Summary of Contents for ADE M20011
- Page 1 Operating Manual Electronic Column Scale, class III approved, M20011 ADE GmbH & Co. Hammer Steindamm 27 – 29 22089 Hamburg / GERMANY +49(40)432776-0 +49(40)432776-10 E-mail: info@ade-hamburg.de...
-
Page 2: Table Of Contents
Hold function .......................... 5 Unit function ........................... 5 Cleaning, Maintenance and Re-approval ....................6 Cleaning ..........................6 Service ........................... 6 Safety instructions........................6 Storage and Transport ......................6 Warranty..........................6 Re-approval..........................7 Technical data ............................7 Certificate of conformity........................... 8 050100-Rev000-M20011... -
Page 3: Components And Features
UNITS ......To change the weighing unit (kg, lb) CLEAR......Clear indication ENTER......Confirm indication 0 – 9......Numeric keys for storing tare value or height for evaluation of BMI Display symbols Arrows indicating which weighing mode or evaluation mode you have chosen 050100-Rev000-M20011... -
Page 4: Installation And Use Of Scale
Installation and use of scale Your ADE Electronic Column Scale is a class III approved scale which has been manufactured for medical use in hospitals, by doctors or medical specialists and pediatricians. The scale is a precision instrument. The weighing result is used as an essential basis for medical application decided by doctors or medical personnel in hospitals, nursing homes, rehabilitation- and dialysis centres. -
Page 5: Quality Check
Quality check ADE products correspond to the applicable EC Directives and European standards to manufacture and distribute world-wide weighing and measuring equipment as per the latest technical standard offering a long lifetime and continuous reliability. This symbol stands for fulfillment of the European Directive 93/42 EEC for medical devices and declares the conformity as per this Directive. -
Page 6: Body Mass Index (Bmi)
As the exact body length is one essential value we recommend to measure the patient by using together with your ADE scale the height measuring rod model MZ 10019. Start the scale as already described and take the weight. Then press the BMI key and use the numeric key to indicate the height of the patient in cm. -
Page 7: Cleaning, Maintenance And Re-Approval
Disconnect all cables before transport to avoid unnecessary damages. Warranty – Liability ADE will repair or replace this product within a period of 2 years from date of delivery applying to defects occurred due to poor material or workmanship (presentation of invoice is necessary). All moveable parts –... -
Page 8: Re-Approval
250 kg / 550 lbs Graduation: 100 g / 0,2 lb Dimensions (WxHxD): 310 x 1200 x 275 mm Working Temperature: 10 to +40 degrees Celsius Supplier: ADE GmbH & Co. Hammer Steindamm 27 – 29 22089 Hamburg Germany 050100-Rev000-M20011... -
Page 9: Certificate Of Conformity
90/384/CEE sobre básculas no automáticas Ενρωπαικη ΠροδιαγραΦη DIN EN 45501. 93/42/CEE sobre productos médicos y la norma europea DIN EN 45501. ADE GmbH & Co. Hamburg, Januar 2004 ℡ +49(40)432 776 - 0 Hammer Steindamm 27 – 29, 22089 Hamburg... - Page 10 050100-Rev000-M20011...
- Page 11 050100-Rev000-M20011...
- Page 12 050100-Rev000-M20011...
