27: Open Bill Path
Opening Bill Path Cautions! Do not attempt to open the top bill path while device is still in operation. Turn off the device before attempting to open the top bill path. Open the Top bill path only when banknotes are jammed in this area as prompted by the error message displayed on the LCD screen during a counting operation and only when device is halted. -
Page 28: Appendix. Specification
Dimensions (inch / mm) 285 (W) x 270 (D) x 280 (H) Weight (lbs / kgs) Approx. 15.8lbs / 7.2 kg RS-232 Interface USB for PC, SD Card Remote Display Options Thermal Printer * Specifications are subject to change without further notice AMROTEC®... - Page 29 AMROTEC® technician or Service Provider. Parts repair or replacement under this warranty is only provided upon presentation of reasonable evidence that the date of the claim is within the warranty period and warranty guideline has been satisfied.
- Page 30 WWW.AMROTEC.COM September, 2014 All Rights are Reserved. Copyright 2014© AMROTEC®...
