CONNECTIONS & ACCESSORIES
Voltmeter
The inbuilt voltmeter will display the voltage of your battery, this can be turned on and
off using the little red switch on the unit. For an accurate voltage reading, disconnect all
loads and charging sources from the control hub and test. The voltmeter is equipped
with an audible low battery alarm that activates when the voltage below 11.0V. To mute
this alarm, simply turn the voltmeter off or connect a charging source.
Note: The battery voltage table on the sticker of the control hub is to be used as a
guide for SOC % only, check your battery specifications for accuracy.
LED Light
The control hub is fitted with a LED light. This can be turned on using the switch
on the top of the unit. A red LED indicator will be visible on the switch when the
light is powered on.
7
