To avoid overheating we recommend to turn off the device while transporting. Always
The Eleaf Pico is a tiny but very powerful unit operating between 1 watt to 70 watts or 200 to 600 F. It works ideally
with the top filling Melo III Mini tank and the supplied 0.3 ohm coils deliver excellent vape and taste. Powered by a
single, interchangeable, 18650 battery it can be set to Variable Wattage (VW), Bypass, and Temperature Controlled
(TC) modes and can be used with Nickel 200 (Ni), Titanium (Ti) and Stainless Steel 316 (SS) M1,M2,M3.
For the expert vaper there is the Temperature Coefficient of Resistance (TCR) mode which allows the devise to
support different temperature control coils. These are under the modes M1, M2 and M3. These modes allow for
alternate Coils to be used (includes re-buildable for the more experienced Vaper) these modes are not needed when
using Eleaf coils provided with the kit or the Eleaf temperature control Nickel coils.
The kit includes:
1 X iStick Pico (18650, 2500mah, batteries sold separately)
1 X Melo III Mini tank – 2ml, top fill, with 0.5 coil and spare 0.3 ohm coil
1 x USB charger
1 x User Manual

How to use:

Note: 1) Ensure you use a high-
rate 18560 cell whose
continuous discharge current
should be above 25
amps.
2) Do not use a cell which has a
torn casing as this can be
dangerous.
3) Before using the Pico set the
wattage to the appropriate
level suitable to the coil
resistance in the clearomiser.
Stealth on/off:
To turn off the OLED screen, but still vape, press the fire button and down button simultaneously.
You can press the fire button once to see current setting. This will increase the battery life.
Lock/unlock:
Press and hold for 2 seconds the "up" and "down" buttons to lock the unit and repeat to unlock.
To change the orientation of the OLED when the unit is powered off press the "up" and "down" buttons for 2
seconds.
Switching vape modes:
display the current vaping mode. Press the "up" or "down" button to scroll through the various modes - Variable
Wattage, Bypass, TC –Ni, TC-Ti, TC-SS, TCR-M1, TCR-M2 and TCR-M3. To select a mode press the fire button once.

*Important notice*

use compatible chargers provided.
With the unit powered on, press the fire button 3 times in quick succession, the OLED will

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iStick Pico and is the answer not in the manual?

Questions and answers

Summary of Contents for Eleaf iStick Pico

  • Page 1 The Eleaf Pico is a tiny but very powerful unit operating between 1 watt to 70 watts or 200 to 600 F. It works ideally with the top filling Melo III Mini tank and the supplied 0.3 ohm coils deliver excellent vape and taste. Powered by a single, interchangeable, 18650 battery it can be set to Variable Wattage (VW), Bypass, and Temperature Controlled (TC) modes and can be used with Nickel 200 (Ni), Titanium (Ti) and Stainless Steel 316 (SS) M1,M2,M3.
  • Page 2 If you try to use a coil with a resistance above 1.5ohm the devise will automatically switch back to VW mode. Charging: The battery power indicator on the screen of the iStick Pico will flash continuously when the remaining power of the 18650 cell is less than 10%, it will flash during charging and go out when fully charged.
