FILE NO. 033-200309
SERVICE MANUAL
COLOUR TELEVISION
C03P Chassis
43PH36P
– SUMMARY –
43PH36P is the same as 50PH36P except for the parts tabled on back of this sheet.
Use this service manual together with the original service manual of 50PH36P (File No. 030-
200315).
PUBLISHED IN JAPAN, Jun., 2003 So
