- Page 1 Operating Manual Electronic Table Scales Portion Scale - Serie HW 945 HW945-210409-Rev006-UM-en...
-
Page 2: Table Of Contents
Contents Components and Features ....................2 Key function ......................2 Display symbols ..................... 2 Installation and use of scale ....................3 Check carton contents ................... 3 Power Supply of the scale ..................3 Positioning of the scale ..................4 Quality check ......................4 Use of the scale........................ -
Page 3: Components And Features
Components and Features Key function Attention: The power switch is situated below the display left-hand side. Keys: Function: For changing between weighing program and counting unit program. To set scale to zero during weighing and for adding up during counting mode. -
Page 4: Installation And Use Of Scale
Keep the instructions for use for future reference. Your ADE Portion scale is a quality product. It is a precision instrument and must be treated accordingly. Therefore kindly read and follow the Operating Manual in all respects. -
Page 5: Positioning Of The Scale
Connect the mains adapter to the scale. Quality check ADE products correspond to the applicable EC Directives and European standards to manufacture and distribute world-wide weighing and measuring equipment as per the latest technical standard offering a long lifetime and continuous reliability. -
Page 6: Use Of The Scale
Use of the scale Weighing Power the scale by pressing the tilting switch underneath the base (left hand side). For approx. 3 sec the display shows "SYS - UP" followed by a test run 0000, 1111, 2222 followed by Volt 6.0 (depending on loading status). Finally the scale is changing into weighing mode and shows 0 on display. -
Page 7: Setting The Unit Counting Mode
Setting the unit counting mode Attention: If containers are used, please proceed as explained under Tare function. Once in weighing mode put a reference batch (10, 20, 30 counting parts) on the platform or container (minimum 1%o of the full capacity) . Press MODE key ... -
Page 8: Service
Service Display Indications: Recharge the power-pack by using the mains adapter Any other failure messages e.g. Err 4, Err 5, Err 6 or Err 9 please contact your local dealer or service partner or see Service Manual where authorized technical staff is available. Safety instructions Do NOT use the scale If the mains plug or cable shows visible damages... -
Page 9: Ce Marking And Declaration Of Conformity
RoHS Directive 2011/65/EC in the currently valid versions. This declaration loses its validity if modifications are made to the scale without our approval. Hamburg, April 2021 ADE Germany GmbH Neuer Hoeltigbaum 15 22143 Hamburg / Germany Manufacturer: ADE Germany GmbH... -
Page 10: Technical Data
Technical data Maximum Capacity: 3 kg / 6 lb 30 kg / 60 lb Graduation: 0,1 g / 0,0002 lb 1 g / 0,002 lb Weighing area: 260 x 215 mm Dimensions: 260 x 125 x 310 mm Dead Weight: 3.6 kg Packing dimensions 392 x 301 x 183 mm... - Page 11 HW945-210409-Rev006-UM-en...
