FEATURES

FRONT VIEW
6 way pre-wired
fuse block
with two spares
5x Back lit
Rocker
switches
1x 10A Cig Socket
2x 2.4A USB
Sockets
SIDE VIEW
Volt
Meter
Switch
2 Pin Anderson Style Plug for Solar Input
(DCDC Charger Model only)
3 Pin Anderson Plug for Alternator Input
(DCDC Charger Model only)
Side Entry Cable gland Side Entry Cable gland
2x Anderson Style In/Out Plugs (50A Combined)
2x Anderson Style In/Out Plugs (50A Combined)
TOP VIEW
4
Volt meter with
low battery alarm
Optional
20A DCDC Charger
with Solar Input
Bottom Entry Cable Gland
Quick Charge QC3.0 USB +
Type C PD Port (45W max)
1x 10A Cig Socket
LED Light Switch
LED Light
