Service Manual

DW-3600 (P)

Caution

: In this Manual, some parts can be changed for improving, their

performance without notice in the parts list. So, if you need the

latest parts information,please refer to PPL(Parts Price List) in

Service Information Center (http://svc.dwe.co.kr).

DAEWOO ELECTRONICS CO., LTD.

Washing Machine

DW-3600 (P)

DW-3610 (P)

DW-3620 (P)

DW-3610 (P)

DW-3620 (P)

Table of Contents

Need help?

Do you have a question about the DW-3600 (P) and is the answer not in the manual?

Questions and answers

Summary of Contents for DAEWOO ELECTRONICS DW-3600 (P)

Page 1 : In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information,please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). DAEWOO ELECTRONICS CO., LTD.
Page 2: Table Of Contents
All manuals and user guides at all-guides.com CONTENTS SPECIFICATIONS ..................................2 CAUTION ON THE OPERATION..............................3 WIRING AND CIRCUIT DIAGRAM ..............................4 CIRCUIT DIAGRAM OF WASH TIMER ............................6 TROUBLE SHOOTING GUIDE ..............................7 HOW TO DISASSEMBLE................................9 EXPLODED VIEWS ..................................11 PARTS LIST....................................14...
Page 3: Specifications
All manuals and user guides at all-guides.com 1. SPECIFICATIONS ITEM SPECIFICATIONS Voltage 100V ~ 110V ~ 127/220V ~ 220V ~ 230 ~ 240V ~ 110/220V Power Source Frequency 50/60Hz 60Hz 50 Hz Washer 240/300 W 305 W 305 W 305W Power Consump- Spindryer...
Page 4: Caution On The Operation
All manuals and user guides at all-guides.com CAUTION ON THE OPERATION A. Caution on Installtion • Install the washer in the place easy access to water, electrical power and drainage. • Install the washer on a firm, and flat floor. •...
Page 5: Wiring And Circuit Diagram
All manuals and user guides at all-guides.com...
Page 6 All manuals and user guides at all-guides.com...
Page 7: Circuit Diagram Of Wash Timer
All manuals and user guides at all-guides.com...
Page 8: Troubleshooting Guide
All manuals and user guides at all-guides.com TROUBLESHOOTING GUIDE é Wash Problem Wash Symptom Pulsator Pulsator washing washing water There is does not does not rotation Wash machine machine drains a heavy rotation rotate rotate. of the water will not will not away There is...
Page 9 All manuals and user guides at all-guides.com é Spin Problem Symptom Spin tub Spin tub Spin tub It takes Water The rotation Water does not does not does long for from of the from rotate. rotate. There is spinned There is spin tub spinned (The...
Page 10: How To Disassemble
All manuals and user guides at all-guides.com HOW TO DISASSEMBLE Fig. 1 Fig. 2 1.Replacing motor for spin and wash. b)Remove one bolt on spin basket and remove spin a) Remove a screws on back cover. (Fig. 1) basket. (Fig. 2) Fig.
Page 11 All manuals and user guides at all-guides.com Fig. 7 Fig. 8 g)Remove motor for wash. (Fig. 7) 2.Replacing wash timer and spin timer. a) Remove five screws on panel. (Fig. 8) Fig. 9 Fig. 10 b)Remove spin timer (Fig. 9) and wash timer (Fig. 10)
Page 12: Exploded Views
All manuals and user guides at all-guides.com...
Page 13 All manuals and user guides at all-guides.com...
Page 14 All manuals and user guides at all-guides.com...
Page 15: Parts List
All manuals and user guides at all-guides.com PARTS LIST PANEL ASSY PART NAME PART CODE Q’TY SPEC REMARKS DECORATOR 3611602900 PC FILM 0.25T 3610 3613400100 3600 KNOB 3613400500 3610, 3620 KNOB 3613400600 '“ 44 3610, 3620 LABEL WATER INLET 3613528600 PC FILM 0.25T 3610 3614200100...
Page 16 All manuals and user guides at all-guides.com Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) PART NAME PART CODE Q’TY...
Page 17 All manuals and user guides at all-guides.com Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) TUB ASSY PART NAME PART CODE...
Page 18 All manuals and user guides at all-guides.com Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) PART NAME PART CODE Q’TY...
Page 19 All manuals and user guides at all-guides.com Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) BASE ASSY PART NAME PART CODE...
Page 20 All manuals and user guides at all-guides.com Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) PART NAME PART CODE Q’TY...
Page 21 All manuals and user guides at all-guides.com Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) PART NAME PART CODE Q’TY...
