INSTALLATION AND
OPERATION MANUAL
805-0035 REV A
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Lynk Lite and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DISCOVER Lynk Lite

Summary of Contents for DISCOVER Lynk Lite

  • Page 1 (950-0040) INSTALLATION AND OPERATION MANUAL 805-0035 REV A...

  • Page 2: Table Of Contents

    5.2 Installing the External Power Source 5.3 LYNK Network Communication Cables 5.4 Verification of the LYNK Network 6.0 Connecting to LYNK ACCESS 7.0 Configuring the CAN Communication with LYNK ACCESS 8.0 Updating LYNK LITE Firmware with LYNK ACCESS 9.0 Specifications...

  • Page 3: Audience, Safety, Messages And Warnings

    1.0. AUDIENCE, SAFETY, MESSAGES AND WARNINGS 1.1 Audience Qualified personnel should perform configuration, installations, service, and operating tasks in consultation with local utilities and authorized dealers. Qualified personnel should have training, knowledge, and experience in: • Installing electrical equipment • Applying applicable installation codes •...

  • Page 4: About Lynk Lite

    Battery website. 2.4 Firmware Revision This User Manual is valid for LYNK firmware version 1.4.0 and above. Use LYNK ACCESS software to view the firmware version of your LYNK LITE device. 3.0 Items Shipped in the Box Discover LYNK LITE device...

  • Page 5: Design And Features

    4.0 Design and Features Figure 1: Ports, Buttons, LEDs, and Mounting Hold Downs LYNK Port IEC M12 PIN connector used for network communications. Termination Configurable. (Terminated by Default) USB Type-B USB device port used to connect with LYNK ACCESS Micro software on Windows 10 devices.

  • Page 6: Reset Operation

    4.1 Reset Operation To reset LYNK LITE, remove and reconnect power to the device. NOTICE HAZARD OF EQUIPMENT DAMAGE Cycling power to LYNK II will cause communications with other devices to be interrupted. Cycling power will not alter previous settings.

  • Page 7: Lynk Port Pin Assignment

    4.3 LYNK Port Pin Assignment Description Do not populate. Do not terminate to ground. Do not terminate to power. Do not terminate to CAN L or CAN H. AEbus CAN L AEbus CAN H Figure 3. PIN Map for M12 AEbus +12V A-Code Circular Metric AEbus GND...

  • Page 8: Power Sources For Lynk Lite

    LYNK LITE to a flat surface. Mounting screws, bolts and nuts are not included. Threading straps through the integrated Hold Down Points can be used to secure LYNK LITE to an object. Secure all cables to prevent them from working loose or becoming damaged.

  • Page 9: Lynk Network Communication Cables

    4. Repeat until all batteries have been attached in a series network (Figure 6). 5. Attach one end of the series network to the LYNK Port on LYNK LITE. Termination of the other end is not required.
  • Page 10 LYNK Network Cables Available for LITHIUM Part Number PROFESSIONAL Batteries DLP B2B-400 (COMM Cable 0.4 m) 950-0035 DLP TOL-7600 (COMM Cable 7 .6 m) 950-0037 DLP TOL-1800 (COMM Cable 1.8 m) 950-0036 DLP T Connector (COMM T Connector) 950-0038 with DLP B2B-400 (COMM Cable 0.4 m) DLP T Connector (COMM T Connector) 950-0041 Figure 5.

  • Page 11: Verification Of The Lynk Network

    Battery website to obtain the most up-to-date suite of available device configurations. Using a USB cable with a Type-B micro plug, connect the Windows 10 device running LYNK ACCESS software to the USB port on LYNK LITE. Figure 8. LYNK LITE and LYNK ACCESS USB connection.

  • Page 12: Configuring The Can Communication With Lynk Access

    NOTE A powered USB hub may be required. Open LYNK ACCESS. LYNK LITE configurations and settings can be found by selecting the LYNK tab. 7.0 Configuring the CAN Communication with LYNK ACCESS Connect the LYNK and open LYNK ACCESS. Ensure that you only have one LYNK device connected to the Computer.

  • Page 13: Updating Lynk Lite Firmware With Lynk Access

    Failure to follow these instructions may cause damage to the equipment. 8.0 Updating LYNK LITE Firmware with LYNK ACCESS Open LYNK ACCESS and select the LYNK Tab. Select the Firmware Version update button and follow the on-screen prompts to complete the update process.
  • Page 14 NOTES...
