- Page 1 FZ-SM03B-1 1.5~8kg (3.3~17.6lbs) RA TED Scan the QR code with your mobile device follow the link for know more about FEZIBO products. https://www.facebook.com/Fezibous/?ref=bookmarks Service@fezibo.com www.facebook.com/Fezibous www.fezibo.com...
- Page 2 Safety Hazard Symbols Review: These symbols alert users of a safety condition that demands attention. All users should be able to recognize and understand the significance of the following Safety Hazards if encountered on the product or within the documentation. Children who are not able to recognize and respond appropriately to Safety Alerts should not use this product without adult supervision! Symbol Signal Word...
-
Page 3: Features And Specifications
Features & Specifi cations 170mm min220~max275mm 60mm 75mm 100mm 114mm 3.3 - 17.6 lbs (1.5 - 8kg) CAUTION: DO NOT EXCEED MAXIMUM LISTED WEIGHT CAPACITY. SERIOUS INJURY OR PROPERTY DAMAGE MAY OCCUR! 360° 45° 360° 180° 45°... - Page 4 Parts Tools required O (x1) P (x1) Q (x1) Phillips 4mm Allen 6mm Allen Screwdriver Wrench Wrench Wrench (not included) Components A (x1) B (x1) C (x1) D (x1) E (x1) F (x1) G (x1) VESA Plate Clamp Base Clamp Cable Clip Long Screw Base Support...
- Page 5 Choose Mounting Method Apply pads (N) to bottom of base to prevent table top from being scratched.
- Page 6 Secure clamp (D) to upper two holes with Secure clamp (D) to lower two holes with bolts (L) using 4mm Allen wrench (O) for bolts (L) using 4mm Allen wrench (O) for desks with a thickness of 10-55mm. desks with a thickness of 50-85mm. Attach base support cover (E)to clamp base support (C).
- Page 7 OPTION B: Grommet Base Installation Slide long screw (F) through the top of the grommet base support (G) and install on base of monitor stand with bolts (M) using 4mm Allen wrench (O). Apply pads (N) to bottom of base. Position stand on desk with long screw through hole, and secure by using the support plate (H) and washer (J) on underside of the mounting surface, tighten the nut (I) with wrench (Q).
- Page 8 ATTACH DISPLAY OPTION A: Flat Back Monitor Attach the VESA plate (B) to back of monitor and secure with screws (M-A) or (M-C) with washers (M-E). Avoid excessive tightening screws damage the monitor. OPTION B: Curved Back Monitor Attach the VESA plate (B) to back of monitor and secure with screws (M-B) or (M- D) with washers (M-E) and washers (M-F).
-
Page 9: Adjust The Tension
Slide the monitor onto the head of swivel arm, install the security nut (K). Make sure the security nut is installed before you rotate the monitor Adjust the tension direction) reduces tension, counter mount. -
Page 10: Cable Management
Cable Management For both bottom and upper portion of the spring arm, just slide the cable cover up and away from the spring arm, do not need to take much effort to pull the ends of the cable cover away from the spring arm. On the bottom portion of the spring arm, insert the cable and slide the cable cover down;... - Page 11 If any parts are received damaged or defective, please contact us. We are happy to replace parts to ensure you have a fully functioning product. Service@fezibo.com www.facebook.com/Fezibous www.fezibo.com For more FEZIBO products, check out our website at: www.fezibo.com...
