Notice for Use
Thank you for choosing Eleaf products! Please read this manual carefully
before use so as to use correctly. If you require additional information or have
questions about the product or its use, please consult your local agents, or visit
our website at www.eleafworld.com.
Product Introduction
The Lemo 2 is the advance version of the well-known Lemo series
atomizers due to its new innovative design of a side e-liquid fill hole and the
use of PEEK(the well-known high heat and corrosion resistance material) of
insulating piece. Vaping becomes safer and more stable, and no needs of
detaching the atomizer during refilling. The fill process becomes easier and
the leakage can be avoided. The Lemo 2 also features RBA head which
maximizes the fun of DIY experience. Meanwhile, all stainless steel
construction, visual friendly glass tube and the enlarged air-inlet hole
enhance its usefulness as well.
Standard Configuration
1× Lemo 2 Mouthpiece
1× Lemo 2 Top Cap
1× Lemo 2 Glass Tube
1× Lemo 2 Atomizer Cover
1× Lemo 2 Atomizer Tube
1× Lemo 2 Coil Stand
1× Lemo 2 Atomizer Base
1× Pre-made Heating Coil
1× Heating Coil (1m)
4× Small Screws
4× Seals Gasket (big)
2× Seals Gasket (mid)
5× Silicone (black)
2× Organic Cotton
1× Screw Driver
Coil Stand
Atomizer Base
DIY Instructions
1. First, cut a piece of heating wire (0.5mm) in a length of 100mm long.
Next, roll the heating wire for about 7-8 circles. The diameter of the circle
is about 3mm. Bend both ends of this wire and cut out excess wire.
Note: Please use the resistance detector to check the coil before use,
make sure the resistance is at least 0.3ohm.
2. Loosen the screws on the atomizer base and install the ready-made coil
into the corresponding posts on the base. Use screws to secure the
heating coil.
Screw
3. Use a tweezers to press a certain length of cotton through the coil and
cut out the excess cotton.
4. Scatter the cotton and drip a few drops of e-liquid on it to make sure it is
moist.
Atomizer Cover
Atomizer Tube
100mm
Lemo 2
User Manual
Top Cap
Glass Tube
Mouthpiece
