- Page 1 FZ-SM02B-2 1.5~8kg (3.3~17.6lbs) RA TED Scan the QR code with your mobile device follow the link for know more about FEZIBO products. https://www.facebook.com/Fezibous/?ref=bookmarks Service@fezibo.com www.facebook.com/Fezibous www.fezibo.com...
- Page 2 TOOLS NEEDED WARNING! DO NOT EXCEED WEIGHT CAPACITY. 17.6 lbs Failure to do so may result in serious injury. (8 kg) If you do not understand these directions, or if you have any doubts about the safety of the PER ARM installation, please call a qualified technician.
- Page 3 STEP 1 (Continued) STEP 3 OPTION B: Grommet Base Installation Adjust arm (A) to desired height. Tighten using 6mm Allen key (L). For grommet hole attachment, disassemble clamp (B) using 6mm Allen key (L) and a Phillips screwdriver. Attach base (J) to pole (E) through ⅜” (10mm) grommet hole in desktop. Secure using bolt from clamp (B) and plate (I).
- Page 4 STEP 5 STEP 7 Slide VESA plate (D) over bracket on arm (A). Secure using thumb screw (G). Remove bottom covers Adjust tension in arm and angle of monitor using 6mm Allen key (L). Clockwise reduces tension, from arm (A). counterclockwise increases tension.
- Page 5 If any parts are received damaged or defective, please contact us. We are happy to replace parts to ensure you have a fully functioning product. Service@fezibo.com www.facebook.com/Fezibous www.fezibo.com For more FEZIBO products, check out our website at: www.fezibo.com...
