3G2055-NA
HSPA/3G W
A
C
IRELESS
LARM
OMMUNICATOR
TL255-NA
E
/I
A
C
THERNET
NTERNET
LARM
OMMUNICATOR
TL2553G-NA
E
/I
HSPA/3G/2G D
-P
A
C
THERNET
NTERNET AND
UAL
ATH
LARM
OMMUNICATOR
v3.0
Installation Manual
Warning: This manual contains information on limitations regarding product use and function and information on the limitations
as to liability of the manufacturer.
Advertisement
Table of Contents
Related Manuals for Tyco DSC 3G2055-NA
Summary of Contents for Tyco DSC 3G2055-NA
- Page 1 3G2055-NA HSPA/3G W IRELESS LARM OMMUNICATOR TL255-NA THERNET NTERNET LARM OMMUNICATOR TL2553G-NA HSPA/3G/2G D THERNET NTERNET AND LARM OMMUNICATOR v3.0 Installation Manual Warning: This manual contains information on limitations regarding product use and function and information on the limitations as to liability of the manufacturer.
-
Page 2: Table Of Contents
3G Alarm Communicator Installlation Manual ABLE OF ONTENTS Warning: Installer Please Read Carefully ..............3 General Information . -
Page 3: Warning: Installer Please Read Carefully
3G Alarm Communicator Installlation Manual Warning: Installer Please Read Carefully WARNING: I NSTALLER LEASE AREFULLY Note to Installers Motion Detectors The Warnings on this page contain vital information. As the only individual in Motion detectors can only detect motion within the designated areas as shown in contact with system users, it is the installer’s responsibility to bring each item in their respective installation instructions. -
Page 4: General Information
Keypad Data Display 3G Alarm Communicator Installlation Manual ENERAL NFORMATION Domain Name Service (DNS) programming is not permitted in UL/ULC listed systems. EYPAD ISPLAY • Section-Toggle Options: The number is displayed when Toggle is ON, the number is not displayed when Toggle is OFF. (e.g., Tog- gle Options displays: “[--3--6--]”. -
Page 5: Communicator Technical Specifications
3G Alarm Communicator Installlation Manual General Information OMMUNICATOR ECHNICAL PECIFICATIONS ENERAL NFORMATION All versions of the HSPA/3G and Ethernet Alarm Communicator, operate on a HSPA/3G network and are housed inside the Self Con- tained Wireless (SCW) 9055/9057. The Communicators use an Internal Antenna only. ( Author’s Note: Underlined bu Aun. -
Page 6: Ratings
6. When you are at the physical installation site, the Communicator will automatically connect and download its programming from Connect24 once the unit is initialized. 1. Connect24, DSC, and DLS IV are Registered Trademarks of Tyco International Ltd. and its respective Companies. All Rights Reserved. -
Page 7: Encryption
3G Alarm Communicator Installlation Manual Encryption NOTE: Following initial installation, you can log in to the Connect24 website at any time to re-configure the Communicator remotely, using the account created for this installation. For more information, refer to the Connect24 website. Before leaving the installation site, the Communicator TL2553G or TL255 shall be connected via an APPROVED (acceptable to the local authorities) Network Interface Device (NID) (e.g., for UL Installations, U60950 listed NID). -
Page 8: Communicator Reset
Inserting/Removing the SIM Card 3G Alarm Communicator Installlation Manual SIM C NSERTING EMOVING THE Figure 3: SIM Card Pinouts 1.Remove the front cover of the SCW Control Panel to access SIM card holder. 2.Remove power from the SCW and disconnect the backup battery connections. 3.On the SIM card holder push gently to slide the cover towards OPEN as indicated by the arrow on SIM holder. -
Page 9: Label Programming For Sms Message
3G Alarm Communicator Installlation Manual Label Programming for SMS Message 6. Panel Section [382]: Toggle Option [5], ‘GS/IP Module Enabled’, must be set to ON. 7. Panel Section [401]: Toggle Option [1] must be set to ON in order to perform panel DLS session through Cellular or Ethernet data chanel. -
Page 10: Ethernet/Cellular Programming Options
System Options 3G Alarm Communicator Installlation Manual ETHERNET/C ELLULAR ROGRAMMING PTIONS The Programming Sections described in this document can be viewed at the SCW LCD. To start programming enter: [*][8][installer code] [851][# # # ], Where # # # is the 3 digit Section number referenced in this section. The Programming Worksheets at the end of this document can be used to record the new values when programming changes have been made from the default values. - Page 11 3G Alarm Communicator Installlation Manual System Options [005] System Toggle Options [1] Ethernet Receiver 1 Supervised Default (OFF) (TL255/TL2553G only). ON: Ethernet Receiver 1 will be supervised and heartbeats will be sent to Ethernet Receiver 1 based on the supervision interval pro- grammed in Section [004].
-
Page 12: Programming Options
Programming Options 3G Alarm Communicator Installlation Manual [006] System Toggle Options 2 [1] Ethernet 1 Receiver Enabled. Default (ON) (OFF for 3G2055). ON: Ethernet Receiver 1 is enabled. OFF: Ethernet Receiver 1 is disabled. [2] Ethernet 2 Receiver Enabled. Default (ON) (OFF for 3G2055). ON: Ethernet Receiver 2 is enabled. -
Page 13: Communications Reporting Codes
3G Alarm Communicator Installlation Manual Communications Reporting Codes ing your firewall with this port is not required. Valid range: 0000-FFFF. NOTE: If Section [006] Toggle Option [7] is ON. DLS will use the Primary path for session. If Section [006] Toggle Option [7] is OFF DLS will use the Ethernet path, if available. -
Page 14: Ethernet Receiver 1 Options
Ethernet Receiver 1 Options 3G Alarm Communicator Installlation Manual [026] Ethernet 1 Transmission Default (FF) Program 00 to disable this event transmission or FF to enable. See System Test Options (above) for details on settings. [027] Ethernet 2 Transmission Default (00) Program 00 to disable this event transmission or FF to enable. -
Page 15: Ethernet Options
3G Alarm Communicator Installlation Manual Ethernet Options [112] Ethernet Receiver 2 DNIS Default (000000) The DNIS is used in addition to the account code to identify the Communicator module at the central station. Valid range: 000000 - 099999. Value is entered as leading 0 followed by the 5 digit DNIS. Format is BCD. NOTE: Each Ethernet/Cellular receiver must be programmed with a unique DNIS. -
Page 16: Cellular Receiver 2 Options
Cellular Receiver 2 Options 3G Alarm Communicator Installlation Manual [203] Cellular Receiver 1 Address Default (000.000.000.000) Enter the Cellular Receiver 1 IP address. This information will be provided by your central station system administrator. Each 3 digit segment of the address must be within a valid range of 000-255. NOTE: When a valid IP address has been entered, the Cellular is enabled and will communicate events over the Cellular channel. -
Page 17: Interactive Options
3G Alarm Communicator Installlation Manual Cellular Options [222] Cellular Login User Name Default ( ) Some network carriers require you to provide login credentials when connecting to an APN. Program your login User Name in this Sec- tion. Format is up to 32 ASCII characters. NOTE: This Section is not accessible via PC1616/PC1832/PC1864 keypad programming. -
Page 18: Receiver Diagnostic Testing
Receiver Diagnostic Testing 3G Alarm Communicator Installlation Manual The default for each Notification Zone Toggle is OFF. Table 16: Notification Zone 41 - 48 Toggle TOGGLE ZONE [688] Notification Zone 49 - 56 Toggle Options The default for each Notification Zone Toggle is OFF. Table 17: Notification Zone 49 - 56 Toggle TOGGLE ZONE... -
Page 19: System Reset Defaults
3G Alarm Communicator Installlation Manual System Reset Defaults This Section will display the unique 15 digit International Mobile Equipment Identity (IMEI) of the radio. Format is: Reporting Body Identifier (2 digits), Allocation Number (4 digits); Final Assembly Code (2 digits); Serial Number (6 digits); and a check digit. [998] MAC Address This Section will display the unique12 digit, hexadecimal number assigned as the Media Access Control (MAC) address of the device. - Page 20 System Reset Defaults 3G Alarm Communicator Installlation Manual...
-
Page 21: Ethernet/Cellular Programming Worksheets
3G Alarm Communicator Installlation Manual System Options THERNET ELLULAR ROGRAMMING ORKSHEETS [022] Communications Format YSTEM PTIONS Default (04) Program 03 (CID), 04 (SIA). [001] Ethernet IP Address |____|____| Default (000.000.000.000) |____|____|____||____|____|____||____|____|____|____|____|____| [023] Panel Absent Trouble [002] Ethernet IP Subnet Mask Default (FF);... -
Page 22: Ethernet Options
Ethernet Options 3G Alarm Communicator Installlation Manual [112] Ethernet Receiver 2 DNIS [213] Cellular Receiver 2 Address Default (000000) Valid range: 000000 - 0FFFFF. Default (000.000.000.000) Valid segment range: 000-255 |____|____|____|____|____|____| |____|____|____||____|____|____||____|____|____|____|____|____| [113] Ethernet Receiver 2 Address [214] Cellular Receiver 2 Port Default (000.000.000.000) Default (0BF5/3061) Valid range: 0000 - FFFF. -
Page 23: Receiver Diagnostic Testing
3G Alarm Communicator Installlation Manual Receiver Diagnostic Testing [689] Notification Zone 57 - 64 Toggle Options |____|____|____|____|____|____|____|____| 57 58 59 60 61 62 63 64 ECEIVER IAGNOSTIC ESTING [901] Diagnostic Test Transmission |___| [1] Ethernet 1 Default (OFF). |___| [2] Ethernet 2 Default (OFF). |___| [3] Cellular 1 Default (OFF). -
Page 24: End User Licence Agreement
EULA if You fail to comply with the terms and conditions of this EULA. In such HARDWARE) and Digital Security Controls (DSC), a division of Tyco Safety event, You must destroy all copies of the SOFTWARE PRODUCT and all of its Products Canada Ltd., the manufacturer of the integrated security systems and the... -
Page 25: Limited Warranty
3G Alarm Communicator Installlation Manual Limited Warranty IMITED ARRANTY Digital Security Controls (DSC) warrants the original purchaser products disassembled or repaired in such a manner as to that for a period of twelve (12) months from the date of purchase, adversely affect performance or prevent adequate inspection or the product shall be free of defects in materials and workmanship testing to verify any warranty claim. - Page 26 Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. 2 9 0 0 7 8 5 0 R 0 0 1 © 2011 Tyco International Ltd. and its Respective Companies. All Rights Reserved. Toronto, Canada · www.dsc.com...
