G - TECHNICAL SETTINGS

Max. distance
Dry contact
Doorbell melody
Screen features
Intercom panel features
Electrical features
Smartphone compatibility
Operating temperature
Operation
Single product features
Kit features
Standard and certification
en - 16 EXTEL - WAVE - 720313
Wiring
Settings
Finish
Wireless
350m wireless - communication frequency between the intercom
panel and the screen: 2.4GHz
Lock AND gate
6 melodies
Sound level: 85dB
Diagonal: 7" (18cm)
Resolution: 1296 x 732px
Internal memory: photos
External memory: videos (8 GB SD card included)
WIFI 2.4GHz/5GHz IEEE 8111b/g/n/ac
Sensor: CMOS colour
Viewing angle: H105°
Lens: fixed
Colour night vision: Infrared LEDs
Strike plate control: 12V/1A for 0.5s
Gate control: breaking capacity 12V/2A for 2s
Surface mounting (recess mounting as an option:
recess case model number 720312)
Image: brightness, contrast, colours
Audio: ring volume, conversation volume
Screen: grey and black plastic
Intercom panel: aluminium and plastic
PowerBox: grey plastic
Monitor: 5V/1A
Intercom panel: 4x1.5V LR20
or external 12-30V/2A power supply
Application: Extel Connect (smartphone with 3G/4G or WIFI connection
required)
OS compatibility: Android (v4.4 or higher)/iOS (7 or higher)
Push notifications if a visitor calls
-10°C/+40°C
Monitor: interior
Intercom panel: exterior (IP44)
Monitor dimensions: 149mm (H) x 197mm (W) x 18mm (D)
Intercom panel dimensions: 202mm (H) x 70mm (W) x 28mm (D)
PowerBox dimensions: 320mm (H) x 90mm (W) x 55mm (D)
Weight: 1.9kg
Dimensions: 345 (H x 285 (W) x 85 (D)
Weight: 2.2kg
CE, RoHS, REACH
