Summary of Contents for Extel Connect 720308
- Page 1 Connect 720308 Installation and User Manual • The latest version of the instructions in colour is downloadable from: www.extelmarket.com EXTEL TV...
-
Page 2: Table Of Contents
Connecting your telephone to a videophone that is already connected e. Interface function TECHNICAL CHARACTERISTICS ......p.12 a. Monitor b. Power supply c. Intercom panel OPTIONS ............... p.12 TECHNICAL SUPPORT - WARRANTY....p.13 SAFETY MEASURES ............ p.14 CFI EXTEL CONNECT - V1... -
Page 3: Safety Instructions
2. Adjustable C-MOS camera lens (at the back of the camera). 3. Speaker: allows the person inside to be heard outside. 4. Call button: when a person presses this button, the doorbell rings inside. The screen and the camera turn on. CFI EXTEL CONNECT - V1... -
Page 4: Installation
If there is a short circuit on the line, protection is triggered. Disconnect and reconnect the power supply after 10 s. a. Connecting the videophone (fig. 6) Important: All the maximum wire lengths shown in the table (fig. 6) must be observed at the same time. CFI EXTEL CONNECT - V1... -
Page 5: Connecting An Electric Strike Plate Or Lock
Videophone settings When your monitor’s display is switched off, your Extel Connect monitor will display the time if you swipe the touch sensitive keys . If you touch these keys again, the main menu will appear. -
Page 6: Lens Adjustment
• To bring back the video feed: To bring back the video feed for an extra 60 seconds, press the key. • Control of an electric strike plate: The strike plate or lock is opened when your press the button. • Control of an automated gate: To control an automated gate, press the key. CFI EXTEL CONNECT - V1... -
Page 7: Settings
Warning Extel Connect is not compatible with 5Ghz Wifi; check that your ADSL Box is 2.4GHz a. Activating the Hotspot on your video doorkeeper When your doorkeeper is first connected to your Extel Connect video, you need to pair it with your smart- phone. -
Page 8: Pairing Your Doorkeeper With An Android Smartphone For The First Time
4. Once the device has been selected, the application will ask you for its password. The password is displayed on the Extel Connect videophone monitor opposite UID. In the example shown in these cg05167913 instructions 5. The application asks you which Wifi network the video doorkeeper can be connected to. Select your network 6. -
Page 9: Pairing Your Doorkeeper With An Iphone For The First Time
2. Select New device. To move to the next step, your telephone must authorise access to your telephone’s loca- tion. If you are asked, grant access to the Extel Connect application. 3. Exit the application and go into the smartphone Wifi settings. Connect to the Wifi starting with ‘UIDcg…’. - Page 10 6-digit password they have selected. e. Interface function Groups the different devices and enables you to move to monitoring mode. Enables you to add a device Click the image to enter monitoring mode. CFI EXTEL CONNECT - V1...
- Page 11 40 kB/s. Full-screen mode Open the electric strike plate or the gate (each opening requires entering the password). Hold pressed to speak to the visitor. Enables you to delete recordings Groups recordings CFI EXTEL CONNECT - V1 EN10...
- Page 12 Warning only photos launched from the application are visible. Photos of visitors’ visits are not available from the application, only from the monitor. Activate/deactivate sound alarms. Activate/deactivate vibration during alarms. Info on the application. Exit the application. Managing settings. CFI EXTEL CONNECT - V1 EN11...
- Page 13 • Gate control: breaking capacity 12V - 2A • Dimensions with shield (mm): 186(h) x 100(l) x 45(d) 9. OPTIONS • All Extel electric strike plates • All Extel electric locks • All Extel motors CFI EXTEL CONNECT - V1...
- Page 14 • In the application settings, check that ‘alarm’ mode is activated. • In the telephone’s settings, check that energy saving mode is deactivated for the Extel Connect application. • On iOS, check that notifications are active for the Extel Connect application.
- Page 15 Let the user know about ‘dangerous voltage’ without insulation inside the casing of the product. The voltage is strong enough to pose a risk of electrocution. CFI EXTEL CONNECT - V1 EN14...
