- Page 1 BabyO2 Pulse Oximeter User Manual Contact us: service@getbabytone.com Website: www.welluehealth.com...
-
Page 2: Table Of Contents
Contents 1 Introduction..............3 2 Overview..............4 3 Using the device and App ..........5 4 PC software ............. 13 5 Maintenance ............13 6 Troubleshooting ............14 7 Specifications ............14 8 Symbols..............16... -
Page 3: Introduction
Introduction Intended use This Pulse Oximeter is intended to be used for measuring the pulse oxygen saturation (SpO2), pulse rate of adults, children and newborns in home or healthcare facilities environment. Contraindications No contraindications. Warnings and Cautions DO NOT twist the sensor and the wrap or apply excessive force on ... -
Page 4: Overview
undesirable changes in skin characteristics, such as irritation, reddening, blistering or burns. Do not open the device cover without authorization. The cover should only be opened by a qualified service personnel. The biocompatibility testing has been performed on the materials ... -
Page 5: Using The Device And App
Connect the sensor and device. Soft wraps: Secure the sensor and the device. Data/Charging Cable: Can be charged and data transmission. Using the device and App Download App App name: ViHealth App Store iOS: Android: Google Play Notice: if you have installed the App before, please update it to the latest version. - Page 6 if not connected to phone for 2 minutes. Even with sensor cable connected, it will power off automatically if no working for 10 minutes. Placement Guide before working To ensure that the measurement is performed normally, please follow the steps below to wear the device. Plug the sensor cable into the device Foot/finger wrap Sensor cable...
- Page 7 the foot. The device should be oriented to the baby’s leg. Put the foot wrap around the foot and attach the velcro securely with no gap between the foot wrap and the baby’s skin. The light emitter and the light detector should be opposite to each other on the two sides of the foot.
- Page 8 A. Tie the finger wrap with the sensor to the finger of the appropriate size. B. The sensor cable should run along the direction of the palm. C. The light emitter and the light detector should be opposite to each other on the two sides of the finger. D.
- Page 9 If the screen display “poor signal”, please check if the sensor has been positioned and secured properly. When the above symbol displays on device screen, it indicates the readings is unavailable right now. When at rest, there will be readings in a few seconds. If you can’t get readings for a long time, it may be caused by: Improper sensor placement ...
- Page 10 Shenzhen Viatom Technology Co., Ltd. The sensor receives the optical signal from the red light and infra-red light through the finger. Insert the finger into the...
- Page 11 DO NOT PAIR in the settings of your smartphone. Add a new device For the initial use, you need to add a new device. Turn on device, run App, select <BabyO2>; Follow the App instruction to add the new device.
- Page 12 3.10 App Dashboard In App Dashboard, you can view: Real-time oxygen Level, heart rate; Near term trends of oxygen level, heart rate and motion. PI (Perfusion Index). If too weak (being red), please check if the sensor has been positioned and secured properly.
-
Page 13: Pc Software
The Reminder in Dashboard will be activated when oxygen level fall below the pre-set value (Threshold). The Reminder will stop when the oxygen level recover. You can press the Mute icon on Dashboard to mute. 3.13 View Report In App->History, Tap an item in the list, you can check the detailed report, ... -
Page 14: Maintenance
download data from the device With the PC software, you can view and print report, which can also be exported as PDF or CSV files. Maintenance Time & Date After connection with App, device time will sync from your phone time automatically. Cleaning Clean the device with a soft, dry cloth with 75% alcohol. -
Page 15: Specifications
turn on or Device might be Please contact your local no response damaged. distributor. The app The Bluetooth of Turn on the Bluetooth in the cannot find your phone is off. phone. the device The device Bluetooth Turn on device is off. - Page 16 (main unit with band and sensor) Display OLED Size 49×27×14 mm (main unit) Battery 5Vdc, Rechargeable Lithium-polymer Charge time 2 hours 16 hours for typical use Battery life Wireless Bluetooth 4.2 BLE Oxygen level range 0% to 100% Oxygen level 70-100%:±2%, 0%-69%:Undefined Accuracy (Arms) A functional tester or SpO2 simulator can be used to determine the...
-
Page 17: Symbols
Symbols Symbol Description Manufacturer Date of manufacture Serial number Indicate separate collection for electrical and electronic equipment (WEEE). Follow Instructions for Use. Type BF Applied Part No alarm system MRI unsafe. Presents hazards in all MR environments as device contains strongly ferromagnetic materials. - Page 18 Symbol Description Temperature limitation Humidity limitation Atmospheric pressure limitation...
- Page 19 FCC Statement FCC Warning: FCC ID: 2ADXK-4728 Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 20 condition without restriction.
- Page 21 Shenzhen Viatom Technology Co., Ltd 4E, Building 3, Tingwei Industrial Park, No.6 Liufang Road, Block 67, Xin'an Street, Baoan District, Shenzhen, 518101, Guangdong, China www.welluehealth.com MedNet EC-REP GmbH Borkstraße 10 48163 Münster Germany Product name: Pulse Oximeter Model: PO5, PO5-1, PO5-2, PO5-3 Version: A Date: Nov.
