Rapid
Quick Start
903134-en
17/05/2016-2
RD 300-400S
RD 300-400C
S/N 16001-

Advertisement

loading
Need help?

Need help?

Do you have a question about the Rapid RD 300-400S and is the answer not in the manual?

Questions and answers

Related Manuals for Vaderstad Rapid RD 300-400S

Summary of Contents for Vaderstad Rapid RD 300-400S

  • Page 1 Rapid Quick Start 903134-en 17/05/2016-2 RD 300-400S RD 300-400C S/N 16001-...
  • Page 2 List of contents Installation of electrics and hydraulics ............Installations ..................E-Control ..................ControlStation ..................Attachments Sowing tables ................. Tips for installing red hydraulic circuit ......Uploading new software – iPad ....... Denna Quickstart ersätter inte instruktionsboken! See kiirjuhend Quickstart ei asenda kasutusjuhendit! Denne Quickstart erstatter ikke instruktionsbogen! Návod Quickstart nenahrazuje návod k použití! Denne Quickstart erstatter ikke instruksjonsboken!
  • Page 3 RD 300-400S/C 1. Electrical installation on tractors • Mount ControlStation or the iPad in the tractor cab. Position it within your field of vision when looking forwards, and preferably so that you can reach it comfortably. Connect the GateWay cable if the tractor has an ISOBUS terminal. Lock the terminal using the locking bolt (A).
  • Page 4 RD 300-400S/C Settings NOTE! It is possible to make approximate basic settings on a flat, solid floor, but you can only perform final checks of your settings when sowing in the field! Horizontal alignment Horizontal adjustment of the seed drill is carried out by means of the push rod (B). The front and rear seed rows must have the same depth.
  • Page 5 RD 300-400S/C Radar The radar angle must be adjusted. The angle must be 35° ± 1° in relation to the soil surface. The angle of the radar is optimal when the surface (A) is parallel to the soil surface. Loosen the screws and adjust the bracket along the oblong hole (B).
  • Page 6 RD 300-400S/C Following harrow There are two different following harrows on Rapid RD – hydraulically controlled and mechanical. Mechanical following harrow The work pressure is set using the socket supplied. - Lower the machine, then lift it to low-lift. - Remove the R cotter pin (B) holding the adjusting screw (A) in position. - In this position, the following harrow must be pressed lightly against the ground, with greater pressure on heavy soils and more gently on light soils or where there is a lot of hay.
  • Page 7 RD 300-400S/C It is important that you also check that the following harrow tines run between the seed rows, one tine should run straight in front of the wheel, and one centrally between the wheels. If you need to adjust the entire tine row, do so by loosening the bolts holding the shaft in the drawbar. Front tools All front tools, other than the CrossBoard system, are depth-adjusted using clips located on the piston rod.
  • Page 8 RD 300-400S/C Spill prevention plates Spill prevention plates must be adjusted so that they remove any soil ridges that may be created between the furrows. They must therefore press lightly against the ground when sowing. The spill prevention plates are adjusted vertically depending on seed depth and the prevailing conditions.
  • Page 9 RD 300-400S/C E-Control Before each season, you should connect your iPad to the Internet and open E-Control to check whether any new updates have been released. See attachment 3. Home screen (Drive menu) Setup, see next page. Drive checks. Half machine shut-off (Area metering). Manual selection of bout marker arm (Left, Right, Both or None).
  • Page 10 RD 300-400S/C Setup Press Setup to access: Calibration of delivered seed Fertiliser BioDrill (option) Radar General (Basic settings) Tramlining (Setting desired tramlining programme). Alarm settings Workstation I/O (service menu) Calibration If you access any of the calibration menus, a pop up will appear: NOTE! Feed output stops if you access any of these menus! Select Yes Before calibration is performed, the bottom flaps and sliding hatches must be...
  • Page 11 RD 300-400S/C Contd. from previous page. Flap lever in sowing position. Flap lever in calibration posi- tion. Select pre-filling (1) or press the plus button onthe MiniRemote to fill the feed rollers. The MiniRemote is located on the left side of the seed hopper.
  • Page 12 RD 300-400S/C Drive checks Manual feed output. If you want to start feed output from a stationary position, e.g. in a corner, or during output verification, press and hold the button marked in green. Preselect the speed in the Basic settings menu. Lift stop.
  • Page 13 RD 300-400S/C Contd. from previous page. Automatic bout marker switching The symbol is green when automatic bout marker switching is activated. The symbol above shows which bout marker arm is activated. Low-lift The button lights green when low-lift is activated. Deactivate low-lift if the following furrow needs raising, e.g.
  • Page 14 RD 300-400S/C Half machine shut-off Half machine shut-off occurs in two stages: Go to the machine and close the selected side using the lever/levers on the side of the seed hopper. The rear lever is for seed and the front lever is for fertiliser.
  • Page 15 RD 300-400S/C Monitoring of seed, fertiliser and BioDrill (option) Area driven Speed Press any of the buttons to temporari- ly switch off the feed output. The but- ton will then be greyed out and STOP will appear in the display. Example: Adjustment of the sown amount Select actual sown amount, and a pop up will appear, make changes using the drop-down list depending on wheth- er you want to increase or decrease the sown amount, then press Done.
  • Page 16 RD 300-400S/C ControlStation CON. 06 - 02 !!!! ? Enter - Accept. Esc - Cancel. Selection dial - Page through the menus or enter value. Calibration menu Drilling depth Remote – Adjustment of fertiliser amount (option) Bout marker arms Tramlining Info menu Half machine shut-off (Area metering).
  • Page 17 RD 300-400S/C Press the B button to access the calibration menu. kg/ha Enter the required seed application rate ( kg/ha) Press Enter. + / - Calibrate Use the selection dial to scroll down and enter the required reduction/decrease of variable application rate in %. Enter. 0.0 kg/ha + / - Page down to Calibrate and press Enter.
  • Page 18 RD 300-400S/C Control – Seed depth In order to set or change seed depth, activate the Control function in the lifting ram by pressing the C button. Use the lifting ram to change depth. The sowing depth indicator on the seed hopper shows the actual seed depth.
  • Page 19 RD 300-400S/C Tramlining Actual driven pass in the tramlining cycle. Selected tramlining programme (24 m on a 4 m RD in this case). 06 - 02 The lamps light green when tramlining is taking place. Half machine shut-off Half machine shut-off occurs in two stages: Go to the machine and close the selected side using the lever/levers on the side of the seed hopper.
  • Page 20 RD 300-400S/C Attachment 1. Sowing table grain Position of sliding hatches Bottom flap position If relevant, disengagement of normal roller 17/05/2016...
  • Page 21 RD 300-400S/C Info menu and Basic settings Sowing table, fertiliser Position of sliding hatches Bottom flap position 17/05/2016...
  • Page 22 RD 300-400S/C Attachment 2 Circuit for hydraulic feed output/hydraulic following harrow (red circuit). The feed output system and, if relevant, hydraulic following harrow take approx. 10–20 litres/min. It will normally be sufficient to bring the hydraulic flow down to approx. 30%. If this is not sufficient, an alarm will be generated for Seed Valve Max Power, in which case, increase the flow by approx.
  • Page 23 RD 300-400S/C If there are any available updates, these will be downloaded. Connect the iPad to Gateway to see the following question: Select OK Updates will now be downloaded in Gateway, which will re-start when done. A message will appear telling the update was successful. DONE! 17/05/2016...
  • Page 24 Väderstad AB SE-590 21 VÄDERSTAD Sweden www.vaderstad.com Phone: +46 142 820 00...
