- Page 1 NSG0060-18 Cordless Sprayer Gun Cordless Staple Technical data Max.viscosity 60 DIN-s Rated Voltage 20V DC Rated Power 243W Water flow rate 700ml/min Weight 1.45Kg...
-
Page 2: Important Safety Information
【Important safety information】 • Please read all safety instructions before using appliance. Save these instructions. Read all safety instructions in the manual to avoid hazards of fire, explosion, electric shock, and personal injury. Familiarize yourself with the correct use of the tool. This symbol indicates that this may result in death or Danger: Harmful gases Paints, solvents, pesticides, and... - Page 3 【Important safety information】 • Please read all safety instructions before using appliance. Save these instructions. Safety instructions of battery pack and charging Prevent unintentional starting. Ensure the switch is in the off-position before connecting to battery pack, picking up or carrying the appliance.
- Page 4 Components ComponentsCompoC Air filter Air volume Nozzle Nozzle regulator Adjusting knob guazrd Seal ring trigger Flow regulator Fan assembly Tank Handle Lock of Viscosity Battery pack tank...
- Page 5 Assembly Do not spray flammable liquids Assembly of spray gun 1. insert the fan assembly into spray part from unlock position to the Filling the spraying material end, then rotate fan assembly to lock position. 2. lock the tank to lock position. As shown below： 1.
- Page 6 Spraying 1. By turning the nozzle adjusting nut in various positions, the gun Spraying offers three types of spraying methods: round, horizontal flat round, The HVLP spray gun (Low Pressure and High Flow) is a brand new vertical flat round. Users can adjust accordingly to achieve the ideal spray system for users.
- Page 7 Cleaning 6. Spray cleaning solution for a few seconds Cleaning the spray gun （2-5s）in safety area, spray for a Note: Do not immerse the gun in the detergent! Unlock the fan assembly and remove it from the gun assembly. few few seconds again. Then remove the Align the release latch and pull out the gun.
-
Page 8: Battery Pack
Battery Pack Charing of battery pack Transportation Recharge only with the charger specified by the manufacturer. A 1. Lithium-ion battery packs supplied with the appliance must be charger that is suitable for one type of battery pack may create a subject to the Dangerous Goods regulations. -
Page 9: Maintenance
Maintenance 2. Remove the dirty filter and replace it with a new one. After using for a period of time, you should check if the filter is dirty or not. If it is too dirty, you need to replace the filter with the following steps. -
Page 10: Parts List
Parts list... - Page 11 Parts list Part name Quantity Gun assembly Fan assembly Battery pack Viscosity cup Nozzle Seal ring Wrench Special needle for unclogging the nozzle Brush Charger...
