Tyco DSC TL280 Instruction Manual

Internet alarm communicator
Hide thumbs
Table of Contents

Advertisement

Quick Links

TL280(R)
Internet Alarm Communicator - North America
I
M
4.0
NSTALLATION
ANUAL V
Warning: This manual contains information on limitations regarding product use
and function and information on the limitations as to liability of the manufacturer.
firealarmresources.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DSC TL280 and is the answer not in the manual?

Questions and answers

Related Manuals for Tyco DSC TL280

Summary of Contents for Tyco DSC TL280

  • Page 1 TL280(R) Internet Alarm Communicator - North America NSTALLATION ANUAL V Warning: This manual contains information on limitations regarding product use and function and information on the limitations as to liability of the manufacturer. firealarmresources.com...
  • Page 2 firealarmresources.com...

  • Page 3: Table Of Contents

    ABLE OF ONTENTS General ............5 Technical Specifications.
  • Page 4 WARNING: I NSTALLER LEASE AREFULLY Note to Installers Motion Detectors The warnings on this page contain vital information. As the only Motion detectors can only detect motion within the designated areas individual in contact with system users, it is the installer’s responsi- as shown in their respective installation instructions.

  • Page 5: General

    Internet Alarm Communicator Installation Manual ENERAL IMPORTANT This installation manual shall be used in conjunction with the control panel manual. All the safety instructions specified within that manual shall be observed. The control panel is referenced as the “panel” throughout this document. The Internet alarm communicator is a fixed, wall-mounted unit, and shall be installed in the loca- tion specified in these instructions.The equipment enclosure must be fully assembled and closed, with all the necessary screws/tabs, and secured to a wall before operation.

  • Page 6: Technical Specifications

    Internet Alarm Communicator Installation Manual Technical Specifications The input voltage to the Communicator can be drawn from an Underwriters Laboratories/Under- writers Laboratories Canada (UL/ULC) listed control panel or compatible power supply module such as HSM2204 or HSM2300. NOTE: Power supply must be Class 2, power limited. UL/ULC Installation Requirements NOTE: For equipment used at the protected premises and intended to facilitate IP communica- tions (hubs, routers, NIDs, Digital Subscriber Line (DSL), cable modems), 24 hour back-...

  • Page 7: Ratings And Compatibility

    Internet Alarm Communicator Installation Manual Ratings and Compatibility Table 1: Communicator Ratings Model TL280(R) Power Supply Ratings 10.8-12.5 VDC Power is supplied from the panel’s PC-Link header or a PCL-422 module in Input Voltage remote cabinet installations. In remote cabinet installations, the PCL-422 module located with the communicator is powered by either an HSM2204 or an HSM2300.

  • Page 8: Installing The Ethernet Cable

    Internet Alarm Communicator Installation Manual indoor locations only. This manual shall be used with the installation manual of the panel which is connected to the Ethernet communicator. All instructions specified within the panel manual must be observed. All the local rules imposed by local electrical codes shall be observed and respected during instal- lation.
  • Page 9 Internet Alarm Communicator Installation Manual c. Locate the screw hole on the right side wall of the Figure 2:HS2016/2032/2064/2128 Control Panel panel. See Figure 2 (screw). Line up the assembled PC-Link communicator with the right side wall of the panel cable connector and, using the screw provided, secure the mount- ing bracket to the panel.

  • Page 10: Initial Panel Programming

    Internet Alarm Communicator Installation Manual NOTE: The GND connection is optional. DSC recommends connecting GND wire at both ends. Install Network Cable 1. Route the CAT 5 Ethernet cable through back of the panel and plug it into the communicator’s RJ45 jack.
  • Page 11 Internet Alarm Communicator Installation Manual NOTE: If this option is OFF, the yellow status LED on the communicator will indicate ‘Panel Supervision Trouble’ (2 flashes) and the unit can not be programmed via the PC-LINK cable. NOTE: Account number in communicator section [851][021] automatically syncs with panel sys- tem account number in section [310][000].

  • Page 12: Communicator Status Leds

    Internet Alarm Communicator Installation Manual OMMUNICATOR TATUS The communicator has 2 on-board LED indicators: a yellow trouble LED and a red network con- nection status LED. The LED meaning is described in this section. Yellow Trouble LED The yellow LED will flash to indicate a trouble on the unit. The number of flashes indicates the type of trouble.

  • Page 13: Communicator Reset / Update

    Internet Alarm Communicator Installation Manual • Twice quickly to indicate incoming Ethernet ACK/NACK. OFF: This is the normal state of the red network connection status LED. There are no network connection issues present. ON: There is a problem with the Ethernet network connection. LED will be ON if any of the fol- lowing occur: •...

  • Page 14: Communicator Troubleshooting

    Internet Alarm Communicator Installation Manual OMMUNICATOR ROUBLESHOOTING NOTE: For additional details: • Refer to section [983] for troubleshooting the firmware updates • Refer to section [984] to verify the trouble status Table 6: Trouble indications Trouble Trouble Possible Indicator Trouble Possible Solution indication Causes Digit...

  • Page 15: Ethernet Programming Options

    Internet Alarm Communicator Installation Manual THERNET ROGRAMMING PTIONS The programming sections described in this document can be viewed at the keypad LCD. To start programming enter: [*][8][installer code] [851] [section number], where section number is the 3 digit section number referenced in this section. The programming worksheets at the end of this document can be used to record the new values when programming changes have been made from the default values.
  • Page 16 Internet Alarm Communicator Installation Manual Table 7: Supervision Intervals for UL/ULC Recommended Supervision Jurisdiction Receiver Window (Timeout) Interval UL Commercial Burglary 200 seconds (0087/135) seconds UL Residential Fire 30 days Panel Test Transmission UL Residential Burglary 30 days Panel Test Transmission ULC Commercial Burglary Active 180 seconds (005A/90) seconds...
  • Page 17 Internet Alarm Communicator Installation Manual [006] System Toggle Options 2 [1] Ethernet 1 receiver enabled. Default (ON). ON: Ethernet receiver 1 is enabled. OFF: Ethernet receiver 1 is disabled. [2] Ethernet receiver 2 is enabled. Default (ON). ON: Ethernet receiver 2 is enabled. OFF: Ethernet receiver 2 is disabled.
  • Page 18 Internet Alarm Communicator Installation Manual number, as determined by your network administrator. In most cases, changing the default value or configuring your firewall with this port is not required. Valid range: 0000-FFFF. [015] DLS Call-Up IP Default (000.000.000.000) [016] DLS Call-Up Port Default (0000) [020] Time Zone Default (00)
  • Page 19 Internet Alarm Communicator Installation Manual Table 8: World Wide Time Zones Offset Location Value Hours Abbrev Atlantic Standard Time CLST Chile Standard Time BWST Brazil Western Standard Time San Luis Time Paraguay Time JFST Juan Fernandez Island Standard Time Guyana Time FKST Falkland Island Standard Time Bolivia Time...
  • Page 20 Internet Alarm Communicator Installation Manual Table 8: World Wide Time Zones Offset Location Value Hours Abbrev Eastern Europian Time Central Africa Time Syrian Standard Time SAST South Africa Standard Time Israel Standard Time Moscow Standard Time Eastern Africa Time Arabic Standard Time Arabia Standard Time Al Manamah Standard Time IRST...
  • Page 21 Internet Alarm Communicator Installation Manual Table 8: World Wide Time Zones Offset Location Value Hours Abbrev Indian Standard Time 5.75 Nepal Time Xinjiang Standard Time EKST East Kazakhstan Standard Time Sri Lanka Time VOST Vostok Time OMSK Omsk Standard Time NOVT Novosibirsk Time Bhutan Time...
  • Page 22 Internet Alarm Communicator Installation Manual Table 8: World Wide Time Zones Offset Location Value Hours Abbrev 8.25 Apo Island Time 8.75 ACWST Australian Central Western Standard Time YAKT Yakutsk Time Japan Standard Time Korea Standard Time Waktu Indonesia Bagian Timur East Timor Time Palau Time ACST...
  • Page 23 Internet Alarm Communicator Installation Manual Table 8: World Wide Time Zones Offset Location Value Hours Abbrev NZST New Zealand Standard Time Fiji Time Wallis and Futuna Time Tuvalu Time PETT Petropavlovsk Time Nauru Time Marshall Island Time GILT Gilbert Island Time ANAT Anadyr Time 12.75...

  • Page 24: Communications Reporting Codes

    Internet Alarm Communicator Installation Manual Communications Reporting Codes Table 9: Communications Reporting Codes Event Reporting Event Reporting User/ Identifier Qualifier Code Code Code Zone [023] Panel Absent Trouble 0001 [024] Panel Absent Trouble Restore 0001 [026] Ethernet 1 Test Transmission 0001 [027] Ethernet 2 Test Transmission 0002...

  • Page 25: Ethernet Receiver 1 Options

    Internet Alarm Communicator Installation Manual Interval 2: The module will send periodic test transmissions to secondary receivers (Ethernet secondary) independently, with no backups. • If the test transmission fails to any of the programmed secondary receivers, an FTC trouble will be generated.

  • Page 26: Ethernet Receiver 2 Options

    Internet Alarm Communicator Installation Manual NOTE: Each Ethernet receiver must be programmed with a unique DNIS. [103] Ethernet Receiver 1 Address Default (127.000.000.001) The default address enables the communicator to operate in Unattended Mode. Unattended mode is used when a receiver is not available and the unit is required to perform DLS sessions.

  • Page 27: Ethernet Options

    Internet Alarm Communicator Installation Manual [115] Ethernet Receiver 2 UDP Local Port Default (0BF9/3065) Use this section to program the value of the local outgoing port. You can set the value of this port when your installation is located behind a firewall and must be assigned a particular port number as determined by your network administrator.
  • Page 28 Internet Alarm Communicator Installation Manual Table 12: Response Code Descriptions and Corresponding Actions Response Description of Response Code Corresponding Action Code Bad File Version check failed Image type mismatch Contact DSC Tech Support, described the action attempted Device type mismatch with the system and supply them with the Response Code in Hardware type mismatch Section [983].
  • Page 29 Internet Alarm Communicator Installation Manual [984] Communicator Status The communicator status sections provide the installer with the status of the communicator’s func- tionality, operational readiness, and failures. The communicator status is displayed as a 6-digit hexadecimal code. The code ranges between 00000F and 2220CF, though not all numbers in this range are assigned.

  • Page 30: System Reset Defaults

    Internet Alarm Communicator Installation Manual System Reset Defaults [999] Software Default Default (99); The software default allows the installer to refresh the unit after changes and also return the com- municator to the default state. 00: Default Module. All programming sections in module revert to factory settings. This will erase all existing programming of the unit.

  • Page 31: System Options

    Internet Alarm Communicator Installation Manual THERNET ROGRAMMING ORKSHEETS System Options [013] DLS Outgoing Port [001] Ethernet IP Address Default (0BFA/3066) Valid range: 0000 - FFFF. Default (000.000.000.000) |____|____|____|____| |____|____|____||____|____|____||____|____|____||____|____|____| [015] DLS Call-Up IP [002] Ethernet IP Subnet Mask Default (000.000.000.000) Default (255.255.255.000) |____|____|____||____|____|____||____|____|____||____|____|____| |____|____|____||____|____|____||____|____|____||____|____|____|...

  • Page 32: Ethernet Receiver 1 Options

    Internet Alarm Communicator Installation Manual [035] Panel Firmware Update Begin [106] Ethernet Receiver 1 Domain Name Default (FF) Program 00 disable or FF enable. Default ( ) 32 ASCII characters.  |____|____| Programming not permitted on UL/ULC listed system. ________________________________ [036] Panel Firmware Update Successful Default (FF) Program 00 disable or FF enable.

  • Page 33: System Reset Defaults

    Ethernet Alarm Communicator Installation Manual [988] DNS 1 IP Address |____|____|____||____|____|____||____|____|____||____|____|____| [989] DNS 2 IP Address |____|____|____||____|____|____||____|____|____||____|____|____| [990] Boot Loader Version |____|____|____|____|____|____|____|____| [991] Firmware Version |____|____|____|____|____|____|____|____| [992] Ethernet IP Address |____|____|____||____|____|____||____|____|____||____|____|____| [993] Ethernet Gateway Address |____|____|____||____|____|____||____|____|____||____|____|____| [998] MAC Address |____| _ ___| _ ___| _ ___| _ ___| _ ___| | _ ___| _ ___| _ ___| _ ___| _ ___| _ ___| System Reset Defaults [999] Software Default Default (99);...

  • Page 34: Limited Warranty

    Ethernet Alarm Communicator Installation Manual IMITED ARRANTY Digital Security Controls (DSC) warrants the original pur- mate shall be provided. No repair work will be performed chaser that for a period of twelve (12) months from the date until a valid purchase order is received from the Customer of purchase, the product shall be free of defects in materials and a Return Merchandise Authorisation number (RMA) is and workmanship under normal use.
  • Page 35 SOFTWARE and any related HARDWARE) and Digital Security COPYRIGHT - All title and intellectual property rights in and to the Controls (DSC), a division of Tyco Safety Products Canada Ltd., the SOFTWARE PRODUCT (including but not limited to any images,...
  • Page 36 NMB-003 du Canada. ence Problems’. This booklet is available from the U.S. Govern- 2 9 0 0 8 8 6 4 R0 0 1 © 2014 Tyco International Ltd. and its Respective Companies. All Rights Reserved. Toronto, Canada www.dsc.com •...
