Gtech ST05 Safety And Instruction Manual

Gtech ST05 Safety And Instruction Manual

Rapid blade pro cordless trimmer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Safety and Instruction Manual for
ST05 Rapid Blade Pro Cordless Trimmer

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ST05 and is the answer not in the manual?

Questions and answers

Related Manuals for Gtech ST05

Summary of Contents for Gtech ST05

  • Page 1 Safety and Instruction Manual for ST05 Rapid Blade Pro Cordless Trimmer...

  • Page 3: Important Safeguards

    Important Safeguards Electrical safety: IMPORTANT: READ ALL INSTRUCTIONS •Power tool plugs must match the outlet. BEFORE USE. Never modify the plug in any way. RETAIN INSTRUCTIONS FOR FUTURE •Do not use any adaptor plugs with REFERENCE. earthed (grounded) power tools. Unmodified plugs and matching outlets WARNING: will reduce the risk of electric shock.

  • Page 4: Personal Safety

    Personal Safety: •Warning, the cutting element will continue to move after the motor is switched off. •Stay alert, watch what you are doing •Ensure that the motor has fully stopped and use common sense when operating before cleaning, clearing a blockage, a power tool.
  • Page 5 in the manner intended for the particular •Under abusive conditions liquid may be type of power tool, taking into account ejected from the battery; avoid contact. the working conditions and the work to If contact accidentally occurs, flush with be performed. Use of the power tool for water.
  • Page 6 Unpacking: Part location Main unit Power switch Safety button Assist handle Assist handle adjustment knob Telescopic handle Head angle lock Trimmer guard Trimmer guard fixing screw 10. Cutting blade (x20) 11. Charger 12. Charger plug (located in housing) Helpline : 0870 7944001...
  • Page 7 Battery Charging & Recharging The battery is fitted in the handle and CANNOT be removed. Connect the supplied battery charging adaptor to the charging socket located on the rear of the handle. Plug the charger into a suitable electrical socket and switch on. The indicator light on the charger will light RED when the battery is charging.
  • Page 8 Assembly Fitting the trimmer guard onto the base of the head: Remove the guard fixing screw from the housing and retain the screw. Locate the guard onto the head of the trimmer ensuring that the two location hooks engage into the slots on the trimmer head. Push the guard forward until the hooks are fully engaged in the slots.

  • Page 9: Fitting And Replacing The Blade

    Fitting and replacing the blade The trimmer has a removable plastic blade that can be replaced with a new blade quickly and easily. WARNING : do not attempt to remove the blade while the unit is running. Wait until the blade has stopped before attempting to remove the blade. Never fit metal blades.
  • Page 10 Extension tube adjustment The telescopic tube length on the trimmer can be varied to suit different user heights. WARNING : do not attempt to adjust the telescopic tube whilst the blade is rotating. Adjusting the handle length: Grip the trimmer firmly and release the latch on the lower handle. Extend the telescopic tube to the desired length.

  • Page 11: Assist Handle Adjustment

    Assist handle adjustment The angle and reach of the assist handle can be adjusted to your preference. WARNING : do not attempt to adjust the assist handle whilst the blade is rotating. Adjusting the assist handle: Loosen the knob on the side of the handle. Slide the handle along the tube and adjust the angle of the handle to a position which is most comfortable.

  • Page 12: Cutting Head Adjustment

    Cutting head adjustment The cutting head can be adjusted to different angles for ease of cutting in different conditions. WARNING : do not attempt to adjust the cutting head while the blades are rotating. Grip the head of the trimmer, press and hold the button marked ‘PUSH’. Rotate the head to the desired angle.

  • Page 13: Using Your Trimmer

    Using your trimmer The handle is designed with a safety button to prevent accidental starting. To start the trimmer: Press and hold the safety button located on either side of the handle, then press the trigger. Continue holding the trigger and release the safety button. The trimmer will be on for as long as the trigger is pressed.

  • Page 14: Cutting And Edging

    Cutting and edging Caution : remove any stones, loose debris and other objects from cutting area. Always take care when other people are around you. The trimmer may throw out stones and debris at high speed. Hold the trimmer away from the body using both hands Stand in a secure and stable position.

  • Page 15: Troubleshooting

    If the product needs to be repaired or replaced only use parts which are approved by the manufacturer. For further help or assistance please contact the Gtech helpline. Tel : 0870 7944001 email: support@greytechnology.co.uk Helpline : 0870 7944001...
  • Page 16 Call your local council, civic amenity site, or recycling centre for information on the disposal and recycling of electrical products. Alternatively visit www.recycle-more.co.uk for advice on recycling and to find your nearest recycling facilities. Technical specification ST05 Cutting Width 23cm No load speed 8500rpm Battery type 14.4V DC, 1.9Ah Li-Ion...

  • Page 17: Warranty Information

    OUT OF GUARANTEE: If your Gtech product is over 12 month old and you need any parts or advice then please contact our customer services department. Parts will be sent out usually within 3 weeks of request.

  • Page 20: Ec Declaration Of Conformity

    Grey Technology Ltd Units 1&2 Cupola Court Spetchley Worcester WR5 1RL declare that the product ST05 Rapid Blade Pro Cordless Trimmer complies with the essential health and safety requirements of the following directives: 2004/108/EC - EMC Directive. 98/37 EEC - Machinery Directive...
