Summary of Contents for HIKVISION DS-2XE6126FWD-HS
- Page 1 Explosion-Proof Dome Network Camera Quick Start Guide...
- Page 2 SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL HIKVISION BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS,...
- Page 3 BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY, OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS. YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES...
- Page 4 Network Dome Camera·Quick Start Guide IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATTER PREVAILS. Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
- Page 5 Network Dome Camera·Quick Start Guide This product and - if applicable - the supplied accessories too are marked with "CE" and comply therefore with the applicable harmonized European standards listed under the EMC Directive 2014/30/EU, the RoHS Directive 2011/65/EU, the ATEX Directive 2014/34/EU. 2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union.
- Page 6 Network Dome Camera·Quick Start Guide Ex Standards: IEC 60079-0: 2011 EN 60079-0: 2012/All: 2013 IEC 60079-1: 2014 EN 60079-1: 2014 IEC 60079-31: 2013 EN 60079-31: 2014 Nameplate: Special Conditions for Safe Use: 1. Ambient Temperature: -40°C to +60°C. 2. DO NOT OPEN WHEN ENERGIZED. 3.
- Page 7 Network Dome Camera·Quick Start Guide Industry Canada ICES-003 Compliance This device meets the CAN ICES-3 (A)/NMB-3(A) standards requirements. Warning: This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures.
- Page 8 Network Dome Camera·Quick Start Guide ● CAUTION: Hot parts! Burned fingers when handling the parts. Wait one-half hour after switching off before handling parts. This sticker is to indicate that the marked item can be hot and should not be touched without taking care. For device with this sticker, this device is intended for installation in a restricted access location, access can only be gained by service persons or by users who have been instructed about the reasons for the...
- Page 9 Network Dome Camera·Quick Start Guide ● Do not connect several devices to one power adapter as adapter overload may cause over-heating or a fire hazard. ● To avoid fire danger caused by electrostatic charge, never touch or wipe the camera in explosive environment. Perform the wiping and replacing accessories only under non-explosive environment with the provided glove.
- Page 10 Network Dome Camera·Quick Start Guide ● Do not aim the camera at the sun or extra bright places. Blooming or smearing may occur otherwise (which is not a malfunction), and affect the endurance of sensor at the same time. ● The sensor may be burned out by a laser beam, so when any laser equipment is in using, make sure that the surface of sensor will not be exposed to the laser beam.
- Page 11 Network Dome Camera·Quick Start Guide ● CAUTION: Risk of explosion if the battery is replaced by an incorrect type. Dispose of used batteries according to the instructions ATTENTION: IL Y A RISQUE D'EXPLOSION SI LA BATTERIE EST REMPLACÉE PAR UNE BATTERIE DE TYPE INCORRECT. METTRE AU REBUT LES BATTERIES USAGÉES CONFORMÉMENT AUX INSTRUCTIONS ●...
-
Page 12: Table Of Contents
Network Dome Camera·Quick Start Guide Table of Contents 1 Introduction .................. 12 1.1 Overview ............... 12 1.2 Model Description............12 2 Appearance Description ............... 14 2.1 Overview ............... 14 2.2 Cable Description ............15 3 Installation ..................16 3.1 Wall Mounting .............. 17 3.2 Pendant Mounting ............ -
Page 13: Introduction
IP68 rating for ingress protection. Application Scenarios: oil industry, mine fields, chemical industry, port, grain processing industry, etc.. Model Description This manual is applicable to the following models: Applicable Model List Table 1-1 Model List DS-2XE6126FWD-HS DS-2XE6127FWD-HS DS-2XE6126FWD-S DS-2XE6136F-HS DS-2XE6147F-HS DS-2XE6146F-S DS-2XE6146F-HS DS-2XE6157F-HS... - Page 14 Network Dome Camera·Quick Start Guide Model Explanation Figure 1-1...
-
Page 15: Appearance Description
Network Dome Camera·Quick Start Guide 2 Appearance Description Overview Explosion-Proof Network Dome Camera Overview Figure 2-1... -
Page 16: Cable Description
Network Dome Camera·Quick Start Guide Cable Description Overview of Cables Figure 2-2 Description of Cables Table 2-1 Description Description RS-485 Power cord (12 VDC) Alarm input and output RJ45 Ethernet interface Audio input and output... -
Page 17: Installation
Network Dome Camera·Quick Start Guide 3 Installation Before you start: ● Make sure the device in the package is in good condition and all the assembly parts are included. ● The standard power supply is PoE or 12 VDC. Please make sure your power supply matches with your camera. -
Page 18: Wall Mounting
Network Dome Camera·Quick Start Guide Wall Mounting Before you start: There is no wall mounting bracket included in the package. You have to prepare a wall mounting bracket if you choose this mounting type. The shown bracket below is only for demonstration. 3-Ø... - Page 19 Network Dome Camera·Quick Start Guide Fix Camera to Wall Mount Figure 3-2 Mark the 3 screw holes on desired mounting surface according to the wall mount. Drill screws holes (Ø10.5 mm, 0.413 inch) for expansion bolts. Secure the wall mount to wall.
- Page 20 Network Dome Camera·Quick Start Guide Expansion Bolt Flat Washer Spring Washer Secure Wall Mount Figure 3-3...
-
Page 21: Pendant Mounting
Network Dome Camera·Quick Start Guide Pendant Mounting Before you start: There is no pendant mounting bracket included in the package. You have to prepare a pendant mounting bracket if you choose this mounting type. The shown bracket below is only for demonstration. DS-1694ZJ Pendant Mount Figure 3-4 Steps:... - Page 22 Network Dome Camera·Quick Start Guide Fix Camera to Pendant Mount Figure 3-5 Mark the 3 screw holes on desired mounting surface according to the pendant mount. Drill screws holes (Ø10.5 mm, 0.413 inch) for expansion bolts. Secure the pendant mount to ceiling. Expansion Bolt Flat Washer...
-
Page 23: Activate And Access Network Camera
