- Page 1 Transactive Xtra User Manual...
-
Page 2: Table Of Contents
10.1 – Preventative maintenance 11. Emergency stopping 12. Emergency lowering 12.1 Electrical lowering 12.2 Manual lowering 13. Fault finding 14. Specification of the Transactive Xtra 15. General inspection and maintenance 16. Recommended cleaning instruction 27 to 29 17. Standards applied Test certificate Guarantee 18. -
Page 3: Symbols Used
Manufacturer Please observe local laws on recycling Refer to user manual Date of manufacture Serial number Transactive Xtra User Manual Page 3 of 40 Part No. 999015 / Rev.2 / Nov 2017... -
Page 4: Introduction
Transactive Xtra Hoist, carefully read this entire manual, especially the section on “Cautions”. The Transactive Xtra hoist is designed to be used in conjunction with Prism Medical UK hoist track, accessories and slings.. Please refer to any user guides supplied with these components and reference them while reviewing this manual. -
Page 5: Intended Use / Overview
3. Intended Use - Overview of the Transactive Xtra Ceiling Track Hoist The Transactive Xtra is a fixed ceiling hoist, that is, it always remains on the hoist track system. It has the ability to raise an individual up from one location such as a bed, move the individual along the track to another location and finally lower the individual into a chair or a bath. -
Page 6: Component List
4. Component list The following components are included with your new Transactive Xtra hoist system: • Transactive Xtra hoist (manual or motorised traverse option) • Carry bar • Pneumatic hand control & hook • In track hoist charging assembly • Track blocks •... -
Page 7: Hoist Dimensions And Lifting Range
5. Hoist Dimensions and Lifting range The diagram above shows the relevant lifting ranges and dimensional sizes of the hoist Transactive Xtra User Manual Page 7 of 40 Part No. 999015 / Rev.2 / Nov 2017... -
Page 8: Safety Precautions
/ or the individual being hoisted/ transferred. • The TRANSACTIVE XTRA hoist, and associated track and sling (s) are not toys. Do not use it for unsafe practices. Do not allow children to play with the hoist or any of its components. - Page 9 This is severe wear. Any damage leading up to this point should prompt the operator of the device to cease use and seek a replacement. Transactive Xtra User Manual Page 9 of 40 Part No. 999015 / Rev.2 / Nov 2017...
- Page 10 Perform the test as noted in the preceding paragraph. If there are still problems with the hoist, then contact your local authorised dealer for service. Transactive Xtra User Manual Page 10 of 40 Part No. 999015 / Rev.2 / Nov 2017...
-
Page 11: Attaching The Airline Tube To The Hoist 10 To
The metal ribbed pins are on the airline. Image shows the line installed fully into the hoist socket (fig 3c.) Transactive Xtra User Manual Page 11 of 40 Part No. 999015 / Rev.2 / Nov 2017... -
Page 12: Operation
8. Operation Always, before using the TRANSACTIVE XTRA hoist system, the hoist, track and sling must be visually checked for any unusual wear, or damage. Refer to the user manual with each piece of supplied equipment to determine what should be checked. Should anything look unusual, contact your local Freeway dealer prior to use. - Page 13 (fig 4b.) Low battery is indicated by the RED LED and an indicated warning to request that the hoist be re-charged. Transactive Xtra User Manual Page 13 of 40 Part No. 999015 / Rev.2 / Nov 2017...
-
Page 14: Raising And Lowering The Carry Bar
Move the hoist along the track gently pushing the carry bar, or individual in the sling. NEVER pull the hoist along the track using the handset airline Transactive Xtra User Manual Page 14 of 40 Part No. 999015 / Rev.2 / Nov 2017... -
Page 15: Moving The Hoist Along The Track 14 To
Always use extreme care when moving the hoist along the track. Watch out for and avoid any obstructions that may cause injury to the individual in the sling and/ or damage to the hoist Transactive Xtra User Manual Page 15 of 40 Part No. 999015 / Rev.2 / Nov 2017... -
Page 16: Moving The H-System Traversing Beam 16 To
The power traverse H - System hand control, shown above, showing traversing beam movement buttons. Button colours correspond to the black and white directional arrows located on the underside of the hoist. Transactive Xtra User Manual Page 16 of 40 Part No. 999015 / Rev.2 / Nov 2017... -
Page 17: Return To Charge
Note that the RTC feature has several characteristics that may be altered to the user’s preference. This will be set during installation. Transactive Xtra User Manual Page 17 of 40 Part No. 999015 / Rev.2 / Nov 2017... -
Page 18: Hand Control Hook
Transactive Xtra User Manual Page 18 of 40 Part No. 999015 / Rev.2 / Nov 2017... -
Page 19: Charging The Hoist
Use only the charger that was supplied with the hoist. Use of any other charger will void all warranties and may cause damage to the hoist Transactive Xtra User Manual Page 19 of 40 Part No. 999015 / Rev.2 / Nov 2017... -
Page 20: Lcd Display Function
2. Make an audible beeping sound every ten (10) seconds. 3. Flash ‘Low Battery’ in the first line. 4. The bars indicating charge level will flash on and off. Transactive Xtra User Manual Page 20 of 40 Part No. 999015 / Rev.2 / Nov 2017... -
Page 21: Preventative Maintenance
(regardless of which default display mode the user has selected). Flashing To reset the counter which notifies the hoist when to signal for preventative maintenance, please call your local service technician. Transactive Xtra User Manual Page 21 of 40 Part No. 999015 / Rev.2 / Nov 2017... -
Page 22: Emergency Stopping
The unit will beep once and all power to the hoist will be turned off. (fig 10b.) above - Return power to the hoist unit by pressing in the plastic tab Transactive Xtra User Manual Page 22 of 40 Part No. 999015 / Rev.2 / Nov 2017... -
Page 23: Emergency Lowering
Once located use the chain to continue to operate the hoist. After use remove the emergency lowering adaptor and insert the grommet back into the plastic cover. Transactive Xtra User Manual Page 23 of 40 Part No. 999015 / Rev.2 / Nov 2017... -
Page 24: Fault Finding
Ensure the Emergency Lowering tab has not come out. If it has, simply No Power. press the tab back into the hoist. Transactive Xtra User Manual Page 24 of 40 Part No. 999015 / Rev.2 / Nov 2017... -
Page 25: Specification Of The Transactive Xtra
14. Specification of the Transactive Xtra hoist • Hoist Motor: 24 VDC • Traverse Motor: 24 VDC (Optional at time of Purchase) • Frame Traverse Motor: 24 VDC (Optional at time of Purchase) • Charger Input: 240V • Charger Output: 30V 0.5 amps... -
Page 26: General Inspection And Maintenance
15. General Inspection and maintenance a. Each Use - To be completed by User Prior to each use the TRANSACTIVE XTRA hoist and associated track, accessories and sling (s), must be visually inspected. Refer to the accessory and sling user guides for specific details regarding their inspection. - Page 27 • Blood spills should be dealt with by an increased concentration of the solution – please refer to the instructions on the manufacturers product labelling. Transactive Xtra User Manual Page 27 of 40 Part No. 999015 / Rev.2 / Nov 2017...
- Page 28 Handle in accordance with good industrial hygiene and safety practice. Remove and wash contaminated clothing before re-use. Wash face, hands and any exposed skin thoroughly after handling. Transactive Xtra User Manual Page 28 of 40 Part No. 999015 / Rev.2 / Nov 2017...
-
Page 29: Recommended Cleaning Instruction 27 To
The information above has been extracted from the Actichlor MSDS (Manufacturers Safety Data Sheet). For a full review of the data please follow the link below: http://www.nhsggc.org.uk/media/236215/msds-actichlor-plus.pdf Transactive Xtra User Manual Page 29 of 40 Part No. 999015 / Rev.2 / Nov 2017... -
Page 30: Standards Applied
Medical electrical equipment. General requirements for basic safety and essential performance • BS EN ISO 10535 Hoists for the transfer of disabled persons. Requirements and test methods Transactive Xtra User Manual Page 30 of 40 Part No. 999015 / Rev.2 / Nov 2017... -
Page 31: Test Certificate
Transactive Xtra Ceiling Track Hoist TEST CERTIFICATE Safe Working Load: 130Kgs 160Kg 200Kg 270Kg Model: TXM Serial No: ……………………………………………………………………. Date of Test: ……………………………………………………………….. This Test Certificate confirms that the above numbered hoist has been fully tested in accordance with the tests specified in: •... -
Page 32: Guarantee
2. The liability of Prism Medical UK under terms of this guarantee shall be limited to the replacement or the defec-tive part (s) to the sales distributor, dealer, agent, person or entity which purchased the equipment from Prism Medical UK. -
Page 33: Initial Information
Telephone number: ……………………………………..………. Comments: Contact the following company for service : ……………………………………………………………………………………... Company : ……………………………………………………..………………………………… Address : …………………………………… City Postal code: …………………………………………. Telephone number: ………………………………………………. Comments: Transactive Xtra User Manual Page 33 of 40 Part No. 999015 / Rev.2 / Nov 2017... - Page 34 18.2 Service Record History Complete this section after each service, repair inspection and/or maintenance. * Photocopy additional pages as required* Transactive Xtra User Manual Page 34 of 40 Part No. 999015 / Rev.2 / Nov 2017...
- Page 35 Transactive Xtra User Manual Page 35 of 40 Part No. 999015 / Rev.2 / Nov 2017...
- Page 36 Transactive Xtra User Manual Page 36 of 40 Part No. 999015 / Rev.2 / Nov 2017...
- Page 37 Page 37 of 40 Transactive Xtra User Manual Part No. 999015 / Rev.2 / Nov 2017...
- Page 38 Page 38 of 40 Transactive Xtra User Manual Part No. 999015 / Rev.2 / Nov 2017...
-
Page 39: User Notes
User notes: Transactive Xtra User Manual Page 39 of 40 Part No. 999015 / Rev.2 / Nov 2017... -
Page 40: Manufacturer's Details
Unit 1, Tir Llwyd Industrial Estate, Saint Asaph Avenue, • info@prismmedical.co.uk Kinmel Bay, • Tel +44 (0)1924 840 100 Rhyl, • www.prismmedical.co.uk LL18 5JA Transactive Xtra User Manual Page 40 of 40 Part No. 999015 / Rev.2 / Nov 2017...
