AU
KULINARISK

Advertisement

Table of Contents
loading

Related Manuals for IKEA KULINARISK 504.210.60

Summary of Contents for IKEA KULINARISK 504.210.60

  • Page 1 KULINARISK...
  • Page 2 ENGLISH Please refer to the chapter IKEA GUARANTEE for contact details of the after sales customer service centre.
  • Page 3 ENGLISH...

  • Page 4: Table Of Contents

    Before first use Energy efficiency Daily use Environmental concerns Clock functions IKEA guarantee Automatic programmes Subject to change without notice. Safety information Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use causes injuries and damage.
  • Page 5 ENGLISH Keep children and pets away from the appliance when it • operates or when it cools down. Accessible parts may become hot during use. If the appliance has a child safety device, it should be • activated. Children shall not carry out cleaning and user maintenance •...

  • Page 6: Conditions Of Use

    ENGLISH The means for disconnection must be incorporated in the • fixed wiring in accordance with the wiring rules. Use only the food sensor (core temperature sensor) • recommended for this appliance. Conditions of Use This appliance is intended to be used in •...
  • Page 7 ENGLISH electrical ratings of the mains power • Be careful when you open the appliance supply. door while the appliance is in operation. • Always use a correctly installed Hot air can release. shockproof socket. • Do not operate the appliance with wet •...
  • Page 8 ENGLISH damage to the appliance, the housing materials, as such consumers are strongly unit or the floor. Do not close the advised to: furniture panel until the appliance has – provide good ventilation during and cooled down completely after use. after each Pyrolytic cleaning.

  • Page 9: Installation

    ENGLISH Service • Cut off the mains electrical cable close to the appliance and dispose of it. • To repair the appliance contact the • Remove the door to prevent children and Authorised Service Centre. pets to get closed in the appliance. •...

  • Page 10: Product Description

    ENGLISH Product description General overview Control panel Electronic programmer Socket for the core temperature sensor Grill Lamp Shelf support, removable Rating plate Shelf positions Accessories To bake and roast or as pan to collect fat. • Core temperature sensor x 1 •...
  • Page 11 ENGLISH Symbol Function Comment Heating Functions Press once to enter to the Heating Functions Menu. or Assisted Cook‐ Press again to switch to Assisted Cooking. To turn on or off the light, press for 3 seconds. Back key To go back one level in the menu. To show the main menu, press the symbol for 3 seconds.

  • Page 12: Before First Use

    ENGLISH Other indicators of the display: Symbol Function Minute Minder The function works. Time of day The display shows the current time. Duration The display shows the necessary time for cooking. End Time The display shows when the cooking time is complete. Temperature The display shows the temperature.

  • Page 13: Daily Use

    ENGLISH 1. Set the function: Conventional Cooking 2. Open the door. Close the oven door without pulling the child and the maximum temperature. lock. 2. Let the oven operate for 1 hour. To remove the child lock, open the oven door 3.
  • Page 14 ENGLISH Symbol / Menu Application Symbol / Menu Description item item Contains a list of fa‐ To set a function and vourite cooking pro‐ activate it later with a Favourites Set + Go grammes created by press of any symbol on the user.
  • Page 15 ENGLISH Symbol / Menu Description Heating Application item function Resets all settings to This function is designed to factory settings. save energy during cooking. Factory Settings For the cooking instructions Moist Fan refer to "Hints and tips" chap‐ Baking Heating Functions ter, Moist Fan Baking.
  • Page 16 ENGLISH Specials Setting a heating function 1. Turn on the oven. Heating function Application 2. Select the menu: Heating Functions. To bake bread. 3. Press to confirm. 4. Select a heating function. Bread Baking 5. Press to confirm. 6. Set the temperature. For dishes such as lasa‐...

  • Page 17: Clock Functions

    ENGLISH Clock functions Clock functions table Setting the clock functions Before you use the functions: Clock function Application Duration, End Time, you must set To set a countdown Minute Mind‐ a heating function and (max. 2 h 30 min). This temperature first.

  • Page 18: Automatic Programmes

    2. Select the menu: Recipes. Press for this oven on the website confirm. www.ikea.com. To find the proper 3. Select the category and dish. Press Recipe Book check the article confirm. number on the rating plate on the 4.
  • Page 19 ENGLISH The core temperature sensor must stay in the meat and in the socket during the cooking. 1. Put the tip of the core temperature sensor into the centre of the meat. 2. Put the plug of the core temperature sensor into the socket at the top of the cavity.

  • Page 20: Additional Functions

    ENGLISH Warning! The core temperature sensor is hot. There is a risk of burns. Be careful when you °C °C remove the tip and the plug of the core temperature sensor. Using the telescopic runners Keep the installation instructions for the telescopic runners for future use.
  • Page 21 ENGLISH If the Pyrolysis function works, Press any symbol (except for ) to start the the door locks automatically. function: Set + Go. The set heating function A message comes on in the starts. display when you press any When the heating function ends, a signal symbol.

  • Page 22: Hints And Tips

    ENGLISH Cooling fan Safety thermostat When the oven operates, the cooling fan Incorrect operation of the oven or defective turns on automatically to keep the surfaces components can cause dangerous of the oven cool. If you turn off the oven, the overheating.
  • Page 23 ENGLISH Food Accessories Temperature Shelf posi‐ Time (min) (°C) tion Swiss roll baking tray or dripping 25 - 35 Brownie baking tray or dripping 25 - 30 Soufflè, 6 pieces ceramic ramekins on wire 25 - 30 shelf Sponge flan flan base tin on wire shelf 15 - 25 base...
  • Page 24 ENGLISH Food Accessories Temperature Shelf posi‐ Time (min) (°C) tion Vegetarian ome‐ pizza pan on wire shelf 25 - 30 lette Vegetables, baking tray or dripping 25 - 30 mediterrean 0.7 Moist Fan Baking - recommended accessories Use the dark and non-reflective tins and containers.
  • Page 25 ENGLISH Food Function Accesso‐ Shelf Temper‐ Time (min) Comments ries posi‐ ature tion (°C) Small Convention‐ Baking 20 - 30 Put 20 small cakes cake al Cooking tray per one baking tray. Small True Fan Baking 150 - 20 - 35 Put 20 small cakes cake Cooking...

  • Page 26: Care And Cleaning

    For additional cooking tables please refer to cavity. the Recipe Book which you can find on the website www.ikea.com. To find the proper Care and cleaning If you have nonstick accessories, do not Warning! Refer to Safety clean them using aggressive agents, sharp- chapters.
  • Page 27 ENGLISH Removing the shelf supports 2. Clean the oven cavity with warm water and mild detergent. Clean the inner door To clean the oven, remove the shelf glass with warm water and soft cloth. supports. 3. Turn on the oven. 4.
  • Page 28 ENGLISH one. Start from the top panel. Make sure the glass slides out of the supports completely. 2. Lift and turn the levers fully on both hinges. 8. Clean the glass panels with water and soap. Dry the glass panels carefully. Do not clean the glass panels in the dishwasher.

  • Page 29: Troubleshooting

    ENGLISH Replacing the lamp Put a cloth on the bottom of the interior of the oven. It prevents damage to the lamp glass cover and the cavity. Warning! Danger of electrocution! Disconnect the fuse before you replace the lamp. The lamp and the lamp glass cover can be hot.
  • Page 30 ENGLISH Problem Possible cause Remedy The oven does not heat up. The door is not closed cor‐ Fully close the door. rectly. The oven does not heat up. The fuse is blown. Make sure that the fuse is the cause of the malfunction. If the fuse is blown again and again, contact a qualified electrician.

  • Page 31: Technical Data

    50 - 60 Hz Number of functions Energy efficiency Product Information and Product Information Sheet* Supplier's name IKEA Model identification KULINARISK 504.210.60 Energy Efficiency Index 81.2 Energy efficiency class Energy consumption with a standard load, convention‐ 0.93 kWh/cycle al mode Energy consumption with a standard load, fan-forced 0.69 kWh/cycle...

  • Page 32: Environmental Concerns

    ENGLISH * For European Union according to EU Regulations 65/2014 and 66/2014. For Republic of Belarus according to STB 2478-2017, Appendix G; STB 2477-2017, Annexes A and B. For Ukraine according to 568/32020. Energy efficiency class is not applicable for Russia. EN 60350-1 - Household electric cooking appliances - Part 1: Ranges, ovens, steam ovens and grills - Methods for measuring performance.

  • Page 33: Ikea Guarantee

    This guarantee is valid for 5 years from the Australia original date of purchase of your appliance at IKEA Pty Ltd, ABN 84006270757 or at Contact - IKEA Customer Service at Cebas Pty Ltd, ABN 15 009 156 003 (Both www.IKEA.com.au...
  • Page 34 If your claim other address, IKEA is not liable for any is approved, the IKEA service provider or its damage that may occur during transport.
  • Page 35 2. Ask for clarification on installation of the IKEA appliance in the dedicated IKEA kitchen furniture. 3. Ask for clarification on user manual con‐ tents and specifications of the IKEA ap‐ pliance. To ensure that we provide you with the best assistance, please read carefully the As‐...
  • Page 36 21552 © Inter IKEA Systems B.V. 2021 AA-2063528-4...
