- Page 1 N3020 电动喷枪 Electric Spray Gun Elektrische Spritzpistole Pistolet à peinture électrique Pistola a spruzzo elettrica Pistola de pulverización eléctrica Pistola de pulverização elétrica 電動スプレーガン Pistol semprot listrik SAVE THIS INSTRUCTION MANUAL FOR FUTURE PEFERENCE.
-
Page 2: Important Safety
Important Safety • Read all safety inform n before opera the equipment. Save these To reduce the risks of fire or explosion, electrical shock and the injury to persons, read and understand all inst included in this manual. Be familiar with the controls and proper usage of the equipment. Indicates a hazardous situa on which, if not avoided, HAZARD: HAZARDOUS VAPORS could result in death or serious injury. -
Page 3: Important Safety Information
Important Safety Information • Read all safety information before operating the equipment. Save these instructions Important Electrical Information 1. The tool plug must fit into the socket. The plug may not be modified in any form. Do not use adaptor plugs together with protective‐earthed tools. Unmodified plugs and suitable sockets reduce the risk of an electric shock. 2. Avoid physical contact with earthed surfaces such as pipes, heating elements, stoves and refrigerators. The risk through electric shock increases if your body is earthed. 3. Keep the equipment away from rain and moisture. The risk of an electric shock increases if water penetrates electrical equipment. 4. Do not misuse the mains lead by carrying the tool by the lead, hanging it from the lead or by pulling on the lead to remove the plug. Keep the lead away from heat, oil, sharp edges or moving tool parts. Damaged or twisted leads increase the risk of an electric shock. 5. If you work outdoors, use only extension leads that are approved for outdoor use. The use of an extension lead that is suitable for outdoors reduces the risk of an electric shock. Components ComponentsCompoC ... - Page 4 Setup 1. Turn both knobs on both sides of the Air Compressor Assembly to the Material Preparation “Unlock” position, and Insert the spray gun into the Air Compressor Assembly into place, Before spraying, the material being used may need to be 2. Turn both knobs on both sides of the Air Compressor Assembly to the thinned with the proper solvent as specified by the “Lock” position to lock the two pieces into place. material manufacturer. Never exceed the thinning advice given by the coating manufacturer. Do not use materials with a flashpoint below 70°F (21°C). Follow the instructions below. 1. Stir the spraying material thoroughly before measuring viscosity. 2. Dip the viscosity test cup completely into the spraying material. Aligning the Suction Tube If you are going to be spraying in a downward direction, 3. Hold the test cup up and measure the time in seconds until the angled end of the suction tube should be pointing ...
- Page 5 Spraying The spray pattern shape is adjusted by turning the ears Proper Spraying Technique of the air cap to either the vertical, horizontal, or diagonal positions. The positions of the air cap and the If spraying with an HVLP spray system is new or corresponding spray pattern shapes are illustrated below. unfamiliar to you, it is advisable to practice on a piece of Test each pattern and use whichever pattern is suitable scrap wood or cardboard before beginning on your for your application. intended workpiece. Surface Preparation All objects to be sprayed should be thoroughly cleaned before spraying material on them. Areas not to be sprayed may, in certain cases, need to be masked or covered. Spray Area Preparation ‐ outdoor use only The spray area must be clean and free of dust in order to avoid blowing dust onto your freshly sprayed surface. How to Spray Properly • Position the spray gun perpendicular to and one (1) or more inches from the spray surface, depending upon the spray pattern size desired. • Spray parallel to the surface with smooth passes at a consistent speed as illustrated below. Doing this will help avoid irregularities in the finish (i. e. runs and sags). ...
- Page 6 Cleanup 6. Spray the solution through the Cleaning the Spray Gun gun for two seconds in a safe area. Spray again for two Special cleanup instructions for use with seconds. Unplug the spray flammable solvents (must have a flashpoint above gun, and trigger the spray gun 70ºF (21ºC): ...
-
Page 7: Maintenance
Maintenance You should inspect the air filter in the Air Compressor Assembly to see if it is excessively dirty. If it is dirty, follow the steps below 2. Remove the dirty filters filters and replace to replace it. with new ones. 1. Unplug the spray gun. Remove the filter cover with a tool (such as a flat screw driver) 3. Secure the cover back onto the turbine. Never operate your unit without the air filters. Dirt could be sucked in and interfere with the function of the unit. Troubleshooting ... -
Page 8: Parts List
Parts List Number Part Description Quantity Sprayer Assembly Container Seal Suction Tube 1 Seal Ring Suction Tube 2 Container Viscosity Cup Air Filter Air Compressor Assembly...
