- Page 1 FZ-SM01B-2 1.5~8kg (3.3~17.6lbs) RA TED Scan the QR code with your mobile device follow the link for know more about FEZIBO products. https://www.facebook.com/Fezibous/?ref=bookmarks www.fezibo.com Service@fezibo.com www.facebook.com/Fezibous...
- Page 2 Safety Hazard Symbols Review: These symbols alert users of a safety condition that demands attention. All users should be able to recognize and understand the significance of the following Safety Hazards if encountered on the product or within the documentation. Children who are not able to recognize and respond appropriately to Safety Alerts should not use this product without adult supervision! Symbol Signal Word...
-
Page 3: Features And Specifications
Features & Specifi cations 3.3 - 17.6 lbs (1.5 - 8kg) 75mm 3.3 - 17.6 lbs (1.5 - 8kg) CAUTION: DO NOT EXCEED MAXIMUM LISTED WEIGHT CAPACITY. SERIOUS INJURY OR PROPERTY DAMAGE MAY OCCUR! 360° 45° 360° 180° 45°... - Page 4 Phillips 4mm Allen 5mm Allen 6mm Allen Screw driver Wrench Wrench Wrench Wrench (not included) (x2) Pole Base VESA Plate Clamp Base Clamp Cable Clip Long Screw Support (x2) (x2) (x3) Q (x3) Base Support Washer Security Nut Bolts Bolts Bolts Support Plate...
- Page 5 Choose Mounting Method OPTION A: Clamp Installation Install clamp base support (C) onto base of monitor stand (A) with bolts (M) using provided 4mm Allen wrench (O). Bolt Apply pads (N) to bottom of base to prevent table top from being scratched.
- Page 6 Secure clamp (D) to upper two holes Secure clamp (D) to lower two holes with bolts (L) using 4mm Allen wrench with bolts (L) using 4mm Allen wrench (O) for desks with a thickness of (O) for desks with a thickness of 10-55mm.
- Page 7 OPTION B: Grommet Base Installation Slide long screw (F) through the top of the grommet base support (G) and install on base of monitor stand with bolts (M) using 4mm Allen wrench (O). Apply pads (N) to bottom of base. Position stand on desk with long screw through hole, and secure by using the support plate (H) and washer (J) on underside of the mounting surface, tighten the nut (I) with wrench (Q).
- Page 8 ATTACH DISPLAY OPTION A: Flat Back Monitor Attach the VESA plate (B) to back of monitor and secure with screws (M-A) or (M-C) with washers (M-E). Avoid excessive tightening screws damage the monitor. OPTION B: Curved Back Monitor Attach the VESA plate (B) to back of monitor and secure with screws (M-B) or (M- D) with washers (M-E) and washers (M-F).
-
Page 9: Adjust The Tension
Slide the monitor onto the head of swivel arm, install the security nut (K). Make sure the security nut is installed before you rotate the monitor. Adjust the tension Be sure to keep the arm in Adjust gas spring tension by turning screw horizontal position during with 6mm Allen wrench (P) . -
Page 10: Cable Management
Cable Management For both bottom and upper portion of the spring arm, just slide the cable cover up and away from the spring arm, do not need to take much effort to pull the ends of the cable cover away from the spring arm. On the bottom portion of the spring arm, insert the cable and slide the cable cover down;... - Page 11 If any parts are received damaged or defective, please contact us. We are happy to replace parts to ensure you have a fully functioning product. Service@fezibo.com www.facebook.com/Fezi bous www.fezibo.com For more FEZ I BO products, check out our website at: www.fezibo.com...
