A320B Mobile Hoist
Owner's Manual
Use and Care
Trouble Shooting
Warranty Information
Introduction ................................................................... 2
Overview ....................................................................... 2
Components of the Floor Hoist ..................................... 3
Component List ............................................................. 4
Specifications ................................................................ 5
Cautions ........................................................................ 6
Assembly Instruction .................................................... 7
Charging.........................................................14
Start...............................................................14
Forward movement...........................................15
Turning...........................................................15
Leg Adjustment................................................16
Raising and Lowering Boom...............................16
Casters and Braking..........................................16
Basics in transferring an individual............................17
Emergency Stop & Lowering...................................19
Control Box-Usage Information.................................20
Control Box-Service Information................................21
Technical Specifications .........................................22
Do's and Don'ts ....................................................23
Fault finding.........................................................24
General inspection and maintenance.........................25
Points of Attachment - Checklist ..............................26
Service record history.............................................27
Warranty..............................................................31
Prism Medical UK
Unit 4 Jubilee Business Park
Jubilee Way
Grange Moor
Wakefield
WF4 4TD
Tel:
0844 980 2260
Fax:
0844 980 2261
Website:
www.prismmedical.co.uk
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Prism Medical UK A320B
Summary of Contents for Prism Medical UK A320B
-
Page 1: Table Of Contents
A320B Mobile Hoist Introduction ..............2 Overview ............... 2 Components of the Floor Hoist ........3 Component List ............. 4 Specifications ..............5 Cautions ................ 6 Assembly Instruction ............ 7 Operation Charging...……………………………………………...14 Start……...……………………………………………...14 Forward movement….………………………………...15 Turning..………………………………………………...15 Leg Adjustment………………………………………...16 Raising and Lowering Boom………………………….16 Casters and Braking……….………………………..16... -
Page 2: Introduction
Models Table for A320B Floor Hoist Product Code Product Description 280400 A320B - Bariatric Alloy 318Kg (700 lbs). 280401 A320B - Bariatric Alloy 318kg (700 lbs). w/Prism QRS Carry Bar 280400 / 280401 - A320B - Owner’s Manual Rev: 07-2013 Page: 2... -
Page 3: Components Of The Floor Hoist
Push Handle Arm Rest Prism QRS Battery Carry Bar Control Box Up & Down Actuator Leg Spreading Actuator Front Caster Rear Caster w/Brake 4 Point QRS Locking Carry Bar 280400 / 280401 - A320B - Owner’s Manual Rev: 07-2013 Page: 3... -
Page 4: Component List
“Charging Instructions”. The Hand control must also be connected to the floor hoist. If it is not connected, then pl. refer to the section titled “Assembly Instructions”. 280400 / 280401 - A320B - Owner’s Manual Rev: 07-2013 Page: 4... - Page 5 +10 to +70 ºC Relative Humidity: 10 to 100% RH Relative Humidity: 30 to 75% RH Atmospheric Pressure: 500 to 1060 hPa Atmospheric Pressure: 700 to 1060 hPa 280400 / 280401 - A320B - Owner’s Manual Rev: 07-2013 Page: 5...
-
Page 6: Specifications
There is a risk of explosion if the hoist is used in the precsense of flammable anaesthetics. Ensure that a clear space is maintained around the hoist. Move any obstacles out of the way before opereating the floor hoist. 280400 / 280401 - A320B - Owner’s Manual Rev: 07-2013 Page: 6... -
Page 7: Assembly Instruction
DO NOT STAND ON COVER Figure 2 Caution: Possible finger trap. Keep fingers away from the end of the mast when inserting into the tube on the Base assembly. 280400 / 280401 - A320B - Owner’s Manual Rev: 07-2013 Page: 7... - Page 8 Tighten the mast locking knob as shown in Figure 5. Adjust the position of the locking handles pointing in downward direction towards the base as shown in Figure 5. Locking Handles Mast Locking Knob Figure 4 Figure 5 280400 / 280401 - A320B - Owner’s Manual Rev: 07-2013 Page: 8...
- Page 9 7. Remove the screws from the mounting position of push handle on Mast assembly. Insert the screws through the push handle bracket, and mount on the Mast assembly as shown in Figure 14, and 15. Figure 15 Figure 14 280400 / 280401 - A320B - Owner’s Manual Rev: 07-2013 Page: 9...
- Page 10 QRS hook as shown in Figure 19. Make sure that latch is closed safely after the dowel pin sitting into the QRS hook as shown in Figure 20. 280400 / 280401 - A320B - Owner’s Manual Rev: 07-2013 Page: 10...
- Page 11 Figure 20B. Apply the same procedure to detach Prism QRS Carry Bar from hoist as shown in Figure 20C, and 20D. Figure 20B Figure 20A Figure 20C Figure 20D 280400 / 280401 - A320B - Owner’s Manual Rev: 07-2013 Page: 11...
- Page 12 9. Remove the middle screw from the mounting bracket using 3 mm Allan Key as shown in Figure 21. 10. Press the A320B CBJ Care Control Box (280445) against the mounting bracket and slide it down. The con- trol box should be seated securely on top of the edge of bracket as shown in Figure 22.
- Page 13 1. Lifting actuator moving up and down with the buttons on the hand control, and control box. 2. Emergency lowering (mechanical, and electrical) functions works properly. 3. Rear wheel brakes works properly. 4. Leg spreading actuator works properly. 5. Batteries are fully charged. 280400 / 280401 - A320B - Owner’s Manual Rev: 07-2013 Page: 13...
-
Page 14: Operation
This is a purposefully built in safety feature. Please Note! The emergency stop must be released at all times during normal operation. 280400 / 280401 - A320B - Owner’s Manual Rev: 07-2013 Page: 14... -
Page 15: Forward Movement
This movement is performed with a smooth, slow action to avoid swinging the patient un- necessarily. Warning: Do not hold on to the actuator or swing link when turning the hoist as there is a risk of getting your fingers caught. 280400 / 280401 - A320B - Owner’s Manual Rev: 07-2013 Page: 15... -
Page 16: Leg Adjustment
Raising and Lowering the Boom: The up and down movement of boom on A320B hoist is achieved by a powerful electric actuator which is con- trolled by hand control. The hand control has two button with directional arrows UP and DOWN. -
Page 17: Basics In Transferring An Individual
Caution: Prior to lifting an individual make sure that the straps of the sling are securely placed on the hooks of the carry bar. 280400 / 280401 - A320B - Owner’s Manual Rev: 07-2013 Page: 17... - Page 18 The hoist should be turned off when not in use. It is recommended that the hoist be left on charge when not in operation. Refer to the section titled, “ ” for instructions on charging. Charging the hoist 280400 / 280401 - A320B - Owner’s Manual Rev: 07-2013 Page: 18...
-
Page 19: Emergency Stop & Lowering
Emergency Leg Closing Button Mechanical emergency lowering: In case of power failure, it is possible to mechanically lower a patient placed in A320B hoist. Turn the manual lowering handle in clockwise direction to lower the boom until the boom reaches to safe position. -
Page 20: Control Box-Usage Information
Control Box: Usage information The control box of A320B hoist having LCD display to have some basic usage information on the display. Following information will be visible on the LCD display of control box. When it is time for service the service symbol will appear on the display will light up and give notice to users about the need for service. -
Page 21: Control Box-Service Information
Control Box: Service information The control box of A320B hoist having LCD display to have some basic service data on the display. To get this information, press the “lifting arm up” button on hand control for half a second. The information that appears on the display is as shown below. -
Page 22: Technical Specifications
Technical Specifications– A320B 280400 / 280401 - A320B - Owner’s Manual Rev: 07-2013 Page: 22... -
Page 23: Do's And Don'ts
Don't continually operate the hoist functions. The system is not designed for continuous operation. Continuous Operation will cause batteries to be deeply discharged or to damage the actuator or con- trol box by overheating. 280400 / 280401 - A320B - Owner’s Manual Rev: 07-2013 Page: 23... -
Page 24: Fault Finding
Rear caster brake is engaged. • Casters are defective. • Cannot tighten Mast into Base tube. Mast locking assembly are defective, replace with new • Mast locking assembly . 280400 / 280401 - A320B - Owner’s Manual Rev: 07-2013 Page: 24... -
Page 25: General Inspection And Maintenance
This section to be only completed by a qualified service technician as authorized by Prism Medical Ltd. Use the provided service record history sheets to note findings during inspection. 280400 / 280401 - A320B - Owner’s Manual Rev: 07-2013 Page: 25... -
Page 26: Points Of Attachment - Checklist
Wrench - Handle Bar 4mm Allen Key- Mounting Bracket 3mm Allen Key- Mounting Control Box 17mm Wrench - Actuator mounting Locking Handle 13mm and 14 mm Wrench - Carry bar mount 280400 / 280401 - A320B - Owner’s Manual Rev: 07-2013 Page: 26... -
Page 27: Service Record History
__________________________ Comments: SERVICE INFORMATION: Contact the following company for service: Company: ___________________________________________________________ (local authorized Prism Medical Representative) Address: _______________________________________ City: __________________________ Postal Code: ________________ Telephone No: __________________________ Comments: 280400 / 280401 - A320B - Owner’s Manual Rev: 07-2013 Page: 27... - Page 28 Time: ________________________ Service Type: Periodic Inspection Monthly Inspection 6 Month Inspection Repair Yearly Inspection Other:_________ _____________________________ _________________________ Completed By: Printed Name Signature Company: _____________________________________________________________ Remarks & Action Taken: 280400 / 280401 - A320B - Owner’s Manual Rev: 07-2013 Page: 28...
- Page 29 Time: ________________________ Service Type: Periodic Inspection Monthly Inspection 6 Month Inspection Repair Yearly Inspection Other:_________ _____________________________ _________________________ Completed By: Printed Name Signature Company: _____________________________________________________________ Remarks & Action Taken: 280400 / 280401 - A320B - Owner’s Manual Rev: 07-2013 Page: 29...
- Page 30 Time: ________________________ Service Type: Periodic Inspection Monthly Inspection 6 Month Inspection Repair Yearly Inspection Other:_________ _____________________________ _________________________ Completed By: Printed Name Signature Company: _____________________________________________________________ Remarks & Action Taken: 280400 / 280401 - A320B - Owner’s Manual Rev: 07-2013 Page: 30...
- Page 31 Time: ________________________ Service Type: Periodic Inspection Monthly Inspection 6 Month Inspection Repair Yearly Inspection Other:_________ _____________________________ _________________________ Completed By: Printed Name Signature Company: _____________________________________________________________ Remarks & Action Taken: 280400 / 280401 - A320B - Owner’s Manual Rev: 07-2013 Page: 31...
-
Page 32: Warranty
If you have any questions about the manufacture or operation of this equipment, please contact Prism Medical UK, or your local authorised dealer. Prism Medical UK, Unit 4 Jubilee Business Park, Jubilee Way, Grange Moor, Wakefield, WF4 4TD Tel 0844 980 2260 www.prismmedical.co.uk...
