- Page 1 Installation and Operation Manual WALL-HUNG THERMAL STORE PS 80 Z PS 80 Z...
- Page 2 CONTENTS 1 Description ............................1.1 Tank protection ........................1.2 Connection points on the tank ....................1.3 Packaging ..........................2 General Information .......................... 3 Technical Data and Dimensions of P 80 Z Tank ................4 Operation ............................5 Examples of Assigning Connection Points ..................6 Installation and Commissioning ......................
- Page 3 1 - Description The wall-hung thermal store PS 80 Z is intended for storing and subsequent distribution of thermal energy. It is suitable as a buffer tank for inverter heat pumps to ensure a sufficient volume of water for defrosting the evaporator.
- Page 4 3 - Technical Data and Dimensions of P 80 Z Tank Technical Data Total tank volume 77 l Max. temperature in tank 80 °C Max. pressure in tank 3 bar Tank diameter 400 mm Tank diameter with insulation 450 mm Tank overall height 865 mm Tank perimeter insulation thickness...
- Page 5 - pump station for DHW recirculation – CSE TV ZV - heating system expansion vessel - RegulusBOX indoor unit - PS 80 Z thermal store - HV 60/125-2 manifold/collector - pump station for heating circuit 2 – CSE2 MIX - pump station for heating circuit 1 – CSE2...
- Page 6 6 - Installation and Commissioning Installation must meet valid rules and may be done only by qualified staff. Defects caused by improper installation, use or handling are not covered by warranty. After the tank is installed and connected to an existing heating system, it is recommended to clean the entire heating system using a suitable cleaning agent, e.g.
- Page 7 7 - Maintenance If the tank is fitted with a heating element, disconnect it from the mains first. Clean the exterior of the tank with a soft cloth and a mild detergent. Never use abrasive cleaners or solvents. Check all tank connections for leaks. 8 - Disposal Packaging shall be disposed of in compliance with the valid rules.
- Page 8 ©2022 We reserve the right to errors, changes and improvements without prior notice. REGULUS spol. s r.o. E-mail: sales@regulus.eu Web: www.regulus.eu...
